Micro Star Computer MS-5607 User Manual

Gps, hands-free, photo viewer and music playback
Hide thumbs

Advertisement

Quick Links

Download this manual
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS-5607 and is the answer not in the manual?

Questions and answers

Summary of Contents for Micro Star Computer MS-5607

  • Page 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2 Important Safety Precaution Always read and follow these basic safety precautions carefully when handling any piece of electronic component. Keep this User Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equipment from overheating.
  • Page 3 Before you begin to install and use this product, please read this manual carefully for fully exploiting the functions of this product. For photos stored in SD card, no need to search for another storage device, just insert into MS-5607 for immediate photo sharing. Sharing moments take no time to wait.
  • Page 4 Below is the main menu one user powered on MS-5607. Four categories are available here to you to take full use of this device. Chapter 1 GPS(Global Positioning System) 1.1 How to locate destination Following is suggested demonstration for user locates in Rue Monge in Paris and tries to find a route to Musee du Louvre without knowing the exact address.
  • Page 5 Since assuming not knowing the exact address of Museum of Louvre. Select Points of Interest. Select Browse to see available Points of Interest. There are six general categories, tap More for more options. Select Museum category, and tap OK. Search downwards to locate Musee Du Louvre.
  • Page 6 As Map shows Musee Du Louvre location, tap Go. Map in the right shows route from Rue Monge to Musee Du Louvre as well as more museums in the neighborhood. There you go, allow the GPS lead you to destination. 1.2 Route To know route details, tap icon on...

  • Page 7: Route Overview

    1.2.2 Route Overview This option is to know overall scheduled route. Distance is also indicated in the right. 1.3 Options This section changes display mode and more settings. Option Main Menu in the right. Night Mode 3D Mode...

  • Page 8: Pedestrian Mode

    Free Map Browsing Pedestrian Mode 1.4 Extras More Extra settings available. Tutorial...
  • Page 9 On. 2.1.1 How to pair and connect Bluetooth mobile phone to MS-5607 Make sure both Bluetooth mobile phone and MS-5607 have been paired and connected before user try to dial via MS-5607. Following is the connecting/pairing procedure between Sony Ericsson mobile phone and MS-5607.
  • Page 10 Follow on-screen instructions to search available Handsfree devices. Note: The Bluetooth menu in mobile phone might differ by different brands and models. MS-5607 has been found, press Select and enter passcode: 0000. Add to and then Connect to New handsfree.
  • Page 11 This picture shows MS-5607 has been successfully paired and connected to MS-5607. User may make phone calls via MS-5607 now. 2.2 Paired List Only when MS-5607 has been paired would this selection be valid. Shows mobile phone model used for demonstration.
  • Page 12 2.3 Dial Select Dial from Main Menu. Tap the number and tap to make the call. This picture indicates the call has been connected. User can adjust Volume in the right. Or hang up the phone by tapping to end. 2.4 Last Calls Select Last Calls to learn the number just dialed or answered.
  • Page 13 2.4.1 Dialed Number Show the Dialed Number tab, user can tap icons in the right to call again or to delete call lists. 2.4.2 Answered Calls Select Dialed Number tab to learn calls answered. 2.4.3 Missed Calls Select Missed Calls tab to learn calls missed.
  • Page 14 2.4.5 Delete Call From Last Call Tabs Choose the number user intend to delete, just tap icon. A transparent window Finished shall show to remind user above process has been made. 2.5 Auto Answer Set On to auto answer incoming calls, tap again to set to Off.
  • Page 15 Chapter 3: Travel Kit Select Travel Kit from Main Menu. 3.1 Music Select Music. User may tap Play All to listen all music available or tap desired song as listed in the right. You may tap on the screen while playing, relative information such as name of the song, the artist and the album shall list accordingly.
  • Page 16 Picture in the right indicates under repeating mode. 3.2 Photo Select Photo. Choose first photo for instance. Enlarge view for this photo. Only Previous and Next options are available here. Tap again to find the selection icon in the bottom of the right side.
  • Page 17 Tap the selection icon to bring up more selections. Selections from Left to right are Slide show interval, rotate, zoom in/out, mute, broadcast.
  • Page 18 Chapter 4: Settings Tap on Settings in the main menu to proceed. 4.1 Volume Tap Volume to adjust volume of this device. Users may adjust either to increase volume or to decrease volume at by tapping icons below. If quiet operation is needed, tap mute icon in the right.

  • Page 19: Audio Output

    Users might like to select Auto or Manual at their preference. Select Auto, the screen will pop Locked message when user left the device unused for a while. In this case, tapping Unlock icon to release. A confirm message, tap to unlock or to remain locked screen.
  • Page 20 4.3.2 FM Transmitter Transmitter enter Transmitter setting. User may adjust frequency by and save as one of your favorite channels. User can select various frequencies among save up to four of your 88.5~107.5 MHz to most frequent used channels as listed in the right.
  • Page 21 4.4.1 Brightness Users can adjust screen brightness either by tapping icons below to plus or minus screen brightness at Brightness tab. 4.4.2 Backlight Timeout Users can adjust Backlight Timeout at this tab for power saving purposes. 4.4.3 Screen Stylus Users can calibrate precision of this device at Screen Calibration tab.
  • Page 22 4.5 Language Select display Language here. There are ten languages available. 4.6 Date & Time Select Date & Time to set local date and time. 4.6.1 Date Set date in Year/Month/Day format. adjusting icons in the right.
  • Page 23 4.6.2 Time Set time in Hour: Minute. Moreover, user could change either in 12-hour format or 24-hour format as user’s preference.
  • Page 24 4.7 Power Status Tap Power Status to learn current power status. From left to right indicates short to full battery status. 4.8 Restore Tap Restore to restore all defaults. A window as in the right shall pop up to confirm restoration. Tap to confirm to cancel.

  • Page 25: System Info

    4.9 System Info. Select System Info to know more details regarding 4.9.1 Devices Software Version, Firmware Version and RAM capacity under Devices tab shows here. 4.9.2 Storage Tap Storage tab to show capacity of Storage Card, and Flash Disk. 4.9.3 Copyright Tap Copyright tab to know copyright of this product belongs to Micro Star International.

  • Page 26: Firmware Upgrade

    4.10 Firmware Upgrade Tap Firmware Upgrade tab to upgrade Firmware. A window in the right shall pop up to confirm. Tap to confirm or cancel. Screen shall show current status as Upgrading. Then Firmware Upgrade Finished.
