Z-SHADE Instant GAZEBO User Manual page 2

PA C K AG E I N C L U D ES
• Instant Gazebo Frame
• Two-Tone Polyester Top (A) (B)
• (4) Corner Skirts (C)
I N I T I A L S ET U P
Please read each step before you attempt to set up. Save these instructions for future reference.
Place your Instant Gazebo 2 Spread the top vent fabric
1
frame in the center of area (A) over the peak section
to be shaded. With partner, and slide the 4 fabric corners
grasp two outer legs, slightly over the 4 vent fingers.
lift off the ground, and step
backwards, stopping at full
arms' length.
S ET U P
With partner on opposite side
1
of canopy, grasp the top and
bottom of the truss on
opposite sides. Lift up and
step backward until canopy is
Clips
3/4 opened. Be careful not to
pinch fingers. Expand frame
to fully open. Make sure the
4 Attach the larger fabric
vent fingers are released –
to the frame by
over the LARGE FABRIC.
inserting the 2 clips
into the small holes at
the top of each leg.
• Roller Bag
• 4-Piece Stake Kit
(A) (B)
Expand the frame to approx.
3
2/3 open. Spread the larger
fabric (B) over the frame,
tuck the fabric under the top
vent fabric fingers and using
the hook and loop strips,
secure the top to the trusses
at 8 different points.
2 To engage Pull Pin slider at each
corner, first lift the fabric off of the
slider, then with one hand hold
the top of the leg while pushing
up on the slider with the other
hand. The Pull Pin will engage the
hole. Repeat on all 4 corners.
a) Insert extension rods in the top of the legs. b) Secure corner fabric to the leg by inserting the
3 a
2 clips into the small holes at the top of each leg. c) Finally, pull the fabric out over the end of the
extension rods and secure using the sewn pockets. Repeat on all 4 corners.
a
b
5 (C)
Snap
Button
4 Lift outer legs up and slide out
the inner legs until the snap
button locks into the outer leg.
Repeat on opposite legs.
TAK E D OW N
3 Release Pull Pin at each corner
Snap
by first lifting fabric away from
Button
slider. With one hand push up
on truss near the Pull Pin,
pull the pin out to release.
1 With partner, slightly lift up 2
NOTE: It is much easier to
adjacent outer legs, depress snap
release Pull Pin when the
button to unlock and telescope
canopy weight has been
inner legs into outer legs.
removed from the Pull Pin.
Repeat on opposite legs.
2 Now, with the canopy in 4 With partner on opposite
side, grasp top and bottom
lowered position, remove
extension rods. area of trusses. Lift the
canopy up slightly and shake
1) Pull the fabric back out
from the sewn pockets to gain it while stepping towards
access to extension rods. your partner until the unit is
2) Remove fabric by releasing 3/4 closed. With each
the 2 clips from the small partner grasping two outer
holes at the top of each leg. legs, push frame together to
3) Carefully slide extension fully close it. Be careful not to
pinch fingers!
rods out from the top of the
legs. Repeat on all 4 corners. Store canopy in roller bag.
WARNING: Keep all flame and heat sources away from all product fabrics. These fabrics meet
the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact
with any flame source. The application of any foreign substance to the fabric may render the
flame-resistant properties ineffective.
b
c
c
ATTACHING CORNER SKIRTS
1) Erect frame to the lowest setting.
Elastic
2) Wrap the skirt around the outside of
Clips
the leg with the clip on top.
Non-coated side facing outward.
3) Connect the elastic clips around
the top truss on both sides.
4) Use the attached tie-back straps to
gather the skirt.
Repeat on all 4 corner skirts.
Pull
Pin
