Notice to Non-CDR Users
If you do not have CDR software installed on your system, your software installation
instructions are revised as follows.
Before performing any of the steps in Section 3 (Software Setup), do the following:
1. Start Windows Explorer and create a new folder on your hard drive called
TempDrivers or some other name that will help you identify this folder as a storage
place for USBCam drivers.
2. Insert the "CDR Video Manager for DirectX" disk, but do not run the Setup program.
When the USBCam Setup Screen is displayed, click Exit.
3. Using Explorer, browse the CD, and open the folder named USBCam Driver and
copy its contents to your TempDrivers folder.
4. Continue with the "USBCam Device Drivers" installation section for your particular
operating system. When you are prompted for the location of the drivers, point the
installation wizard to the TempDrivers folder.
• For Windows 98 Second Edition, continue with Section 3.4.3
• For Windows 2000, continue with Section 3.5.3
• For Windows XP, continue with Section 3.6.3.
5. If you have questions about these instructions or experience any problems during
installation, please refer to the following resources for assistance. In North America,
customers can contact the Patterson Technology Center at 1-877-498-6505. Other
customers please contact the authorized dealer for Schick Technologies products in
your country or region.
