Operating Instructions for analog transmitter MONITOR
Content
1 Introduction
.......................................... 1
2 Safety guidelines
................................. 1
3 Functional description
.......................... 1
4 Installation
............................................ 1
5 Device description
................................ 2
6 Programming
........................................ 2
7 Connection diagram and dimensions
... 2
8 Technical specifications
........................ 3
1 Introduction
The analog transmitter MONITOR is characterized by
reliable function and simple operation. In order to use
the advantages of this equipment in its entirety, please
consider the following:
Each person assigned to work on or operate this
equipment, must have read and understand the
Operating Instructions and in particular, the safety
references!
2 Safety guidelines
2.1 General information
To ensure safe operation, the device must be operated
only in accordance with the instructions in this manual.
Additionally, use of the device requires adherence to
all accident prevention-, legal regulations and safety
standards for the respective application.
2.2 Correct use in accordance
with these instructions
The analog transmitter MONITOR must only be used in
combination with the following flow monitoring- and flow
indicating devices from Meister Strömungstechnik:
DUM
DWM
RVM/U-1
RVM/U-2
RVM/U-4
DKM-1
DKM-2
DKME
DWM-L
RVM/U-L1
RVM/U-L2
RVM/U-L4
Any additional or different application, above and
beyond the correct use described in these instructions,
is deemed as incorrect use.
Meister Strömungstechnik GmbH
Tel. +49 6096 9720-0
Im Gewerbegebiet 2
Fax +49 6096 9720-30
DE-63831 Wiesen
-1-
2.3 Qualified personnel
Flow monitoring/metering devices equipped with the
analog transmitter MONITOR must only be installed by
qualified personnel, who are able to correctly employ
the device for its intended purpose. Qualified personnel
are persons who are familiar with the setup, assembly,
start-up, and correct use of these devices, and who
are able to independently carry out the work assigned
to them.
3 Functional description
The analog transmitter MONITOR detects the position
of magnetic floats or pistons with the aid of Hall-sen-
sors. An analog signal, appropriate to the position, is
provicled.
4 Installation
The analog transmitter MONITOR and the appropriate
flow sensor come pre-assembled. For installation into
the pipe system, please refer to the Operating Instruc-
tions for the flow sensor.
