- Page 1 SHERLINE Lathe Operating Instructions (Reprinted from the Sherline Assembly and Instruction Guide, Fourth Edition (1997) CAUTION! Read all operating instructions carefully before attempting any machining operations! Review Safety Rules for Power Tools before beginning. Lathe Operating Instructions...
- Page 2 FIGURE 1--Parts of a Sherline lathe (Note: Tailstock locking screw is now relocated to a vertical position on the newer tailstocks. This drawing shows an older style tailstock without gib or cutout front face.) Leveling the Cutting tool Each type of turning work requires the correct tool for the job. It is important that the cutting tool is sharp and correctly set up in the tool post.
- Page 3 Our optional rocker tool post (P/N 3057) allows this adjustment to be made without shims. It comes standard with the Model 4400/4410 long bed lathe. Initial Test Cutting If you have never operated a lathe before, we suggest that you make a trial cut on a scrap of material to learn the operation of the machine.
- Page 4 speed to about 200 RPM and feed the tool into the work with more force. The chatter should disappear. Once you have learned to control chatter by adjusting speed and feed, you will be on your way to becoming a machinist. Holding the Workpiece Work can be held between centers, in three- or four-jaw chucks, on the faceplate or with a collet.
-
Page 5: Turning Between Centers
FIGURE 4—Holding a square work piece in a 4-jaw chuck. . Turning Between Centers This is done by fitting the dog to the work that is to be turned and placing the work and dog between the centers in the headstock and tailstock. The maximum diameter that can be held with the dog is 5/8"... - Page 6 withdrawn, cleared of chips and oiled several times during the drilling of a hole to keep the tip from breaking off. FIGURE 6—Center drilling. The work turns while the drill is stationary. chart of commonly available center drill sizes. FIGURE 7--Center drilling a long work piece held in a steady rest. Tailstock Drilling...
- Page 7 Hold the work in a 3- or 4-jaw chuck. If the work is longer than approximately 3" (76mm), support the free end with a steady rest. Fit the drill chuck to the tailstock with a No. 0 Morse arbor and secure a center drill in the chuck. Adjust the tailstock to bring the center drill close to the work and lock in position.
-
Page 8: Faceplate Turning
requiring accuracy within .0005" (.013mm). Reamers are available in any standard size but are rather expensive and are generally not purchased to do one-of-a-kind type work. Use them only when a boring tool cannot be used because of the depth of the hole. Because of their length, they cannot always be used on a small lathe. - Page 9 FIGURE 9--Turning a taper with the Headstock rotated. Short work can be inserted in a 3- or 4-jaw chuck and turned as shown in Figure 9. If the headstock is angled towards the lathe front, the taper will cut smaller at the right. Tapers can also be bored in work held in the 3- or 4- jaw chuck.
- Page 10 The shaping of cutting tools to suitable angles for the type of material and nature of work being performed can be very important to satisfactory work. When tools become dull, gently re-grind and preserve the original angles and shapes. Do not grind the top face of the tools, but confine sharpening to the end and/or sides except form tools which are ground on the top surface.
- Page 11 work piece. The Sherline parting tool instead uses a thin .040" (1mm) blade which has a slightly thicker ridge at the top to accomplish the same job of providing clearance for the tool while cutting. Parting tools thicker than .040" (1mm) will be too thick for use on your Sherline lathe. Boring Tool—Used in the tool post on a lathe or in an offsettable boring head on a mill to enlarge holes in a work piece.
- Page 12 work. Insufficient clearance will cause the tool to "rub" and excessive clearance will produce a ridged or wavy finish due to the small length of tool edge in contact with the work. This ridging becomes more pronounced with rapid feed. To provide a smooth finish, the sharp cutting point may be slightly rounded with an oilstone, taking care to preserve the side clearance underneath this corner.
- Page 13 After completing a part in the lathe it is frequently necessary to separate the part from the excess material used for chucking. This operation is best accomplished with the use of a cutoff tool or "parting tool" as it is sometimes called. The Sherline cutoff tool and holder (P/N 3002) utilizes a very slender, high speed tool steel cutting blade mounted in a special tool holder.
- Page 14 If the tool chatters, first check to see if the work is being held properly. Then decrease speed (RPM) or increase feed rate or both. Once the blade has chattered, it leaves a serrated finish that causes more chatter. Sometimes a serrated finish can be eliminated by stopping the spindle, adding a liberal amount of cutting oil, bringing the blade up so there is a slight pressure on it without the spindle turning, and then turning by hand or as slowly as possible with the speed control.
- Page 15 used to indicate the correct depth at which to stop the feed. Notice that with boring, the depth of cut is increased by moving the tool and crosslide towards the operator and not away as with normal turning. The boring of holes often necessitates greater than normal overhang of the tool from the tool post, so the depth of cut and rate of feed should be reduced from normal.
- Page 16 FIGURE 18—3/8" Negative rake insert tool holder (P/N 7610). Another tool available to Sherline machinists which holds carbide inserts is the 3/8" IC 55° negative rake insert tool holder (P/N 7610). The indexable carbide insert sits on the tool holder at a 5°...
- Page 17 FIGURE 20—The Sherline W.R. Smith T-Rest T-Rest (P/N 2110) and Gravers Another method of removing metal is with a hand held cutting tool called a "graver". It is rested on and moved along a repositionable rest called a T-Rest. It is traditionally associated with clock and watch makers using jeweler's lathes, but can be a useful skill to anyone turning small, custom parts because of its freehand versatility.
-
Page 18: Turning Speeds
and this creates high tool loads. Using two knurls opposing each other equalizes these loads allowing successful knurling on a small machine. A number of patterns can be achieved by changing the knurls. A 25 thread per inch medium diamond pattern set comes with the tool. A number of additional straight and spiral knurls can be ordered. - Page 19 Your lathe can be made more versatile with the addition of suitable attachments and accessories. These include various chucks and collets, a thread cutting attachment, vertical milling column, knurling tool, a live center and many others. Remember that accessories and attachments must be cared for in the same way as the lathe.
- Page 21 Part Numbers and Descriptions, SHERLINE Lathes and Mills KEY TO MATERIALS: A=Aluminum, B=Brass, C=Composite, DC=Die Cast, P=Plastic, U=Urethane, S=Steel (Updated 10/24/01) PART NO. DESCRIPTION MATERIAL 11950 1/4" HSS cutting tool (RH) 11980 Rocker Tool Post Body 11990 Rocker Tool Post Rocker 30220 Toggle Switch Retaining Ring 30230...
- Page 22 40221 (41221) Tailstock Feed Screw body only, Inch (Metric) 40220 (41220) Feed Screw, Inch (Metric) 40230 Headstock Spindle 40240 Headstock Pivot Pin, Lathe 40250 Tool Post Tee Nut 40260 Head Key 40270 (41270) Tailstock Spindle, Inch (Metric) 40280 Thrust Collar 40290 Leadscrew end 40300...
- Page 23 40660 3/16" I.D. Washer 40670 10-32 x 1/2" Skt. Hd. Cap Screw 40690 10-32 x 3/4" Skt. Hd. Cap Scrw 40760 10-32 x 5/8" Thumbscrew 40820 Gib Lock 40860 Tailstock Locking Screw Grommet 40870 Tailstock Spindle Locking Screw 40890 (41890) Slide Screw Insert, Inch (Metric) 40900 10-32 x 3/8"...
- Page 24 45010 (45160) Leadscrew, Z Axis, Inch (Metric) 45040 Saddle, Z Axis 45170 Column Saddle Lock 45180 3/16" Ball Bearing 45190 #10 Type B Washer 45450=DC Motor with externally replaceable brushes (Leeson) 45460=DC Motor with externally replaceable brushes (Hill 45450 House) (NOTE: We purchase motors from two different manufacturers Motor 45460...
