- Page 1 App Instruction Manual Sygonix Home Starter Kit Item No. 1597114 www.conradconnect.de...
- Page 2 Contents Conrad Connect ..........4 Symbols ............4 Core functions ..........5 App to device communication ......6 App – Installation ..........7 App – Deinstallation ........7 App – Multiple mobile devices ......7 App – User account ......... 8 App –...
- Page 3 Sensors – Add sensor ........19 Sensors – Sensor page ......... 21 Sensors – Delete sensor ....... 22 Sensors – Configure sensor ......23 Sensors – Enable/disable sensor ....24 Function – Alerts ..........25 Function – Night light mode ......28 Function –...
-
Page 4: Conrad Connect
Conrad Connect Your product is compatible with the Conrad Connect IoT platform at www.conradconnect.de. You can set up a personal account at the given URL. Symbols The following instructional symbols are used in this instruction manual. This triangle indicates important instructions contained in these operating instructions that must be followed. -
Page 5: Core Functions
Core functions Measuring and recording Sensors measure and record illuminance, noise, pressure, temperature and humidity. Event monitoring Events are monitored and logged in the app. Examples include door/window sensor, motion detector, smart button. Alert mode You are alerted of events important to you. Night light mode Determine the behaviour of the gateway during the night. -
Page 6: App To Device Communication
App to device communication ■ In order to add a new device to the app, the mobile device that runs the app and the smart device must connect to your WLAN. ■ Once a new device was added, you can control the smart device through the app via WLAN or mobile network. -
Page 7: App – Installation
1. Head to the respective app store and download the app named 'Sygonix Home' onto your mobile device. 2. Set up a user account as outlined under App – User account. -
Page 8: App – User Account
App – User account A 'Sygonix' account is required for you to operate the smart device. Your smart device cannot be linked to two accounts at the same time. Adding the smart device to a second account will remove it from the first account. - Page 9 After logging out of your current account you can log in with a different one. Integrating with Conrad Connect Note that your 'Sygonix' account is independent of Conrad Connect. If you wish to integrate your smart device with Conrad Connect you require a separate Conrad Connect account.
-
Page 10: App – Landing
App – Landing page Account settings App settings Add new devices Device list Show Devices Show Scenes - 10 -... -
Page 11: App – Settings
App – Settings Touch to open app settings: Language Select app language Select currency Price Set the cost for one kWh Download operating Manual instructions See app version and available app updates. About Links to www.conrad.com www.conradconnect.de App – Updates App software updates are managed as other apps through the corresponding app store. -
Page 12: Smart Devices – Firmware Update
Smart devices – Firmware update The firmware of your smart device is updated via the app. Available firmware updates are indicated in the device settings. For all firmware updates the smart device and the mobile device that runs the app must be connected to the same WLAN network during the update. -
Page 13: Gateway – Add
Gateway – Add During set-up make sure to keep the mobile device running the app and the smart device within receiving distance of the wireless access point. 1. Connect your mobile device running the app to your WLAN network. 2. Open the app and navigate to the landing page. -
Page 14: Gateway – Gateway
Gateway – Gateway page Back to home Gateway settings Modes Sensor list Add a new sensor - 14 -... -
Page 15: Gateway – Settings
Gateway – Settings 1. Select a gateway from the device list on the landing page. 2. Touch to open the gateway settings. 3. Adjust settings: Name Give your gateway a name. Indicates the firmware version of the gateway. Firmware version Update firmware if updates are available. -
Page 16: Gateway – Indicator Light
Gateway – Indicator light Indications Observe the indicator lights during set up and use of your smart device. Indication Status/Action Fast blue flashing Ready to connect to (4 times per sec) network Stays blue for 5s Gateway successfully then off connected to router Slow blue flashing Connecting to network... - Page 17 Manual control The gateway indicator light can be turned on and off manually. Configure the manual control as follows: 1. Go to the app landing page. 2. Touch if it is not already selected. 3. Select the gateway from the device list. 4.
-
Page 18: Gateway – Reset
Gateway – Reset Attention! Resetting removes all configuration data in the gateway and any linked external sensors. Option 1 1. Select the gateway from the device list. 2. Touch 3. Touch Reset To Factory Settings 4. Confirm the prompt to reset. 5. -
Page 19: Sensors – Sensor Types
The gateway sensors cannot be removed. Sensors – Add sensor Only sensors compatible with the Sygonix Home Starter Kit can be added. Add sensor via App 1. Insert batteries into the sensor to power it 2. - Page 20 - If you attempt to add a sensor a second time, the instructions window does not Cancel < close. Touch to close, then reach the landing page. 7. Wait for the confirmation window, then touch 8. You will be asked to name the sensor. Enter a name and confirm.
-
Page 21: Sensors – Sensor
Rename a sensor 1. iOS: In the sensor device list, swipe left the sensor you want to rename, then touch Edit. Android: Hold down the sensor you want to rename, then touch Edit. 2. Enter a new name for the sensor and confirm the dialog. -
Page 22: Sensors – Delete Sensor
Logging For sensors that log trigger date and time, you can view the trigger history. Trigger time Sensors – Delete sensor Note that internal sensors (sensors built into the gateway) cannot be removed. 1. Go to the app landing page. 2. -
Page 23: Sensors – Configure Sensor
Sensors – Configure sensor Note that sensors that do not allow for parameter adjustment are not listed in the sensor configuration panel. 1. Go to the app landing page. 2. Touch if it is not already selected. 3. Select the gateway from the device list. Alert Mode. -
Page 24: Sensors – Enable/Disable Sensor
Sensors – Enable/disable sensor 1. Go to the app landing page. 2. Touch if it is not already selected. 3. Select the gateway from the device list. Alert Mode. 4. Touch 5. Touch the sensor you want to enable or disable. -
Page 25: Function – Alerts
Function – Alerts Status All alerts enabled All alerts disabled Disabling of alarms implies that all alarms, including alarms controlled through schedules (see Control alerts by schedule), are disabled. Control alerts by schedule 09:00 21:00 Receive Alerts 1. Go to the app landing page. 2. - Page 26 6. Touch Save. Save 7. Touch once more. Saving immediately enables or disables alerts, depending on your schedule. Listen for the signal sound. ■ To disable the schedule function, deselect all weekdays from the repeat pattern. Control alerts manually 1. Go to the app landing page. 2.
- Page 27 Confirm alerts on gateway Once a sensor is triggered, depending on the sensor settings, the gateway notifies you with colour, sound and push notification. Touch the button on the gateway to confirm and stop alerts. Also see chapter Function – Scenes.
-
Page 28: Function – Night Light Mode
Function – Night light mode Night light mode works in conjunction with the manual control of the gateway indicator light. See chapter Gateway – Indicator light. Option 1 – Without motion sensor When night falls, the gateway indicator light comes on, and goes off again when daylight is measured. - Page 29 ■ If motion is detected before the timer expires the timer is reset and restarted. Configure Night light mode 1. Go to the app landing page. 2. Touch if it is not already selected. 3. Select the gateway from the device list. Night Light Mode.
-
Page 30: Function – Alarm Clock
Function – Alarm clock Add alarm The alarm clock (Alarm Mode) has the function of a regular alarm clock and is configured as follows: 1. Go to the app landing page. 2. Touch if it is not already selected. 3. Select the gateway from the device list. 4. - Page 31 7. Touch Save. Alarm Mode, activate/deactivate the 8. Under alarm. Delete alarm 1. Go to the app landing page. 2. Touch if it is not already selected. 3. Select the gateway from the device list. 4. Touch Alarm Mode. 5. There are two ways to delete an alarm: - iOS: Swipe left the alarm you want to delete, then touch Delete.
-
Page 32: Function – Scenes
Function – Scenes A scene is a collection of procedures to be executed when triggered. Open scenes as follows: 1. Go to the app landing page. 2. Touch Default scenes Configurable Function Execute all actions when you leave home. Execute all actions when you return home. - Page 33 5. Touch . Set a timer that triggers the scene and its linked actions after expiry. Save 6. Touch to save the scene. Execute a scene In the Scenes panel, touch the scene you want to execute. Edit a scene 1.
- Page 34 This is a publication by Conrad Electronic SE, Klaus- Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
