Newer Technology MXP802NRTR Quick Installation Manual

Wireless-n broadband ap/router
Hide thumbs

Advertisement

Quick Links

Download this manual
Wireless-N Broadband AP / Router
Quick Installation Guide
Version 1.3

Advertisement

loading
Need help?

Need help?

Do you have a question about the MXP802NRTR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Newer Technology MXP802NRTR

  • Page 1 Wireless-N Broadband AP / Router Quick Installation Guide Version 1.3...
  • Page 2 Table of Contents English 1. Before Installation ..........................2 2. Hardware Installation ........................3 3. Configure your computer’s TCP/IP Settings..................4 4. Configure your AP ..........................7...

  • Page 3: Package Contents

    1. Before Installation Thank you for purchasing the Wireless 11n AP Router. This guide will help you set-up and configure your AP with easy-to-follow instructions. For more detailed or advanced settings, please refer to the User Manual on the CD-ROM. Package Contents Please make sure you have the following in the box: ♦...
  • Page 4 2. Hardware Installation 1. Power off your network devices. 2. Locate an optimum location for the AP. The best place for the AP is usually at the center of your wireless network, with line of sight to all of your wireless devices. 3.
  • Page 5 3. Configure your computer’s TCP/IP Settings Windows 2000/XP Click Start; click Settings and then click on the Control Panel. Double-Click the Network Connection icon. Right-Click on the Local Area Connection icon and then click on Properties. The Local Area Connection Properties windows will appear. Under the General Configuration Tab, locate and select TCP/IP with the corresponding network card, then click Properties.

  • Page 6: Windows Vista

    Now your computer is ready to access and configure the AP. Windows VISTA Click Start Control Panel, then Network and Internet Manage network connections. Right-Click on the Local Area Connection icon and then click on Properties. The Local Area Connection Properties windows will appear. Under the Networking Configuration Tab, locate and select Internet Protocol Version4 (TCP/IPv4) with the corresponding network card, then click Properties.
  • Page 7 Click on Use the following IP Address and enter IP Address: 192.168.1.10 Subnet Mask: 255.255.255.0 Default gateway: 192.168.1.1 Now your computer is ready to access and configure the AP. NOTE : The default IP address setting for the AP is a class C IP address (192.168.1.1 / 255.255.255.0).
  • Page 8 4. Configure your AP Open your web browser, type http://192.168.1.1 in the Address bar, and press Enter. An authentication window will appear. Enter the username and password, and then click OK. By default, please leave blank in username and type admin in password. Turn to the Wireless Section;...
  • Page 9 When the AP reboot procedure is completed, you may change the TCP/IP properties of this computer. Select the “Obtain an IP address automatically” instead of “Use the following IP Address “ item if your local network has DHCP server service to assign IP address for your wireless client.
  • Page 10 This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The MXP802NRTR ( FCC ID: UNH-MXP802NRTR ) is limited in CH1~CH11 for 2.4 GHz by specified firmware controlled in U.S.A.
