DCS1
WARNING
Patent Pending
Please Recycle
the Document Camera Stand
Assembly Guide
DCS1_2014_D
Check out our other products online at
www.copernicused.com
This product is meant to be assembled by an adult.
In its unassembled state, small parts present a hazard.
To be used under direct supervision of an adult.
DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Assembly Guide
For assistance, please contact us:
1-800-267-8494
Email info@copernicused.com
Have your packing slip ready for reference
Check out some of our
other great products!
www.copernicused.com
Need Tech Support?
Have a Question?
Email our Tech Support Service
iPad® not included.
Document Camera Function
only works with iPad 2™ & Newer.
iPad mini™ NOT Supported.
1
Advertisement
Related Manuals for Dewey DCS1
Summary of Contents for Dewey DCS1
- Page 1 Have a Question? Patent Pending Email our Tech Support Service iPad® not included. Document Camera Function only works with iPad 2™ & Newer. iPad mini™ NOT Supported. Please Recycle DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 2 Do not install or use the electrical components of this unit during a lightening storm. Electrical Shock Do not climb on, hang from or suspend objects from any components of your product unless otherwise specified. Climb Hazard DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
-
Page 3: Before You Begin
To validate your warranty submit the ON-LINE form at www.copernicused.com Frame Warranty “The beautiful thing about learning is that no one can take it away from you.” - B. B. King DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc. - Page 4 This product should be assembled by an adult. Top Arm Pre-Assembly (1) Inner Tube Pre-Assembly (1) Outer Tube (1) Base (1) DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 5 M6 Lock Washer Allen Key (Not to Scale) Base VGA Strap Bag of extra hardware Additional Items Needed Not Included Apple® VGA iPad 2™ or Cable Adapter Newer DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 6 You will need: (Not to Scale) Inner Tube Pre-Assembly Place the Inner Tube inside the Outer Tube Pay close attention to the orientation of the Valco Double-End Snap Buttons. DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 7 (Not to Scale) Top Arm Pre-Assembly Assemble the Top Arm To easily assemble the Top Arm, adjust the height to the lowest position then assemble the pieces together. DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 8 & bolt with 10mm wrench and the provided allen Inserting iPad® The green piece slides in and out to secure iPad® DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 9 To hold the VGA cable in place use provided VGA strap. Tie the strap around the adapter cable and then loop over the edge of the top mechanism. DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 10 NOTE: If the screen of your iPad® turns off while in use, adjust sleep mode time by going to Setting>General>Auto- Lock. And when you are not using your device put it into sleep mode. DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 11 By rotating the top mechanism 90 degrees, change between landscape By tilting down the top mechanism, switch between document and portrait projection. camera and stand position. DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
- Page 12 Thank you for purchasing one of our products. I hope the assembly of your Dewey - the Document Camera Stand went well. If you have any questions, or concerns, or ideas for how we can improve, please call us at 1-800-267-8494, where someone will be happy to help.
