Summary of Contents for EROAD ehubo2
- Page 1 EROAD Ehubo2® Installation Guide...
- Page 2 3. Install the Ehubo2 by connecting it to the vehicle. 4. Complete the installation by following the Ehubo2’s on-screen guide. Refer to “Replacement Installation” on page 12 if you are installing a replacement Ehubo2 © 2016 EROAD. Doc 100200AA1.9. 4/2016.
-
Page 3: Important Safety Information
• Do not damage existing wiring and components when drilling the dashboard. • Avoid fitting the Ehubo2 in a location that could cause injury to a driver or passenger in a crash. This includes potential head strike zones on the windshield or dashboard, or other locations where a deploying airbag may contact the Ehubo2. - Page 4 • Only operate or look at the Ehubo2 when it is safe to do so. Do not message, change settings or access functions while driving. Pull over before you wish to attempt such activities. Always keep your hands free to operate the vehicle while driving.
-
Page 5: Inside The Box
Inside the box Open your Ehubo2 box and check that everything is inside. EROAD Ehubo® Installation Guide EROAD EROAD Ehubo2 Ehubo2 mount (pre-fitted wiring loom) This installation guide Fuse kit Mounting High–strength adhesive tape (permanent power/ignition) Alcohol wipe plate (optional, for tape mount) 2 x ¾”/ 19mm screws + washers... - Page 6 Choose a location that does not expose the Ehubo2 to excessive temperature or vibration.
- Page 7 The Ehubo2 needs a permanent power source and a good view of the sky to operate optimally. While the vehicle is off, the Ehubo2 will shut down to a low power mode and will draw a very small current from the vehicle supply. Remove the Ehubo2 permanent power fuse if the vehicle is in storage or parked up for more than a month to avoid discharging the vehicle battery.
- Page 8 NOTE: If the screen remains black or if you cannot successfully complete the instructions on the screen, the wiring of the Ehubo2 may not be quite right. Please refer to the Wiring Diagrams in this Installation Guide or to the Troubleshooting section and adjust your wiring.
- Page 9 Existing Installs To uninstall an Existing Ehubo1, disconnect the Ehubo1 from the vehicle wiring harness and insert the Ehubo2 connector in its place. Use a cable clamp or heat shrink to secure the connection and hide it beneath the dash.
- Page 10 Note: Ensure exposed to permit wiring is neatly handing unit to routed to under enforcement officer the dash EROAD Dashboard Fuses must be fitted Cable clamp at connection point. or heat shrink This is to protect the wire in case of a short...
- Page 11 Replacement installation To replace an existing Ehubo2, NOTE: Turn off the - disconnect the power cable from the existing Ehubo2 and engine prior to - connect it to the replacement Ehubo2. replacing the Ehubo2 Follow these simple steps: Remove the...
- Page 12 Pull the sticker and screen protection film off the Ehubo2 screen. To complete the installation, follow the instructions on the screen. At the end of the process the Ehubo2 Home screen will appear, and the installation is complete. Please place the uninstalled Ehubo2 in the replacement...
-
Page 13: Troubleshooting
Troubleshooting This section will provide some solutions if the installation of your Ehubo2 is unsuccessful or the Ehubo2 doesn’t perform as expected. SCENARIO SYMPTOM SOLUTION Permanent Power • Ehubo2 screen remains off • Check that Permanent Power is not connected has been properly connected to •... - Page 14 LIBZINT - THE OPEN SOURCE BARCODE LIBRARY THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED LICENSE WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED Copyright (C) 2008 Robin Stuart WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
- Page 15 INNOVATION AND INTEGRITY EROAD.COM...
