Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
Part. No.
Part. No.
31454379
31454379
Electric engine heater, 230 V
Electric engine heater, 230 V
Electric engine heater, 230 V- 31650137 - V1.4
5
5
5
5
Page 1 / 28
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Volvo 31454379
- Page 1 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Instruction No Instruction No Version Version Part. No. Part. No. 31650137 31650137 31454379 31454379 Electric engine heater, 230 V Electric engine heater, 230 V © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 2 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Special tools 951 2955 Cover Tool number:951 2955 Tool description:Cover Tool boards:20 951 2957 Coolant Reservoir Tool number:951 2957 Tool description:Coolant Reservoir Tool boards:20 Equipment IMG-345497 IMG-239664 IMG-240673 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 3 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-425505 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 3 / 28...
- Page 4 Certain steps in the instructions are only presented in the form of images. Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Preparation Open the hood. IMG-420320 Disconnecting the battery ©...
- Page 5 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-394535 Remove the battery's negative cable. Tightening torque: Battery cable for battery , 6 Nm IMG-425513 Removal © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 5 / 28...
- Page 6 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the marked part. IMG-422562 Remove the marked part. IMG-422563 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 6 / 28...
- Page 7 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Orientation view IMG-392033 Note! Close the drain cock after the coolant has drained. Place a container under the car. Drain the coolant. IMG-391976 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screws. Remove the marked part. IMG-422431 Remove the clips. Remove the screws. IMG-382204 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 8 / 28...
- Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the marked part. Use: Pliers IMG-403425 Remove the marked part. IMG-403428 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 9 / 28...
- Page 10 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the marked part. IMG-403430 Remove the screws. Remove the clips. IMG-382210 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 10 / 28...
- Page 11 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the nut. IMG-382280 Fold the wing liner to one side. IMG-382211 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 11 / 28...
- Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Orientation view IMG-391565 IMG-391573 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 12 / 28...
- Page 13 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the nut. The part is to be reused. IMG-391924 Remove the screw. IMG-412196 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 13 / 28...
- Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screw. IMG-412198 Fold marked part to one side. IMG-412199 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 14 / 28...
- Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Orientation view IMG-428776 Remove the screw. Release the catches. Remove the marked part. IMG-428775 Preparation © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 15 / 28...
- Page 16 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Measure and mark as illustrated. IMG-425328 IMG-425329 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 16 / 28...
- Page 17 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Adjust the hole with a file or knife as necessary. IMG-425330 Accessory installation IMG-412652 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 17 / 28...
- Page 18 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-430245 Tighten the nut. IMG-425506 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 18 / 28...
- Page 19 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Reinstall the removed part. IMG-428777 Install the clip(s). Tighten the cable tie. IMG-425507 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 19 / 28...
- Page 20 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Install the nut. IMG-392572 IMG-391930 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 20 / 28...
- Page 21 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the connectors. Install the catch. IMG-412700 IMG-425365 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 21 / 28...
- Page 22 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Install the clip(s). Tighten the cable tie. IMG-425366 Install the clip(s). Tighten the cable tie. IMG-419110 Vehicles with Power Pulse © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 23 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Tighten the cable tie. IMG-419071 All vehicles Hold the component in the position in which it is to be fitted and mark the hoses where they are to be cut. IMG-425906 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 24 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Caution! Cut carefully to avoid unintentional damage or personal injury. IMG-391395 IMG-391422 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 24 / 28...
- Page 25 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Tighten the screw. Tightening torque: M6 , 10 Nm IMG-391908 Remove the screw. The part is to be reused. IMG-391906 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 26 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fold marked part to one side. Install component that comes with the accessory kit. Tighten the screw. IMG-391910 Install component that comes with the accessory kit. Tighten the hose clamps. IMG-391420 © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4...
- Page 27 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Caution! No grease on contact surfaces. Lubricate the O-ring. IMG-391915 Connect the connector. Install the catch. IMG-391913 Installation © Volvo Car Corporation Electric engine heater, 230 V- 31650137 - V1.4 Page 27 / 28...
- Page 28 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Always follow the manufacturer's instructions when handling the equipment. Use special tool: T9512955, Cover Use special tool: T9512957, Coolant Reservoir Fill with coolant and run the engine to operating temperature. IMG-404661 Reinstall the removed parts in reverse order.
