Download
Share
Print this page
  1. Manuals
  2. Brands
  3. GTV Manuals
  4. Drill
  5. 128242
  6. Owner's manual

GTV 128242 Owner's Manual

3/8 inch reversible electric drill
Hide thumbs Also See for 128242:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Owner's Manual
3
/
" REVERSIBLE
8
ELECTRIC DRILL
Model No.
128242
CAUTION:
Before using this
Electric Drill, read
this manual and
follow all its Safety
Rules and Operating
Instructions.
Manufactured For and Distributed By
True Value® Company, Chicago, IL
©2010 True Value Company
Made in China
Safety Instructions
Assembly
Operation
Maintenance
Parts List

Advertisement

loading
Need help?

Need help?

Do you have a question about the 128242 and is the answer not in the manual?

Questions and answers

Related Manuals for GTV 128242

Summary of Contents for GTV 128242

  • Page 1 Owner’s Manual " REVERSIBLE ELECTRIC DRILL Model No. 128242 CAUTION:  Safety Instructions Before using this  Assembly Electric Drill, read  Operation this manual and  Maintenance follow all its Safety  Parts List Rules and Operating Instructions. Manufactured For and Distributed By True Value®...
  • Page 2 SATISFACTION GUARANTEE If for any reason you are not completely satisfied with the performance of the GTV product, it will be replaced free of charge. Simply provide proof of purchase and return the product to your place of purchase. WARNING...
  • Page 3 POWER TOOL SAFETY GENERAL POWER TOOL SAFETY WARNINGS Do not expose power tools to rain or wet conditions. Water entering a power WARNING: tool will increase the risk of electric shock. Read all safety warnings and instructions. Failure to Do not abuse the cord. Never use the follow the warnings and instructions may cord for carrying, pulling or unplugging result in electric shock, fire and/or serious...
  • Page 4 POWER TOOL SAFETY PERSONAL SAFETY – cont’d Disconnect the plug from the power source before making any adjustments, Prevent unintentional starting. Ensure changing accessories, or storing power the switch is in the off-position before tools. Such preventive safety measures connecting to power source picking up reduce the risk of starting the power tool or carrying the tool.
  • Page 5 SPECIFIC SAFETY Hold power tools by insulated gripping Wear ear protectors with impact drills. surfaces when performing an operation Exposure to noise can cause hearing loss. where the cutting tool may contact hidden wiring or its own cord. Contact Use auxiliary handles supplied with the with a “live”...
  • Page 6 EXTENSION CORD USE & SAFETY Make sure your extension cord is in good condition. When using an extension WARNING cord, be sure to use the proper minimum gauge extension cord. An undersized cord Repair or replace damaged or worn will cause a drop in line voltage resulting in extension cords immediately.
  • Page 7 UNPACKING & CHECKING CARTON CONTENTS WARNING DRILL COMPONENTS If any part is missing or damaged, do not plug the drill into the power source DESCRIPTION until the missing or damaged part is Drill Assembly replaced and assembly is complete. Carefully unpack the drill and all its components.
  • Page 8 ASSEMBLY & OPERATION VARIABLE SPEED DIAL WARNING Remove the plug from the power source The variable speed dial in the trigger before assembly, changing accessories switch (see Fig. 1 on page 7) can be used or bits and making adjustments. This when driving screws to limit the risk of over driving screws.
  • Page 9 ASSEMBLY & OPERATION WARNING INSTALLING BITS – cont’d Have you read “POWER TOOL SAFETY”, “ELECTRIC DRILL SAFETY” and “ELECTRICAL REQUIREMENTS & SAFETY” on pages 3, 4, 5 and 6 of this Manual? If not, please do it now before you operate this drill. Your safety depends on it! Fig.
  • Page 10 ASSEMBLY & OPERATION DRILLING – cont’d CHUCK REMOVAL While holding the drill firmly, place the The drill chuck must be removed in order point of the drill bit at the point to be to use some accessories. To remove the drilled.
  • Page 11 MAINTENANCE ASSEMBLY & OPERATION CHUCK REMOVAL – cont’d GENERAL Insert hex key into chuck and tighten WARNING jaws of chuck securely (see Fig. 6). Tap the hex key sharply with a mallet When servicing, use only identical in a COUNTER CLOCKWISE original equipment parts.
