Page 1: User Manual
USER MANUAL HDMI Wireless Extender Model No：HDEX0016M1 Enjoy the vivid world! REMARK Manufacturer does not make any commitment to update the information contained herein. - Page 2 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The products are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient.
-
Page 3: Package Contents
PACKAGE CONTENTS: 1. HDMI Wireless Transmitter 1pcs 4. IR Receiver cable 1pcs 2. HDMI Wireless Receiver 1pcs 5. User manual 1pcs 3. IR Transmitter cable 1pcs 6. DC power adapter 2pcs FEATURES OF THE INTERFACE: Transmitter (TX) POWER STATUS HDMI IR OUT HDMI IN HDMI OUT... - Page 4 OPERATIONG AND CONNECTION: 1.Connect one HDMI cable from the DVD/BD player into the HDMI input port of the HDMI wireless TX. 2.Connect one HDMI cable from TV/Monitor into the HDMI output port of the HDMI wireless RX. 3.Connect the IR Transmitter cable to the HDMI wireless TX and the IR Transmitter cable must face to the control target device.
- Page 5 first log in. Pls follow the below steps: 1. Connect 5V power supplies to the TX&RX, and inserted into the power socket. 2. Turn on the WLAN of the mobile phone / PC ， search and connect SSID： HDMI_Wireless, Enter the default password: 00000000 3.
- Page 6 Note: You have to do reset to sender and receive both first, then you can connect the Sender and receiver again. SPECIFICATIONS: HDEX0016M1 HDMI Compliance…………………………………..………………………………….. HDMI1.3/HDCP1.4 HDMI resolution ……………up to 1080P@50/60Hz&SVGA/XGA/WXGA/SXGA/WXGA+/UXGA/ WSXGA+/ WUXGA HDMI Audio Format……………………………………………………………………………….. LPCM2.0 HDMI Max bandwidth………………………………………………………….……………………...225MHz...
- Page 7 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
- Page 8 3. Co-channel interference. Pls select a new band or channel 1. Please adjust the angle of the antenna or adjust the placement Screen not fluent 2. Co-channel interference. Pls select a new band or channel 1. Please check the RX and TX power supply Can't login to the Web 2.
