Preliminary User manual GlobespanVirata ISL39300A IEEE 802.11a/g WLAN Access Point User Manual Version 0.1 FCC ID: RGS39300A Page 1 of 10...
Page 2
Preliminary User manual Table of Contents 0-INTRODUCTION ....................3 1-INSTALLATION PROCEDURE ................3 1.1 I .................3 NSTALLING THE CCESS OINT 1.2 I ..............3 NSTALLING THE SOFTWARE DRIVERS 1.3 W IRELESS INSTALLATION GUIDE LINES AND UTHORIZATION FOR USE 2-REGULATORY INFORMATION.................7 2.1 FCC I ................7 NFORMATION TO 2.2 FCC G...
Preliminary User manual 0-Introduction The GlobespanVirata ISL39300A WLAN Access Point (AP) is a complete wireless high speed AP solution. It conforms to the IEEE 802.11g and IEEE 802.11a protocol and operates in the 2.45 GHz and 5150- 5350MHz frequency bands.
Page 4
Preliminary User manual e-double click the GlobespanVirata WLAN icon to open the WLAN settings, the following window will appear (see fig.02) fig, 02: GlobespanVirata WLAN settings window f-click on configuration tab and select which type of network is required (access point or Peer-to-peer mode), see fig.
Preliminary User manual g-select what TX rate is required (default setting is fully automatic) see fig. 04. fig, 04: WLAN tx rate setting window h-select what encryption type is required, 64 or 128 bit WEP (default setting is disabled) see fig. 05. fig, 05: WLAN encryption rate setting window FCC ID: RGS39300A Page 5 of 10...
Preliminary User manual i-click on the status tab to see the connection status (fig.06). fig, 06: WLAN network status j-click on the about tab to see the software drivers versions and MAC address (fig.07). fig, 07: WLAN driver and MAC addres information FCC ID: RGS39300A Page 6 of 10...
Preliminary User manual 1.3 Wireless LAN installation guide lines and Authorization for use Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by GlobespanVirata may void the user’s authority to operate the equipment.
Page 8
Preliminary User manual 2.4 FCC Radio Frequency Interference statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Preliminary User manual 2.6 Europe - EU Declaration of Conformity This device complies with the essential requirements and other relevant provisions of the European R&TTE Directive 1999/5/EC. Compliance to essential test suites is met per standards: R&TTE Harmonized Standard Description LVD specification EN 60950,ed.
Preliminary User manual 3-Technical Specifications IEEE 802.11g and IEEE 802.11a (DSSS and OFDM) Radio Technology Operating Frequency 2400-2497MHz ISM band and 5150-5350 MHz bands Modulation Schemes DQPSK, DBPSK, CCK, 16 QAM, 64 QAM RF Channel Availability 2.4GHz band 11 channels for United States (2412 MHz to 2462 MHz) 13 channels for Europe (2412 MHz to 2472 MHz) 13 channels for Japan (2412 MHz to 2472 MHz), channel 14 only available in DSSS mode (11 Mbps max)
