Biocare EverHeart EH-01 User Manual

Respiratory humidifier

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

M o d e l : E H - 01

Respiratory Humidifier

U s e r M a n u a l

Table of Contents

Need help?

Do you have a question about the EverHeart EH-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Biocare EverHeart EH-01

Page 1 M o d e l : E H - 01 Respiratory Humidifier U s e r M a n u a l...
Page 2 Introduction 1.1 Application and Description 1.2 De nitions Product speci cations General Information Explanation of controls and indicators Assembling Operation 6.1 Basic Step Daily Checking Product Performance Routine Maintenance Service Procedure...
Page 3: 1.1 Application And Description
Application and Description 1.1 Application and Description The everHeart Respiratory Humidi er is designed to warm and add humidity to gases delivered to patients requiring mechanical ventilation or other positive pressure breathing system where the gas ow remains at a constant level. 1.2 Intended Use Disposable heated humidi cation chamber is intended for use to hold water required to humidify the air being delivered to patients.
Page 4: De Nitions
1.2 De nitions - Symbol Symbol Explanation Symbol Explanation Type B Caution Manufacture Date Protective Earth Caution : 　　　　　　　　　　 Consult instructions for use Hot surface may exceed 74℃ 　　～ Alternating current　　　　　　　　　　 Caution : Electrostatic sensitive device Caution: Electrical Shock Hazard. Refer to quali ed service personnel.
Page 5: Product Speci Cations
Product speci cation Model EH-01 Product Speci cation 155mm(H)*140mm(D)*110mm(W) (w/o chamber) Weight 1.3kg (w/o chamber tted) 1.6kg (w/ chamber tted and lled with water) Electrical Rating Frequency：47~63Hz Voltage：AC100 ~240V~/1.8A max./ 60W Fuse ”T24M105ASR2” Overheating protection The machine cuts o its power when temperature over 105℃ Heater Control Adjustable 1~9 level Setting Range...
Page 6: General Information
2. All serving, calibration and/or repairs being carried out by service personnel authorized to do so by the manufacture. Use only parts supplied or approval by BioCARE. 3. Compliance with the local electrical installation regulations. 4. Maintenance of grounding integrity by connection to a hospital grade receptacle. Always disconnect supply before servicing.
Page 7: Explanation Of Controls And Indicators
Explanation of controls and indicators Front panel 【Display window】 : Display the current setting temperature level. 】Unlock key : Continue press for 3 seconds to unlock the system. Then it is able to 【 adjust the setting temperature level. 【＋】Temperature rising key : Press one time to higher setting temperature level. 【－】Temperature decreasing key : Press one time to lower setting temperature level.
Page 8: Assembling
Assembling 1. Assembling the humidi er on the rod or ventilator.(pic 1) 2. Place the chamber on the heating plate then push the chamber all the way into the slot. The chamber protection rod will raise to x the chamber.(pic 2) 3.
Page 9: Operation
● Make sure that gas delivers to the patient is continuously monitored and checked periodically. ● Electric shock hazard - do not remove cover. In case of failure, refer to BioCARE's quali ed service technician. ● This device may not be able to function appropriately, or provide su cient humidity,...
Page 10: Daily Checking
Daily Checking ● Check the power cable for damage and replace as necessary. ● Ensure the heater plate surface is clean and free from pitting, gouging etc. The heater base may be cleaned by using dry damp cloth. Product Performance The following data are based on factory test.
Page 11: Routine Maintenance
Routine Maintenance 9.1 Maintenance note Keep the humidi er in good working condition. It is important to perform maintenance in regular maintenance. Ensure the heater plate surface is clean and free from pitting, gouging etc. The heater base may be cleaned by using dry damp cloth. 9.2 Cancel ●...
Page 12 Service Procedure 10.1 Service Procedure Caution ● Be sure to disconnect the everHeart humidi er from the power supply before servicing. ● All servicing procedure should be followed by an electrical safety test to ensure proper operation. ● Where screws and bolts have been removed from the product, do not use excessive force when re-fastening.
