For Intermediate & Advanced Fliers.
SAFETY PRECAUTIONS
This radio control model is not a toy!
Fist-time builders should seek advice from people having building
Experience in order to assemble the model correctly and to produce
Its performance to full extent.
Assemble this kit only in places out of children's reach!
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
Always keep this instruction manual ready at hand for quick
reference, even after completing the assembly.
Notice:
**This manual included Specification, Parts list in paper and CD full instruction manual.**
Before you read the CD. Please install Acrobat Reader. First.
"Acrobat Reader" logo are trademarks of Adobe Systems Incorporated
This Products Produce by P & D Products Company
3F., 94 HAK PO ST., KOWLOON, HONG KONG
TEL:852 8211 2461 FAX:852 8220 6288 E-mail: info@2krc.com http://www.2krc.com
Sold Agent in USA
5614 Franklin Pike Circle | Brentwood, TN 37027 USA
(615) 373-1444 http://www.hobby-lobby.com
Phone +
Hobby-Lobby International
:
Advertisement
Summary of Contents for 2KRC Voodoo
-
Page 1: Safety Precautions
“Acrobat Reader” logo are trademarks of Adobe Systems Incorporated This Products Produce by P & D Products Company 3F., 94 HAK PO ST., KOWLOON, HONG KONG TEL:852 8211 2461 FAX:852 8220 6288 E-mail: info@2krc.com http://www.2krc.com Sold Agent in USA Hobby-Lobby International 5614 Franklin Pike Circle | Brentwood, TN 37027 USA (615) 373-1444 http://www.hobby-lobby.com... - Page 2 Serious injury, destruction of property, or even death may result from this misuse of this product, 2KRC. is providing you, the buyer with a very high quality model aircraft component kit, from which you, the buyer, will assemble a flying model. However it is beyond our control to monitor the finished aircraft you produce.
- Page 3 Table of Contents Tail surface installation..…………………01-06 Tail plane……………………………………………01-05 Servo tray………………………..………07-10 Tail servo mounting…………………………………07-11 Receiver mounting………………………19-20 battery mounting……………………………………32-36 Servo and battery mounting…………….24-34 Tail control wire setup………………………………13-17 Motor mounting…………………………21-29 Spinner and prop…………………………26-29 Wing mount.…………………………………………48-49 Ailerons control install……...……………38-47 C.G. adjust……………………………………………….51 First install the Stab. In fuse. And mark the edge with marking tape, then use hobby knife made a line small hole on the cover surface of cover for ensure when you glue Stab with Fuse was good.
- Page 4 Install the Stab. Inside Fuse. And check alignment as show. Glue Stab. and Fuse in place with thick CA. or Epoxy as show. If use Epoxy please remove the marking tape before the glue complete dry, so you can get a clean surface. .install hinges inside Elevator And glue it with thin CA then install the Elevator To Stab.
- Page 5 Install the servo horn and on the Elevator then turn on the Radio to neutral the Elevator Servo. Drill a 1.9mm hole for the control wire adjuster 8mm from the center of the servo horn as show. Install the control wire adjuster and mount the Elevator Servo on the servo tray as show.
- Page 6 Cut Elev. Control hone as show. install the “ Z” push rod with control horn first then check the control wire was operation smooth or not when you install the wire and pre install Elevator Control horn. Before you ensure the control wire are operation smooth, please do not glue the control horn in anyway.
- Page 7 Ensure Elevator Control wire in right center inside the wire adjuster before you glue the Elevator Control horn. Check the Elevator And Elevator Servo all in neutral then fix the control wire with lock screw as show. Placing a good quality self adhesive hooks at the servo tray end for receiver.
- Page 8 Mount the receiver at the end of the servo tray as show. If you choice our “ATP SR40 260KV” BL motor. Or Hacker B40 motor. Please check there two differ pair mount hole on the motor, so please check the direction with this mount screw hole with fire wall and ensure the motor wire was on the low side in side the Fuse.
- Page 9 Please find the Alum. Spinner that supply with combo kit one and two. You need to re-open the prop. Hole to 8mm for this spinner. If you choice APC. Prop. You may need option wash to fit the prop at the top as show. If you choice Cam Prop.
- Page 10 please check that on place that spinner open hole for prop. Will not hit the prop in any place. If there any place has a hit. Please trim the spinner hole before you install the spinner and use. IMPORTANT NOTICE: IF THE SPINNER HIT THE PROP.
- Page 11 Install the ESC. inside the Fuse. as show. And made sure the battery plug will be at motor side as show. Install and check the battery that you choice are fit in side the Fuse as show. Mostly 2100 and 2200MA Lipo battery will fit this model.
- Page 12 Push the hatch forward till the wire end can be inside the battery open then backward the hatch to normal post see pic 37 Trim off covering film at Aileron Servo bay as show. Trim off cover film from servo wire out let at the wing center as show.
- Page 13 Use a long and thin wire for lead the servo extend wire from servo bay to wing center out let see pic.41 Made the Aileron servo extend wire out in both side of wing. Drill a 2mm hole for Aileron Push rod at the servo 10mm from center of the servo horn as show.
- Page 14 Cut Aileron Control hone as show. Glue to Aileron Horn according the push rod in line with thick CA. as show. Also fix the Aileron Servo with high quality double tape. Before you drill and install the Aileron Control horn please ensure the servo arm neutral point was around 1/3 forward when the radio was on.
- Page 15 Trim off covering from two wing bolt hole at wings penal as show. Mount wing penal with two nylon wing blot as show. After install battery fix the hatch as pic.36-37. CG. Point for this model was 55mm-60mm backward from LE. At wing root.
- Page 16 CODE:P001 & P002 Description Description WING SPAN Motor CLASS 1228mm SR40S-13 2600KV WING AREA 14.11 dm. TOTAL LENGTH 737mm MH 43 Modify AIR FOIL CENTER OF GRAVITY 55-60mm WING INCIDENCE 0 ° TOTAL WING AREA 16.2dm2 WING DIHEDRAL 2.5° STAB.AREA STAB.
- Page 17 P001 & P002 PART LIST Date: 2010/03/13 Description code size QUT′Y REMARK ￠4X14mm WING BOLT 2PCS SERVO FAIRING 1pair WING ￠1.8x28 Aileron push rod "Z" 2PCS PARTS ￠2 clevis 2PCS Aileron contorl horn 2PCS ￠1.2X360mm Elevator contorl push rod Elevator ￠2mm contorl wire adjuster parts...
