- Page 1 RP101v2 Wireless Repeater Manual Guide...
- Page 2 Introduction Overview The RP101v2 is Wireless Repeater, you can use this device to ex- tend your existing Wireless network. Physical Details Figure 1: RP101v2 (Wireless Repeater) LEDs Power On – Power on / Normal operation. (Green) Off - No power.
- Page 3 Signal The connection between the RP101v2 and Root AP (access point) or Wireless Router. Quality (Repeater Off - No associate to Root AP (access point) or <-> AP) Wireless Router Green - The Wireless Link Rate is best Amber - The Wireless Link Rate is good...
- Page 4 Buttons WPS button (for Push Button Method only) button Establish a secure connection between the RP101v2 and Root AP (access point) or Wire- less Router or IP camera / Client station WPS between RP101v2 and IP camera / Client Station:...
- Page 5 3. Plug the RP101v2 into the AC power slot, then the Power will remain on. 4. Press the WPS button on the side panel of the RP101v2 and hold for greater than 8 seconds. The WPS LED blinks.
- Page 6 The RP101v2 (Wireless Repeater) is now ready for use. Connect with RP101v2’s Easy Setup You can use a web browser to connect to the RP101v2 and set it 1. Locate the RP101v2 near your Root AP (access point) or Wireless Router while doing the configuration.
- Page 7 6. Select a Wireless network to extend and click the Next button. 7. In the Password (Network Key) field, type the network pass- word (also called passphrase or security key) of Root AP (access point) or Wireless Router. Page 6...
- Page 8 8. In the Range Extender Name (SSID) field, type a name (SSID) for your RP101v2’s Wireless network and click the Next but- ton. Click the Save button, then the RP101v2 will reboot and the settings are applied. Page 7...
- Page 9 The RP101v2 (Wireless Repeater) is now ready for use. 10. Use a Wireless network manager on the computer or mobile device to connect to the RP101v2’s newly created Wireless network. Example : The wireless setting of RP101v2 is as below:...
-
Page 10: Specifications
Appendix A Specifications Network Camera Model Wireless Repeater Dimensions 40.7mm x 57mm x 91.7mm Operating Temperature 0 C to 40 C Frequency Band 2.4 G PHY Rate Up to 300 Mbps Storage Temperature -20 C to 70 C Network Protocols TCP/IP, HTTP, DHCP, NTP Network Interface 1 Ethernet 10/100BaseT LAN connection... - Page 11 Regulatory Approvals FCC Statement This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the in- structions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
- Page 12 (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunc- tion with any other antenna or transmitter. Page 11...
