To get your ePipe up and running quickly, follow the four
steps below.
To understand how you can use ePipe see "Using ePipe"
in the "ePipe Exposed" section of the Stallion Software &
Documentation CD-ROM.
– – – – –
Before you Start
Check the packing list below to ensure you have all the correct parts (cables are color
coded for identification):
Your ePipe kit should contain:
ePipe 2202 unit
H
AC/DC power supply unit
H
Two Ethernet UTP cables (green connector)
H
Console cable with DB9 connectors (black)
H
Stallion Software & Documentation CD-ROM
H
Warranty Registration Card
H
Quick Setup Guide (this card)
H
— — — — —
What Else do you Need?
To connect your ePipe to an Internet Service Provider (ISP) or other network you will need
the following:
•
PC running Windows (95, 98, NT or 2000) with an Ethernet Network Interface
Card (NIC) configured and operational to use the "Find ePipe" utility
•
A cable or xDSL modem or a dedicated access router (ISDN, T1, Frame Relay,
etc)
•
A cable, xDSL or other dedicated connection
•
An account with an ISP for connecting to the Internet
•
An available port on your Ethernet hub or switch to which you will connect
the ePipe 2202
2202
Quick Setup Guide
