Product Ove rvie w
This HD video grabber with whole A/V input terminal, support 1080p/ 720p / 480p / 480i, 1080i
full HD full screen real-time preview & capture while without distortion, can connect digital TV
STB, MOD, BD Blu-Ray Player, HDV digital camera, Xbox & PS3, etc. offer DVI-I (DVI-D or
VGA) input, can connect another PC / Mac display card to record directly.
Feature:
★
Support Windows 7
★
Support HD 1080p real-time record
★
MPEG-4 real-time compress
★
MST3367CMK-LF-170 10-bit HD Image processing chip
★
PCI-Express *1, support plug and play
★
Support NTSC/PAL
★
Dynamic acquisition: AVI(MPEG-4/VBR) and Static collection: BMP/JPG format
★
Sampling frequency: 16-bit / 32~48KHz/ Stereo
★
4:3 / 16:9 display
★
Image window zoom and full screen preview
★
Video format detect, window display ration automatically
★
Zooming display function (MouseWheel)
Resolution Support:
Input Terminal
SDI
HD
Ypbpr
HD
HDCA02
Mode
NTSC
1920*1080p*30fps
1080P
1920*1080p*24fps
1080I
1920*1080i*30fps
720P
1920*720p*60fps
1080P
1920*1080p*30fps
PAL
1920*1080p*25fps
1920*1080p*24fps
1920*1080i*25fps
1920*720p*50fps
1920*1080p*25fps
Advertisement
Table of Contents
Summary of Contents for KATO VISION HDCA02
- Page 1 HDCA02 Product Ove rvie w This HD video grabber with whole A/V input terminal, support 1080p/ 720p / 480p / 480i, 1080i full HD full screen real-time preview & capture while without distortion, can connect digital TV STB, MOD, BD Blu-Ray Player, HDV digital camera, Xbox & PS3, etc. offer DVI-I (DVI-D or VGA) input, can connect another PC / Mac display card to record directly.
- Page 2 1920*1080p*24fps 1920*1080p*24fps 1080I 1920*1080i*30fps 1920*1080i*25fps HDMI 720P 1920*720p*60fps 1920*720p*50fps 480P 720*480p*60fps 720*576p*50fps 480I 720*480i*30fps 720*576i*25fps 800*600p*60fps 800*600p*60fps 1024*768p*60fps 1024*768p*60fps 1280*960p*60fps 1280*960p*60fps HDMI 1280*1024p*60fps 1280*1024p*60fps 1440*900p*60fps 1440*900p*60fps Parameter: Dimension 114.44*101.03(mm) Interface PCIe*1 Video Input 1*SDI, 1*HDMI, 1*DVI-D, 1*DVI-A, 1*Ypbpr Video Format YUY2 NTSC/PAL 1920*1080p@30/25/24fps...
- Page 3 1280*960p@60fps 1024*768p@60fps 800*660p@60fps 640*480p@60fps 720*480p@60fps 720*586p@60fps Audio Input 1*SDI, 1*HDMI, 2*RCA Audio Format Stereo / 16-bit/3200-4800Hz √ WatchDog ∞ Multi Card Composite VC++ / .NET / BCB / VB/ V4L2 WINDOWS XP /VISTA/ 7 Operation System Linux 2.6. 14 or higher (32-bit and 64-bit) Accessories: Driver Disk...
