Summary of Contents for Smartware ULTRASMART USN3se
- Page 1 USN3se, MX3se-3I3P - Datasheet V1R01c ™ LTRA MART RIPLE NTERFACES FOR PRODUCTION (USN3se, MX3se-3I3P) Industrial equipment to personalize contact and contactless smart cards or modules. Datasheet V1R01c Date: December 2016 © 2016, Smartware CONFIDENTIAL...
- Page 2 Any reproduction or any complete or partial representation of the pages published in this work, made without the written permission of SMARTWARE is illicit and constitutes an imitation, whatever mean is used. Only reproductions strictly reserved for the private use of the purchaser and not intended to be used collectively are authorized.
- Page 3 4.3.2 Configuration and address switches ..................14 4.3.3 LEDS ............................16 Electrical characteristics ..................... 17 4.4.1 Power Supply ......................... 17 4.4.2 Contact interfaces ........................18 4.4.3 Contactless interfaces ......................19 Regulatory ..................... 20 Contact information ..................22 Revision history ..................... 22 © 2016, Smartware CONFIDENTIAL...
- Page 4 Standard or Proprietary Use Single Wire Protocol Work Waiting Time Glossary 12 V 3A: 12 Volt 3 Amp Direct Current (DC) power supply Modulation index: Defined as the voltage ratio (Vmax - Vmin) / (Vmax + Vmin). CONFIDENTIAL © 2016, Smartware...
-
Page 5: Overview
OVERVIEW USN3se and MX3se-3I3P are industrial solutions dedicated to the personalization of contact and contactless smart cards and memory cards. USN3se fulfills any integration based on Smartware industrial racks while MX3se-3I3P is dedicated to the Datacard MX smart card module. -
Page 6: Block Diagram
To optional connectors ST8000/ST8001 Flash (aX6e version only) RF aodulator RF Amplifier Node Offset Clocks RF aodem Logic : - Interface Led INTERFACE B Idem Interface A INTERFACE C Idem Interface A Synoptic chart of one communication interface CONFIDENTIAL © 2016, Smartware... -
Page 7: Functional Description
USN3se, MX3se-3I3P - Datasheet V1R01c FUNCTIONAL DESCRIPTION USN3se and MX3se-3I3P are Smartware assemblies that include three independent US-NANO modules. Each US-NANO module provides a CPU core and a dual communication interfaces for contact and contactless smart cards or smart objects. -
Page 8: Hardware Measurements
To properly test one contact, all others contacts shall be in high impedance state, and C5 contact must be driven by the reader (i.e. it should not be linked to the ground/earth). Force Voltage measurement of the clamp diode for contact C3 CONFIDENTIAL © 2016, Smartware... -
Page 9: Contactless Interfaces
• Protocol specific error detection and recovery. • Authentication mechanisms requiring cryptography and ciphered exchanges. At last, contactless interfaces support both contactless smart cards with inductive coupling to an antenna and contactless modules with a direct connection to the RF pads. © 2016, Smartware CONFIDENTIAL... -
Page 10: Technical Characteristics
ECHANICAL LAYOUT 100.00 19.42 13.08 13,50 13,50 10,00 5,55 Ø2,70 5,50 5,50 aStC 5,00 aStB aStA Ø3,20 ST8000 L1 L2 SWCFG 5,50 DIN 41612 C/2 aâle R/A 16 x 3 2.00 USN3se or MX3se-3I3P top side view CONFIDENTIAL © 2016, Smartware... -
Page 11: Front Panels
Components on bottom side are lower than 2 mm. The fixing attachment holes and side strips are connected to the USN3se and MX3se-3I3P electrical ground. 4.2 F RONT PANELS USN3se specific 3U / 4TE front panel MX3se-3I3P specific 3U / 8TE front panel © 2016, Smartware CONFIDENTIAL... -
Page 12: Physical Interfaces
C7 smart card contact (I/O) Shield Ground 4.3.1.2 CL1, CL2 and CL3 description CL1, CL2 and CL3 connectors provide signals of the contactless interfaces. The following table describes the pinout for all interfaces: ESCRIPTION RF_ANT Center RF output Body Ground CONFIDENTIAL © 2016, Smartware... - Page 13 Ethernet Pair 2 + ETH_BP_0P Ethernet Pair 0 + ETH_BP_1M Ethernet Pair 1 - ETH_BP_2M Ethernet Pair 2 - ETH_BP_0M Ethernet Pair 0 - Internal pull up resistor Internal serial resistor for current limiting function Termination only © 2016, Smartware CONFIDENTIAL...
-
Page 14: Configuration And Address Switches
MLOS.INI configuration file, and does not start any system and user applications. The Mono Mode does not start MLOS operating system. It only allows to boot the CPU cores, and to communicate through a Serial port to reload an MLOS operating system. Termination only CONFIDENTIAL © 2016, Smartware... - Page 15 Node offset bit 0 Node offset b1 Node offset bit 1 Node offset b2 Node offset bit 2 The default configurations of the node offsets are: ODEL NTERFACE ODE OFFSET VALUE USN3se USN3se USN3se MX3se-3I3P MX3se-3I3P MX3se-3I3P © 2016, Smartware CONFIDENTIAL...
-
Page 16: Leds
• ON if link is established Backplane Ethernet link status • ON if link is established Backplane Ethernet speed • ON (100 Mbps) • OFF (10 Mbps) Not used for models USN3se and MX3se-3I3P Not used for models USN3se and MX3se-3I3P CONFIDENTIAL © 2016, Smartware... -
Page 17: Electrical Characteristics
An USN3se or MX3se-3I3P assembly shall be powered by a 12 Volt 3 Amp Direct Current (DC) power supply. OWER SUPPLY YPICAL RECISION Rating Voltage (12 V 12 V DC ±1.2V Idle Current (V = 12 V) 950 mA Maximum Current (V = 12 V, RF Output 1850 mA short circuited) © 2016, Smartware CONFIDENTIAL... -
Page 18: Contact Interfaces
Current to measure a clamp diodes 2,5 mA 3,2 mA voltage Diode threshold voltage range 0.1 V 2.5 V Diode threshold voltage precision 0.1 V 470 kΩ internal pull-down 10 kΩ and 4.7 kΩ software selectable internal pull-ups connected to V CONFIDENTIAL © 2016, Smartware... -
Page 19: Contactless Interfaces
ISO14443 A / PayPass A / 90 % 100 % 100 % Mifare ISO14443 B / PayPass B 9.5 % 12.5 % 11 % ISO15693 9.5 % 12.5 % 11 % FeliCa 9.5 % 12.5 % 11 % © 2016, Smartware CONFIDENTIAL... -
Page 20: Regulatory
Warning 8: In case of collocated transmitters, the maximum number of transmitters in a small place should be 48. Warning 9: The product shall not be modified without written authorisation of Smartware. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 21 NO UNAUTHORIZED MODIFICATIONS 47 CFR Section 15.21 CAUTION: This equipment may not be modified, altered, or changed in any way without signed written permission from Smartware. Unauthorized modification may void the equipment authorization from the FCC and will void the Smartware warranty.
-
Page 22: Contact Information
For more information, please send an email to: support@smartware.fr For ordering information, please send an email to: sales@smartware.fr REVISION HISTORY ERSION UTHOR CHANGES V1R01c December 2016 Editorial corrections V1R01b November 2016 Add Regulatory section. Editorial corrections V1R01a July 2016 Original version CONFIDENTIAL © 2016, Smartware...
