Hako Robotic Fusion-FX CLASSIC Parts Manual And Owners Manual

High speed burnisher with suction

Advertisement

Quick Links

Fusion-FX CLASSIC
HIGH SPEED BURNISHER WITH SUCTION
Hako Australia Pty Limited
ABN 43 002 858 059
90 Wetherill St North, SIlverwater NSW 2128
PO Box 6426, Silverwater NSW 1811
Telephone: +61 2 8756 4700 Fax: +61 2 8756 4799
Freecall within Australia: 1800 257 221
Email:
hksales@hakoaustralia.com.au
www.hakoaustralia.com.au
Parts Manual and Owners Guide
An ideal cleaning
solution from
Hako Rotobic.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fusion-FX CLASSIC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hako Robotic Fusion-FX CLASSIC

  • Page 1 Fusion-FX CLASSIC HIGH SPEED BURNISHER WITH SUCTION Parts Manual and Owners Guide Hako Australia Pty Limited ABN 43 002 858 059 An ideal cleaning solution from 90 Wetherill St North, SIlverwater NSW 2128 PO Box 6426, Silverwater NSW 1811 Hako Rotobic.
  • Page 2 Lugs  Remove 3” bolt from handle upright support lugs and repeat the above procedure. Pic 1 Fusion-FX Classic Handle Assy ELECTRICAL CONNECTION  Align 4 pin bayonet socket from handle with plug base on chassis, and lock into place, refer to Pic.2.
  • Page 3 PAD SIZE  Use 25mm thick, 50cm diameter synthetic high speed pads. Pads containing natural fibre may release odours which can be confused with Lock burning smells, and are not recommended. FITTING PADS  Raise the handle into an upright position and lay machine back onto the floor refer to Pic 5 ...
  • Page 4 START UP  Unwind the electrical cord and plug into power point.  Adjust handle to comfortable waist height refer to Pic 12  Check that the power indicator lamp is ON. Push  Push the Safety Interlock Lever forward to dis- Forward engage safety lock refer to Pic 9.
  • Page 5 (3) If the Red light occassionally flickers ON during operation, it is due to undulating floors and is not detrimental to the machine. (4) Once the height adjustment is set, the Fusion-FX Classic burnisher is operated in RED Lamp a straight forward motion at walking Indicator speed.
  • Page 6 PAD MAINTENANCE  Replace pads that are excessively worn, to reduce the risk of floor damage.  Wash pads on a regular basis and then store to dry.  Excessive amounts of polish or embedded in the pad will cause excessive drag that can over load the machine.
  • Page 7 HAZARD PRECAUTIONS Unplug electrical plug from the power point before conducting repair, service, maintenance or equipment cleaning. Electrical  Do not handle electrical plug or machine with wet hands and power connected.  Do not store machine outdoors or expose to rain. ...
  • Page 8: Specifications

    SPECIFICATIONS Main Motor Type: Induction 4 Pole CSCR Voltage and Frequency: 220 – 240 Volts a.c. / 50 – 60 Hz Power Output: 1500 watts @ 8.3 amps Vacuum Motor Type: Single stage Flo-Thru Voltage and Frequency: 220 – 240 Volts a.c. / 50 – 60 Hz Air Flow: 20 litres/sec Transmission...
  • Page 9 ELECTRICAL CIRCUIT DIAGRAM Fusion-FX Classic...
  • Page 10 CHASSIS FUSION-FX CLASSIC...
  • Page 11 FUSION-FX Classic Chassis Assembly Parts List ITEM PART ITEM PART DESCRIPTION DESCRIPTION 13250001 Filter Bag Polisher 167Dia x 125L PE 13380017 Screw No. 4 x 5/8 S/T Pan ZP 13330011 Nut Hex 1/4 Hex Steel ZP 13350002 Plate Gland Fusion-FX Classic...
  • Page 12 Fusion-FX ndustrial & ommercial Handle Part Name Part No. Part Name Part No. Handle Fusion-FX IC Assy 13277070 Bolt 5/16W x 1-1/2 Hex ZP 13210011 Handle Grip 13270005 Grommet Loom Cord 13260001 Pin M6 x 20 Dowell CP 13350010 Cord Polisher 3 Core 15m x 15A 13220007 Housing Handle Lower Fusion-FX IC 13270002...
  • Page 13 Hako Australia Pty Ltd Warranty Policy Effective July 1, 2008 Hako Australia Made Simple Limited Warrantly Policy Hako Australia Pty Ltd warrants to the original purchaser/user that the product is free from defects in workmanship and materials under normal use. Hako Australia Pty Ltd will, oblige under this warranty to repair or replace at our factory or authorised dealer service outlet, parts that fail under normal use and service when operated and maintained in accordance with the Parts Manual and Owners Guide, after examination discloses it to have been defective.
