Void RESONATOR Owner's Manual

Parametric eq
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
RESONATOR
PARAMETRIC EQ
acoustics

Advertisement

loading
Need help?

Need help?

Do you have a question about the RESONATOR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Void RESONATOR

  • Page 1 OWNER'S MANUAL RESONATOR PARAMETRIC EQ acoustics...
  • Page 2 OWNER'S MANUAL RESONATOR PARAMETRIC EQ Technical and design specifications are subject to change without notice...
  • Page 3 Processor Series acoustics TO PREVENT ELECTRIC SHOCK, DO NOT Shock Hazard - Do Not Enter REMOVE TOP OR BOTTOM COVERS. Choc Hasard - N*entrent NO USER SERVICEABLE PARTS INSIDE. Schocke Hazard - Test Nicht REFER SERVICING TO QUALIFIED Betrete SERVICE PERSONNEL. DISCONNECT Urto Hazard - Do Non Entrano POWER CORD BEFORE REMOVING REAR PANEL COVER TO ACCESS GAIN...
  • Page 4 2. The XLRs are set for +4dBu the TRS jacks for -10dBV operating levels. Use the appropriate connector/level to interface between your equipment and the Resonator. 3. Using the TRS jack input with +4dB signal levels in some set-ups may over drive the Resonator and cause distortion.

  • Page 5: Front Panel

    Processor Series acoustics Front Panel 1.Power LED Shows if the unit is on or off. 2.Band Gain Control To control the level of the selected frequency. 3.Band Q Control To control the width of the selected frequency. 4.Band Frequency Control To select the frequency to be adjusted.
  • Page 6 Processor Series acoustics Rear Panel 1.Balanced Input XLR's +4dBu. Wired pin 1 ground, pin 2 +ve and pin 3 - ve. 2.Balanced Input Jacks -10dBu. Wired sleeve ground, ring signal - and tip signal + 3.Balanced Output XLR's +4dBu. Wired pin 1 ground, pin 2 +ve and pin 3 - ve 4.Balanced Output Jacks -10dBu.
  • Page 7 Processor Series acoustics Operation CHANNEL 1 LF gain control This control sets the amount of cut or boost for the LF (Low Frequency) section. The gain range in +15db and -15dB. LF Q control Varies the 'Q' (bandwidth) of the cut or boost region. A low Q, CW (clock wise) affects a wide band of frequencies whilst a high Q, CCW affects a very small band.
  • Page 8 MONO LED Pressing the MODE switch on the rear of the Resonator lights the MONO led. This puts the two EQ channels in series to form a single mono 6 band unit. In this mode the BYPASS and 30Hz filter switches on Channel 2 are disabled.

  • Page 9: Warranty Registration

    They will handle the necessary paperwork and repair. Remember to transport your unit in the original factory packaging. 1. When sending a Resonator to an authorised service centre for service, please write a detailed description of the fault and list any other equipment used in conjunction with the faulty product.

  • Page 10: Limited Warranty

    Owner shall then have the option to elect either a refund or replacement of said Void product free of charge. The refund shall be an amount equal to but not greater than the actual purchase price, not including any taxes, interest, insurance, closing costs and other finance charges (minus reasonable depreciation on the product).
  • Page 12 Void Acoustics Unit 10B Dawkins Road Ind Est Poole Dorset BH15 4JD...
