Summary of Contents for DIGITALas DMV-M01
- Page 1 Monitor DMV-M01 User Manual...
- Page 2 Description Monitor DMV-M01 is a device designed for resident video conversation with guest. DMV-M01 should be installed indoors. It is possible to connect to monitor both addressable system (such as DD- 5000, DD-5100) and individual intercom module (SAC5C-CK). Monitor has hands free function.
- Page 3 Common wire (ground) should be connected to (-) contact of monitor (black wire). Video signal from doorphone: Video signal can be fed to monitor DMV-M01 over coaxial cable or twisted pair. If coaxial cable is used, shield of the cable should be connected to (-) contact of monitor in VIDEO segment, and...
- Page 4 should be according to which connection type (coaxial cable/twisted pair) is used. If coaxial cable is used jumpers coax1, coax2 and coax3 should be placed. If differential video signal is fed over twisted pair, non inverted signal caring wire should be connected to (+) contact of monitor in VIDEO section, and inverted to (-) contact.
