Summary of Contents for SHENZHEN LIANCHUANG TECHNOLOGY GROUP CO. DF-HU28010
- Page 1 Cool and Warm Mist Ultrasonic Humidifier DF-HU28010 User's Manual Please read the manual carefully before use.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS 1. Read all instructions carefully and keep this manual for future reference. 2. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 3 19. Children should be supervised to ensure that they do not play with the appliance and packaging materials. 20. Please use pure water for cleaning the humidifier instead of any cleansers. 21. Do not disassemble the humidifier. 22. If long time no use, please unplug the appliances. (Do not need to connect to the ground) 23.
- Page 4 Nozzle top-fill water cover Front Water tank panel Water tank cover Base Base cover Display (see more detail at the end of the files) Six touch control icon. ON/OFF HI/LO Humidity setting Timer Warm mist Sleeping Mode Inside view:...
- Page 5 Floater Heating elements Silicone plunger Transducer Air outlet Brush’s position FEATURES 1. Ultrasonic humidifier, 2. Touch control. 3. Cool and warm mist optional. 4. Humidity setting and display（40% 50% 60% 70% CO）. 5. Hi and low modes for mist control. 6.
- Page 6 Note: Do not add water to the base directly. Take away the top-fill water cap, you can add water from it directly. Put the filter and the tank back. There will be “gurgling” sounds and air bubbles would appear once the tank is placed correctly into the humidifier.
- Page 7 ②OFF：Press again the ON/OFF icon. The matrix screen will display OFF for 1 second, the buzzer will sound “Bi—”and then standby： a) DC fan OFF; b) PTC OFF; c) Screen OFF; （ （ （ （ 3） ） ） ） HI/LO Mode Setting： ： ： ： a) Default HI Mode when start;...
- Page 8 lack of water, the screen will display as POINT 8. Except ON/OFF icon and sleeping mode icon, other icons are invalid. ② Press this icon twice. Exit sleeping mode. The buzzer on, other functions keep the same. It will display ZZZ for 1 second and then display .The middle line will flicker for 2 seconds.
- Page 9 gutter. The intensity of the mist would be affect by the relative humidity, temperature of the area. It would be harder to generate mist if it is cold and wet. The water used should be between 4°C to 50°C and should be clean tap water or distilled water.
- Page 10 Clean the transducer, tank, and main body every week. Replace water frequently. Do not remove the water tank once it has been properly placed unless a refill of water is needed. Whenever you need to pour away water from the water trough, unscrew at the bottom part of the main body (the outlet) then let the water flow out.
- Page 11 This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
