Summary of Contents for Dragino DT01
- Page 1 DT01 WiFi/3G VoIP PBX / ATA User Manual Document Version: 1.0 Firmware Version: v1.3.5 Version Description Date Initiate 2015-Feb-26 DT01 WiFi/3G VoIP PBX / ATA User Manual 1 / 23...
- Page 2 Upgrade Firmware .................... 21 FAQ ........................22 How to get long distance WiFi range? ............. 22 How to reset DT01 to factory default? ............ 22 How to recover DT01 if firmware crash? ..........22 Reference ......................23 DT01 WiFi/3G VoIP PBX / ATA User Manual...
-
Page 3: Introduction
The DT01 is an Open Source appliance designed for VoIP application. DT01 has built-in Asterisk software and have a FXS port to connect normal phone. DT01 has a friendly Web UI, user can configure the DT01 to work as a VoIP ATA or PBX through the web browser easily. -
Page 4: Operation Temperature
Optional external antenna for long distance connection Support USB dongle for 3G/4G dial up Support USB flash for extend storage Operation Temperature Operation Temperature: -25 ~ 65 Storage Temperature: -40 ~ 85 DT01 WiFi/3G VoIP PBX / ATA User Manual 4 / 23... -
Page 5: Access Dt01
Access DT01 Overview DT01 has two separate RJ45 ports and a WiFi Interface. They have different IP addresses, user can use either of them to access the DT01 and configure it via Web or SSH. Find the ip addresses... -
Page 6: Configure Method
Configure Method The DT01 runs Open Source Linux system. If user has a PC at the same network as DT01, user can access its system via either Web Interface Secure Shell (SSH). 2.3.1 Access via browser The recommended browsers to configure DT01 are Firefox and Chrome. -
Page 7: Typical Network Setup
Typical Network Setup User can configure DT01 to meet different network requirement. This chapter lists some typical network setup. Device are not limited to the network set up shows below, user can configure more advance network modes via the OpenWrt Linux system. -
Page 8: Connect Internet Via Wifi Client Mode
Way to Get IP: DHCP Input correct SSID, Password and Encryption. LAN and DHCP Enable DHCP server in its LAN port Access Point Disable WiFi AP Mesh Network Disable WiFi Mesh Network DT01 WiFi/3G VoIP PBX / ATA User Manual 8 / 23... -
Page 9: Connect Internet Via Usb Dongle, 3G/4G/Gprs
Enable DHCP server in its LAN port Access Point(optional) Enable WiFi AP Input SSID/ Encryption/ Passphrase Mesh Network Disable WiFi Mesh Network Below are USB 3G modem set up example: DT01 WiFi/3G VoIP PBX / ATA User Manual 9 / 23... - Page 10 Service 3G WCDMA Provider: China Unicom Service: 3G EV-DO Provider: China Telecom DT01 WiFi/3G VoIP PBX / ATA User Manual 10 / 23...
-
Page 11: Set Up Wifi Mesh Network
Access Internet via WAN port or USB Modem LAN and DHCP Enable DHCP server in its LAN port Access Point Enable WiFi AP Mesh Network Enable WiFi Mesh Network Mesh Mode: SERVER DT01 WiFi/3G VoIP PBX / ATA User Manual 11 / 23... -
Page 12: Mesh Client Set Up Via Web Ui
BSSID: 02:CA:FF:EE:BA:BB //Note: (1) BSSID should start with 02:; (2) Mesh Device with different BSSID can’t communicate with each other. Note: Mesh set up need to reboot to take effect. DT01 WiFi/3G VoIP PBX / ATA User Manual 12 / 23... -
Page 13: Voip Settings
User can configure the VoIP settings in the Web UI or configure Asterisk advance settings via SSH access to the DT01. Overview This page shows the servers register status. General Settings Define the general info for Asterisk DT01 WiFi/3G VoIP PBX / ATA User Manual 13 / 23... -
Page 14: Voip Server Settings
VoIP Server Settings This page defines how DT01 connect to VoIP services. Configure each SIP/IAX2 service entry. DT01 WiFi/3G VoIP PBX / ATA User Manual 14 / 23... -
Page 15: Voip Clients
VoIP Clients DT01 can act as a SIP/IAX2 server. This page defines the clients’ info. Client Entry: DT01 WiFi/3G VoIP PBX / ATA User Manual 15 / 23... -
Page 16: Dial Plan
- any digit from 0-9 - any digit from 1-9 - any digit from 2-9 [12679] - any digit in the brakets (in the example: 1,2,6,7,9) - (dot) wildcard, matches everything remaining DT01 WiFi/3G VoIP PBX / ATA User Manual 16 / 23... - Page 17 Add prefix or suffix to the real outgoing number. ¾ Use trunk Select the VoIP service provider to send the outgoing call. ¾ VoIP Protocol The dial out voip protocol , SIP or IAX2. DT01 WiFi/3G VoIP PBX / ATA User Manual 17 / 23...
-
Page 18: Voip Set Up Example
VoIP Set up example: Configure as SIP ATA This is the most normal configuration for DT01, the structure is as below: Below is the configure example for Voipbuster service: Step 1: Input Service Provider info Step 2: Configure Dial Plan After above configure, user will be able to use the normal phone to dial out via VoIP Buster. -
Page 19: Configure As Sip Server
Configure as SIP server In this application, DT01 connect to SIP provider like section 5.1. Besides that, DT01 also acts as a SIP server. So softphones or IP phones can register to DT01 and make outbound calls via DT01’s trunks. -
Page 20: Link Two Dt01S Via Iax2 Protocol
Link two DT01s via IAX2 protocol. Two DT01 can link to each other so extension behind them looks like in the same office and calls between all extensions are free. Set up example: Step 1: ¾ Create a softphone client 8003 in DT01 #1, ¾... -
Page 21: Upgrade Firmware
Upgrade Firmware User can upgrade the firmware of DT01 for new features or bugs fix. Below are the method to upgrade via Web UI, there are more other upgrade methods can refer: Upgrade DT01 firmware Upgrade via Web UI: Web UI Æ... -
Page 22: How To Get Long Distance Wifi Range
The DT01 are equipped with chip antenna by default this antenna is mainly for indoor use and have a range 20~50 meters depends on the real environment. It is possible to change the DT01 to use a high gain (15dB etc) external antenna to reach a long distance range in WiFi. -
Page 23: Reference
Remark ： 3G or 4G dongle is not in the device package， only the USB port of the device can connect this kind dongle The distance between user and products should be no less than 20cm DT01 WiFi/3G VoIP PBX / ATA User Manual 23 / 23...
