Picocell 1900 Radio Unit Installation
Installation Method – 02-0245
September 3, 1998
Issue Number: 01.02
Information subject to change without notice . This is a DRAFT copy
for review and to provide advance information. Document release
subject to IM verification. Errors, omissions and corrections should be
sent to: lthomp@nortel.com
Pkgid: 0000003
PROPRIETARY INFORMATION: The information contained in this document
is the property of Nortel (Northern Telecom). Except as specifically authorized
in writing, the holder of this document shall keep all information contained
herein confidential and shall protect same in whole or in part from disclosure
and dissemination to third parties.
© Nortel 1998
All Rights Reserved
Advertisement
Table of Contents
Related Manuals for Nortel Picocell 1900
Summary of Contents for Nortel Picocell 1900
- Page 1 Pkgid: 0000003 PROPRIETARY INFORMATION: The information contained in this document is the property of Nortel (Northern Telecom). Except as specifically authorized in writing, the holder of this document shall keep all information contained herein confidential and shall protect same in whole or in part from disclosure and dissemination to third parties.
- Page 3 Picocell 1900 Power Supply Specifications ........28...
- Page 4 Method 02-0245 September 3, 1998 4 / Picocell 1900 Radio Unit Installation...
-
Page 5: September 3, 1998 Method
Figure 3 – PICOCELL 1900 transciever Assembly ....... . 12... - Page 6 Method 02-0245 September 3, 1998 Tables Tools Stock List and Mounting Kits Mounting Hardware 6 / Picocell 1900 Radio Unit Installation...
-
Page 7: General Information
Service Impact : There is no service impact at this time. 1.2 Sequence This method is to be performed after the building cabling has been installed and is ready to recieve the PICOCELL 1900 Transceivers. PICOCELL 1900 Planning Method 04-0242 has been reviewed. 1.3 Reason for Reissue Changes from Project Team Review Sept 1, 1998: •... - Page 8 Radio and CSI Power test IM28-0248 Commission PICOCELL Radio Commisioning with 1900 transcievers the IFR Load CSI and Radio IM28-0247 software and run CSI Equipment Loading diagnostics and Diagnostics IM02-0249 Test Integrated System Microcell System Test 8 / Picocell 1900 Radio Unit Installation...
-
Page 9: Material Requirements
NTMQ50AA Picocell Basestation, 1900MHz B Band NTMQ60AA Picocell Basestation, 1900MHz C Band NTMQ70AA Picocell Basestation, 1900MHz 60MHz Band NTMQ75AA Picocell Basestation, 1900MHz 60MHz Band Table 3 – Mounting Hardware Quantity CPC/PEC Product Description Picocell 1900 Radio Unit Installation / 9... -
Page 10: Customer Supplied Equipment
CSI and MDF Cabling and pair assignment matching PICOCELL 1900 transceivers to cable pair numbers. Building access authorization, security clearance if required and keys for access to restricted CSI and PICOCELL 1900 equipment locations. 10 / Picocell 1900 Radio Unit Installation... -
Page 11: Precautions And Preparations
This method is for indoor installations only. Picocell 1900 transcievers and antennae are for indoor installations only and mounting of some or all; transcievers, antennas, hybrids and cabling in an outside environment may create a potential fire hazard from lightning. - Page 12 Are System T1s facilities ordered (if required) and what is the availability date? Is the antenna system design cabling Interconnect Schematic available? Figure 3 – Transciever Assembly P0880222 Antenna Element P0880211 LED indicators Cover P0880217 Interface Cover P0880218 12 / Picocell 1900 Radio Unit Installation...
-
Page 13: Procedure
Method 02-0245 4.0 Procedure 4.1 Overview Below is a list of procedures required to install the PICOCELL 1900: Procedure 1 - Unpacking and Inventory transciever Material Procedure 2 - Wall Mounting and securing the Radio Mounting Bracket Procedure 3 - Ceiling Mounting and securing the Radio Mounting... -
Page 14: Procedure 1 – Unpacking And Inventory Transciever Material
Hybrid(s) will have to reside close together. Refer to the PICOCELL 1900 Installation Planning Method 04-0242 and Antenna installation 12-0152 for spacing requirements and cable length considerations. 14 / Picocell 1900 Radio Unit Installation... -
Page 15: Procedure 2 – Wall Mounting And Securing The Radio Mounting Bracket
Install the remaining wood screws into Figure 4 the wall mounting bracket. Position the transciever into the bracket and ensure that the locking retainer is locked and correctly positioned . Picocell 1900 Radio Unit Installation / 15... - Page 16 Method 02-0245 September 3, 1998 Figure 4 – PICOCELL Transceiver Bottom view Figure 5 – PICOCELL Wall Mount Wall Studs Wall Stud Wall Mount Backboard Wall Mount Latch Locking 16 / Picocell 1900 Radio Unit Installation...
-
Page 17: Procedure 3 – Ceiling Mounting And Securing The Radio Mounting Bracket
Drill an access hole near the front of the transciever for the facility cable pairs. Lock the transciever into the bracket and complete the wired connections. Picocell 1900 Radio Unit Installation / 17... - Page 18 Figure 6 – Track Ceiling support IDSClips Drop wire Ceiling Panel Ceiling Panel Ceiling support Spacer Track Mouinting Bracket Mouinting Bracket Figure 7 – PICOCELL Transciever Ceiling mount Cross Track IDS Clip Main Ceiling Track Mounting Bracket Spacer Washer 18 / Picocell 1900 Radio Unit Installation...
-
Page 19: Procedure 4 – Installation Of Picocell Transceiver Onto Wall Mounting Bracket
Figure 12. PICOCELL 1900 cabling and commis- sioning can be completed, proceed with Method 12-0152 and 04-0244. Figure 8 – Locking the transciever into the mounting Bracket P08800222 Mounting Bracket Radio unit Locking Retainer Picocell 1900 Radio Unit Installation / 19... -
Page 20: Procedure 5 – Co-Located Ac Power Supply Installation
Plug the power supply into the AC outlet and - 48VDC verify the supply output power. transciever powers up with activity on LEDs Verify the transciever operation in IM 04-0246 Figure 9 – PICOCELL Co-located power supply 20 / Picocell 1900 Radio Unit Installation... -
Page 21: Procedure 6 – Remote Ac Power Supply Installation
AC-DC AC-DC -48VDC -48VDC -48VDC AC-DC AC-DC AC-DC -48VDC -48VDC -48VDC AC-DC AC-DC AC-DC -48VDC -48VDC -48VDC AC-DC AC-DC AC-DC -48VDC -48VDC -48VDC AC-DC AC-DC AC-DC -48VDC -48VDC -48VDC 3.0" AC Power Bars Picocell 1900 Radio Unit Installation / 21... -
Page 22: Power Supply Connections
September 3, 1998 4.2 Power Supply connections The PICOCELL 1900 transciever is powered by an AC to -48VDC supply which is mounted either at the CSI location or near the PICOCELL transceiver mounting position. If it is mounted near the transciever (co-located), an AC outlet must also be within close proximity. -
Page 23: Picocell Transceiver Connections
September 3, 1998 Method 02-0245 4.3 PICOCELL Transceiver Connections Connections to the PICOCELL 1900 transciever consist of bare wire terminations on the PICOCELL 1900 terminal strip which provides terminals for the following: Figure 12 – PICOCELL transciever Connections Terminal Port Radio 2... -
Page 24: References
PICOCELL 1900 transciever Installation 22-0246 PICOCELL 1900 Radio and CSI Power up 24-0247 PICOCELL 1900 Equipment Loading and Diagnostics 28-0248 PICOCELL 1900 Radio Commissioning with the IFR 1900 28-0249 PICOCELL 1900 System Test 24 / Picocell 1900 Radio Unit Installation... -
Page 25: Appendices
September 3, 1998 Method 02-0245 6.0 Appendices Appendix A - PICOCELL 1900 transciever Cover removed Top view Picocell 1900 Radio Unit Installation / 25... -
Page 26: Appendix B - Mounting Orientation And Isolation
Wire entrance Wall or Ceiling outlet box Note: Ensure station wiring does not loop or coil near the PICOCELL 1900 antenna. The unit installation should mount as shown with maximum spacing between the antenna and entrance wiring to avoid interference with RF signals. -
Page 27: Appendix C - Picocell 1900 Technical Specifications
• Maximum length remote Power (see IM 04-0242 section 4.2) • 1900MHz Version IS 136 TDMA operation • 100mW (+20dBm) ERP • 2 RF channels per PICOCELL 1900 RF unit (Internal duplexer) • Internal Omni Antenna • Receiver Diversity • Distributed Omni and directional Antenna Support •... -
Page 28: Picocell 1900 Power Supply Specifications
• output current limiting • Short circuit protection Mechanical • 6.58 L x 4.0 W x 1.25 H(in) • Case Material: Black 94V0 Polycarbonate • Weight: 22 ounces, 625 grams (excluding cords) Last Page 28 / Picocell 1900 Radio Unit Installation...
