USER MANUAL
MNPG148 Rev. 2 02/07/15
Electrotherapy model
MIO-CARE PRO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIO-CARE PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for I-Tech MIO-CARE PRO

  • Page 1 USER MANUAL MNPG148 Rev. 2 02/07/15 Electrotherapy model MIO-CARE PRO...
  • Page 2 IACER S.r.l. 2 of 36 MNPG148 Rev. 02 02/07/15...
  • Page 3 Summary Summary Technical Specifications Manufacturer Declaration of Conformity Specifications Purpose Technical features Labels detail Symbols description Kit contents How to use Warnings Electromagnetic interference Contraindications How to use TENS Programs Programs Technical Specifications Maintenance Battery charging Battery replacement Cleaning Carriage and storage Disposal Troubleshooting Assistance...

  • Page 4: Technical Specifications

    5 September 2007 (D. Lgs. 37/2010 dated 25 January 2010). Notified body: Cermet, Via di Cadriano 23 – 40057 Cadriano di Granarolo (BO) Italy. MIO-CARE PRO is a Class IIa equipment, with reference to Directive 93/42/EEC (MDD), annex IX rule 9 (and following modifications).

  • Page 5: Purpose

    Purpose Clinical purpose: Therapeutic Use: Clinic/Hospital and domestic use MIO-CARE PRO is indicated for the treatment and the functional rehabilitation of the following pathologies and anatomical zones:  wrist articulation  hand articulation  shoulder articulation  foot articulation ...
  • Page 6 Labels CH1 output CH2 output Battery charger connector Display Increase intensity CH1 Decrease intensity CH1 Mode operation button Increase intensity CH2 Decrease intensity CH2 (10) Increase program (11) Decrease program (12) ON/OFF and OK button (13) Set programs and therapy pause button (14) Belt clip (15) Battery compartment IACER S.r.l.

  • Page 7: Labels Detail

    Mode operation (NEMS, TENS, BEAUTY, MEM) Wave frequency Wave impulse width Program number CH1 intensity CH2 intensity Battery status Therapy time Contraction time (10) Recovery time (11) Up/down slope Labels detail IACER S.r.l. 7 of 36 MNPG148 Rev. 02 02/07/15...

  • Page 8: Symbols Description

    Check the device and its accessories before use. Avoid the use in case of damage to the case or to the accessories (damaged cables): contact the manufacturer as mentioned in “Assistance” paragraph;  Avoid the use of MIO-CARE PRO to people not educated through the reading of the manual;  Avoid the use of MIO-CARE PRO in damp environments;...

  • Page 9: Electromagnetic Interference

    If this occurs, suspend the evening treatment. How to use MIO-CARE PRO is a portable and battery-powered device that generates TENS and NEMS currents. It is particularly indicated for daily treatments of the most commons muscle diseases. MIO-CARE PRO is provided with two independent and adjustable intensity channels.

  • Page 10: Tens

    MIO-CARE PRO recognize the electrodes connection: in case of faulty connection, when the intensity reaches 10 mA the value is resetted to zero. The remaining time is showed on the display of MIO-CARE PRO. An acoustic signal advises the user when the treatment is completed.

  • Page 11: Programs

    Programs TENS BEAUTY NEMS Firming up – Conventional Tens upper limbs Warming up Free TENS 1 (fast) and trunk Resistance – Endorphinic Tens Firming up – upper limbs and Free TENS 2 (delayed) lower limbs trunk Toning up – Tens at maximum Resistance –...

  • Page 12: Programs Technical Specifications

    Sequential phasic contractions – upper limbs and trunk Sequential phasic contractions – lower limbs Muscle relaxant Deep massage Programs Technical Specifications TENS programs Prg. PHASE 1 PHASE 2 PHASE 3 Total time 40 min frequency 90 Hz impulse width 50s Total time 30 min frequency 1 Hz impulse width 200s...
  • Page 13 Total time 20 min Total time 10 min Total time 10 min frequency 90 Hz frequency 70 Hz frequency 50 Hz impulse width 50s impulse width 60s impulse width 90s Total time 20 min Total time 20 min frequency 90 Hz frequency 70 Hz impulse width 50s impulse width 60s...
  • Page 14 stimulation is not recommended for particularly sensitive people and in any case the electrodes should not be positioned in sensitive areas such as the face and genitals or close to wounds. Position of electrodes: form a square above the painful area as shown in illustration 1. TENS 4 •...
  • Page 15 TENS 9 • Muscle relaxant Program used to speed up the recovery of muscle function after intense training or strain from work; the effect is immediate. Adjust the intensity for moderate muscle solicitation. Two treatments per day for three or four days. Program duration: 30 minutes. Position of electrodes: from photo 1 to 28. TENS 10 •...
  • Page 16 Program duration 41 minutes, intensity set above the threshold of perception with small muscle contractions at the end of the program (10 minutes before the end). ARTHROSIS Arthrosis is a chronic-degenerative medical condition, appearing insidiously, developing over time and causing progressive degeneration of the joints (a joint is formed of two or more joint "heads", cartilage, ligaments, a synovial membrane, a joint capsule, tendons and muscles), limiting joint motility increasingly over time.
  • Page 17 Important: for all of these programs, stimulation intensity must be set between the threshold of impulse perception and the moment in which the impulse starts to cause discomfort. With the exception of the “periarthritis” program, the muscles surrounding the area to be treated must not contract, they should only produce slight “vibrations”.
  • Page 18 Total time 20 min: Total time 4 min Total time 5 min (5Hz-250s x 8 sec ch1/ch2 frequenza 6 Hz frequenza 3 Hz 80% + 40Hz-250s x 6 sec ch1 80%+ 40Hz-250s x 6 impulse width 250s impulse width 250s (80%) sec ch2 80%) x 60 cycles Total time 20 min: Total time 4 min...
  • Page 19  during the program and over the next few days the intensity should be increased gradually so that muscle contractions are not painful;  during contraction generated by the unit, contract the muscle voluntarily;  a cycle of 15/20 applications must be completed before the first results can be seen; one application for each muscle every two days with a day of rest in between.
  • Page 20 BEAUTY 7 • Modelling. Due to a combination of capillarizing and toning impulses, this program helps mobilise fat in areas where it tends to accumulate. The electrodes should be positioned to form a square around the area to be treated and can be applied daily using a medium intensity. Program duration: 14 minutes.
  • Page 21 local microcirculation. Program duration: 30 minutes. Recommended stimulation intensity: medium. Position of electrodes: see photos 01 to 20 in the manual of positions. BEAUTY 15 • Heaviness in legs This program is used to improve blood flow and muscle oxygenation speeding up the elimination of lactic acid (produced after anaerobic sessions for muscle definition), reducing soreness and the risk of contractures.
  • Page 22 NEMS programs Total time 10 min (5Hz- Total time 3 min Total time 3 min 250s x 7sec 80%+ 1Hz Frequency 6 Hz Frequency 8 Hz 250s x 3 sec 100% + 30Hz-250s x 5 sec 80%) impulse width 250s impulse width 250s x 40 cycles Total time 15 min (3Hz-...
  • Page 23 cycles x 40 cycles Total time 10 min (3Hz- Total time 10 min (3Hz- Total time 4 min 200s x 12sec 90%+ 1Hz 200s x 12sec 90%+ 1Hz Frequency 6 Hz 200s x 3 sec 100% + 200s x 3 sec 100% + 100Hz-200s x 5 sec 80%) x 120Hz-200s x 5 sec 80%) impulse width 200s...
  • Page 24 250s x 5 sec 80%) x 40 impulse width 250s (90%) impulse width 250s cycles Total time 5 min Total time 10 min (3Hz- Total time 10 min (2Hz- 250s x 2 sec ch1 100% + 250s x 2 sec ch1 100% + Frequency 3 Hz 3Hz-250s x 2 sec ch2 2Hz-250s x 2 sec ch2...
  • Page 25 NEMS 8/9 • Fast strength - upper limbs and trunk (8), lower limbs (9). This program is designed to increase speed in fast athletes and develop it in athletes lacking the quality. Program duration: 24 minutes. The exercise assumes a fast pace and the contraction is short, as is the recovery. It is usually best to complete a three-week basic strength cycle of increasing intensity before using this program.
  • Page 26 improve blood and lymphatic circulation in the lower limbs (e.g. applying CH1 to the right calf, CH2 to the right thigh). Program duration: 18 minutes. These programs can be carried out using self-adhesive electrodes. Stimulation intensity must be sufficient to produce good muscle contractions during the treatment but not enough to cause any soreness.
  • Page 27 Treatment programs for muscle strength. Weekly training program No. of Muscle Photo weeks Day 1 Day 3 Day 5 Day 7 Abdominal muscles - No. 1/20 Fitness6 F19+F6 basic strength Pectoral muscles - No. 7/17 F19+F6 basic strength Quadriceps – No.

  • Page 28: Maintenance

    M1-M5 • TENS Free memories Free memories for antalgic TENS treatment. M6-M10 • NEMS Free memories Free memories for muscle recovery and training. M11-M12 • NEMS Alternated free memories Free memories for muscle recovery and/or training with alternated impulses on channel 1 and 2. M13 •...

  • Page 29: Cleaning

    Troubleshooting If it is used in accordance with the instructions of the user manual, MIO-CARE PRO does not need a particular regular maintenance. If you find any malfunctioning using MIO-CARE PRO, please follow these instructions: ...

  • Page 30: Assistance

    Warranty Make reference to the national laws for any warranty conditions by contacting the national distributor (or directly the manufacturer IACER). MIO-CARE PRO. All rights reserved. MIO-CARE PRO and logos are owned by I.A.C.E.R Srl and are registered. IACER S.r.l.

  • Page 31: Emc Tables

    EMC Tables Electromagnetic emission Emission test Compliance Electromagnetic environment – guidance RF emissions Group 1 The device uses RF energy only for its Cispr 11 internal function. Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic equipment RF emissions Class B...
  • Page 32 Guidance and manufacturer’s declaration – electromagnetic immunity The device is inteded for use in the electromagnetic environment specified below. The customer or the user of the device should assure that is used in suche environment Immunity test Test level EN Compliance level Electromagnetic environment –...
