GATEWAY TO SMARTER TELECOMS
Quick Start Guide – Initial Setup (PC)
INTRODUCTION
This document is designed to instruct you on the basic setup of your Hypermedia™ GSM
gateway, from out of the box and powering up, to getting the unit successfully connected
to your local LAN and ready to be accessed remotely and further configured according to
specific site requirements. Below are the topics covered.
** If you are unsure about any of the steps covered in this guide, please call the
support team a call on 0900 111 2222 and they will be happy to help **
CONTENTS
Introduction ................................................................................................... 1
Contents ........................................................................................................ 1
Upacking The Unit ........................................................................................... 2
Installing The Management Software ................................................................. 2
Adding Your Unit To Server List ......................................................................... 3
Setting The Ip Address Of The Unit ..................................................................... 3
Removing And Inserting Gsm Cards .................................................................... 5
Understanding Port & Sim Positions ................................................................... 6
Installing Sims ............................................................................................... 6
Setting Up Remote Access ................................................................................ 7
Isdn Quick Start Guide ................................................................................... 7
Contacting Technical Support ............................................................................ 7
Page
|
1
Advertisement
Table of Contents
Summary of Contents for Packet Media hypermedia
- Page 1 Quick Start Guide – Initial Setup (PC) INTRODUCTION This document is designed to instruct you on the basic setup of your Hypermedia™ GSM gateway, from out of the box and powering up, to getting the unit successfully connected to your local LAN and ready to be accessed remotely and further configured according to specific site requirements.
-
Page 2: Upacking The Unit
HyperSMSx.x.x.exe file where x.x.x is the version number. The install should now begin. Follow the on-screen instructions to complete the install of the admin tool. You should now have the Hypermedia™ icon on your desktop. Double click the icon and you... -
Page 3: Adding Your Unit To Server List
GATEWAY TO SMARTER TELECOMS ADDING YOUR UNIT TO SERVER LIST Click the “add” link contained in the title. Please note that adding units using the Firefox browser will not work. Please use IE6 or later. Next will be presented a box of fields where the various gateways details can be defined. - Page 4 GATEWAY TO SMARTER TELECOMS Setting the IP Continued - Direct Connection to PC Laptop 192.168.0.5 Lan 1 – 192.168.0.2 Standard Ethernet cable Go back to the server list and click the icon that looks like a cog (pictured below). The unit’s password will be requested at this stage. The default is “hypergateway”. Submit and you will be taken to the “HGS Setup Parameters Screen”...
-
Page 5: Removing And Inserting Gsm Cards
GATEWAY TO SMARTER TELECOMS REMOVING AND INSERTING GSM CARDS It is essential GSM cards are removed and inserted in the correct manner, or damage could occur to the card itself, or to the unit’s chassis/back-plane. The following section will explain and illustrate the correct method. **GSM cards and ONLY GSM cards can be removed while the gateway is powered up. -
Page 6: Understanding Port & Sim Positions
GATEWAY TO SMARTER TELECOMS UNDERSTANDING PORT & SIM POSITIONS Each of the GSM cards has 4 GSM modules/ports that can each hold up to 4 sim’s giving you a max of 16 sims per card. Position 1 sim’s for all 4 ports are in the front of the cards, while positions 2 to 4 are held on the inside of the cards usually hidden inside the unit. -
Page 7: Setting Up Remote Access
8878 63333 For remote access via an external “Nat’d” IP address, the above ports should be forwarded from the external IP address to the internal LAN address of the Hypermedia™ gateway in the firewall/router configuration. ISDN QUICK START GUIDE If required you will also find a voice setup guide in the box covering dedicated & pass- thru ISDN setup.
