Summary of Contents for XTBA F451
- Page 1 Software 1.3 R83 or later Unit 2 The Old Curatage The Street Caston NR17 1DD 44 (0) 208 882 0100 email dmx@xtba.co.uk www.xtba.co.uk XTBA F451 DMX Fire FX unit Page 1 of 6 Product #10502 - March 2015 © XTBA 1986 – 2015...
- Page 2 Introduction The XTBA F451 DMX fire effect unit is designed as a stand-alone DMX unit or can also be used in conjunction with an existing DMX control system either in merge or replace mode. The F451 generates two hundred thousand random levels every second to provide ‘randomness’...
- Page 3 SET FOR REPLACE / MERGE STORE SETTINGS RECALL SETTINGS RESET TO DEFAULTS PROPORTIONAL or HARD LIMIT On first entry the display will show if the F451 is in merge or replace. (Replace is the unit’s default). Pressing the UP button will toggle the selection.
- Page 4 If set to replace any incoming DMX levels are ignored within the start address and block length and only the F451 flicker levels are transmitted in that DMX space. STORE SETTINGS The F451 retains all the settings on power down but in addition the unit has eight memories. S T O R E...
- Page 5 RECEIVING LEVELS If the random output is set to OFF and the unit set for merge the F451 can be used as a DMX level receiver to find out if incoming DMX channels are working. XTBA F451 DMX Fire FX unit...
- Page 6 Using the product out of these specifications will remove all responsibility from the supplier. CE Declaration of conformity XTBA declares that the following equipment meets the requirements of the EMC Directive 89/366/EEC. WEE/FC2753ZS Unit 2 The Old Curatage The Street Caston NR17 1DD 44 (0) 208 882 0100...
