User Manual

CP8N

Programmable Control Panel

Version: CP8N_2016V1.0

Table of Contents

Need help?

Do you have a question about the CP8N and is the answer not in the manual?

Questions and answers

Summary of Contents for Altimium CP8N

Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
Page 3: Safety Precautions
 Unplug the power cord when left unused for a long period of time.  Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
Page 4 Programmable Control Panel Table of Contents 1. Introduction ......................... 1 1.1 Introduction to CP8N ..................1 1.2 Features ......................1 1.3 Package List ...................... 1 1.4 Installation ......................2 2. Panel Descriptions ...................... 2 2.1 Front Panel ......................2 2.2 Side Panel ......................3 2.3 Rear Panel ......................
Page 5: Introduction
1.1 Introduction to CP8N CP8N is a Wall Control Panel. Every button is programmable and works either individually or together. CP8N is built in the programmable 3 RS232, 1 RS485, 3 Infrared & 2 Relay, and 1 mini USB for programming.
Page 6: Installation
Then, plug a set screw into the fixing mounting and screw the nuts tightly. Figure 1- 1 Aperture paper Figure 1- 2 Installation Guide 2. Panel Descriptions 2.1 Front Panel Crystal and luminescent, programmable buttons: Every button can be programmable with the software PS-WP. Connect the PC via USB or RS232. Altimium www.altimium.com...
Page 7: Side Panel
(Optional). Infrared sensor port: receive and learn the IR code, to build the IR database. Note: When use this USB port to program the control panel’s buttons, the available COM port number should not be more than 10. Altimium www.altimium.com...
Page 8: Rear Panel
④ ② CP8N has various ports in the rear panel, including Lopping port, RS232 port, RS485 port, IR port, Relay port and Power port. Below is the introduction: ① Power connector: 12VDC. Be sure that the “+” and “-” never be mixed or wrong connection.
Page 9: Connections
3. Connections 3.1 System Diagram CP8N can active different ports at one time. It means every button can send the RS232 and RS485 commands, IR code and control the relay at the same time. The demo system diagram as below: 3.2 Connection of Programming and Looping...
Page 10 After connect the CP8Ns as above, and then we should set the ID of each CP8N by PS-WP. The ID number is from 01 to 99, and it also is the class of the CP8N in the loop, different CP8Ns should set to different ID. After connections finish, we can set the control modes by PS-WP.
Page 11 Programmable Control Panel Last class … Second class Detailed looping connecting Note: Up to 99 CP8Ns can be looped within one system. However, to achieve normal interaction, loop less CP8Ns (10 tops) in the system. Altimium www.altimium.com...
Page 12: System Operations
But when connect the CP8N with PC by USB, it may need to install the USB driver. Use the driver file to install the driver of USB, we can use USB to program the CP8N. 4.2 Software Programming You can use this software PS-WP to easily set every button of the CP8N.
Page 13 NOTICE: When select the model, it will pop up “Output Port Selection” dialog, user can select different RS and IR types, depend on the uses of the two shared ports. The dialog is as the picture below: Altimium www.altimium.com...
Page 14 Programmable Control Panel The output port set in PS-WP and the port used in the CP8N is corresponding. And there are four output types. They are showed as below form (“√” means port is available): Output port of the Panel...
Page 15: Panel/Key Setting
Here take programmable control panels-V for example, to introduce the uses of different buttons: White keys: keys 1-8, correspond to the buttons on the CP8N. Click the key, it will pop up dialog as below: Altimium...
Page 16 The toggle class is the action loop class, depends on the numbers of looped actions. When the class is 2, there are two actions in the toggle. And so on. 2. Blue Keys: Keys 9-32, all are virtual keys, used in the loop function. When use the Altimium www.altimium.com...
Page 17: Action List
Yellow Keys: Keys 33-36, all are virtual keys. Key 33 and 34 are for I/O control, which is not supported with the CP8N. Key 36 is a start action, if add events to this action, when the CP8N is power on, it will execute the events in this action.
Page 18: Event Setting
Toggle setting. Before set events, an action must be added first. The following introduction will show you the setting of each event:  RS232 Setting This item is used for setting the parameters of the CP8N’s serial ports. Click “RS232”, it will show as below: Send...
Page 19 4) User can set the event name. It is optional function, not necessary.  IR Setting This item is used for setting the parameters of the CP8N’s IR ports. Click “IR”, it will show as below: Altimium...
Page 20 Notice: When editing finish, remember to save the editing, and then press “OK”. There are two send types: send once and send more times. When select “more times”, the send times and the delay between times can be set. See in picture below: Altimium www.altimium.com...
Page 21 The IR can set the carrier on/off, to turn on/turn off the IR sending.  I/O Setting There is no I/O port in the CP8N, so the setting is not introduced in this manual.  Relay Setting This item is for the replay ports setting. The setting is as the picture below: Port Action: “On”...
Page 22 RS232 command to the controlled device, the device will send back a feedback. If we add the correct feedback in the data, the CP8N will compare it with the feedback received from controlled device, to verify the command is work or not. The compare...
Page 23 If the compare is incorrect, the event behind compare will not be executed.  LED setting This item is used for set the button LEDs in the CP8N to turn on/off. The setting is as below:  Page setting White buttons can be set to type “page”...
Page 24 Then set the “page” event to make four “press” actions to active the four page number: key5-num1, key6-num2, key7-num3 and key8-num4. It will perform like this: a) When press the button5 and then button1, the button1 will execute the event of num1, press button1 more times it will execute num1 more times; Altimium www.altimium.com...
Page 25 When press the button8 and then button1, the button1 will execute the event of num4, press button1 more times it will execute num4 more times.  Loop Setting This item is used for looping the CP8N. When use the loop function, the ID of each CP8N must be set.  Toggle Setting...
Page 26: Event List
The event list shows all events of the selected action. The executing priority abides by the serial number, see the picture below. If there is an event execute incorrectly, all the events behind it will not be executed. Altimium www.altimium.com...
Page 27: Specification
9600 baud, 8 data bits, 1 RS232 Port Protocol stop bit, no parity Software PS-WP Temperature -20 ~ +70° C Frequency 20Hz ~20KHz Humidity 10% ~ 90% Response 100VAC~240VAC, Power Power Supply 50/60 Hz Consumption Case 114x70 x28mm Product Weight 0.15kg Dimensions Altimium www.altimium.com...
Page 28: Panel Drawing
Programmable Control Panel 6. Panel Drawing 50 mm 70 mm CP8N +12 VDC RELAY 1 RELAY 2 RS485 IR 1 RS232 1 ( ) / IR 2 RS232 2 ( ) IR 3 NET OUT RS232 3 ( ) CONFIG...
Page 29: Troubleshooting & Maintenance
5) When serial commands sending without function executed, please check the baud rate and make sure is correct, and the serial connection is well. If the controlling queue is confused when use loop function, please reboot the CP8N. Altimium www.altimium.com...
Page 30: After-Sales Service
 Product version and name.  Detailed failure situations.  The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor. Altimium www.altimium.com...
Page 32 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
