Page 1 Part. T5852A User instructions ® 335828...
Page 2 PABX 28D Basic functions Keys to press Pulse-dialling telephone Touch-tone telephone Function Call an extension from 401 to 416 from 401 to 416 General internal call Call on outside telephone line with 0 + telephone number 0 + telephone number...
Page 3 Terraneo Quick guide For quick consultation the procedures used most frequently have been summarised in this guide. Main functions These functions require no specific programming or personalisation. The exchange is in basic configuration. Call an extension Call on outside telephone line General call Dosa service Put through and continue a conversation...
Page 4 PABX 28D Call an extension Call on outside telephone line 1. Lift the receiver; you will hear the start dialling 1. Lift the receiver. tone. 2. Press key 0. 2. CDial the number to call (from 401 to 408 or 3.
Page 5 Terraneo Put through and continue a conversation Put through and continue a conversation with pulse-dial telephone: with touch-tone telephone: 1. Dial the number to which the call is to be put 1. Press R. through. 2. Dial the number to which the call is to be put 2.
Page 6 PABX 28D Use of the short number phone book Repeat last number 1. Lift the receiver; you will hear the start dialling 1. Lift the receiver. tone. 2. Dial 50. 2. Dial 30XX, where XX indicates the 3. f the telephone line is free, the exchange dials...
Page 7 Terraneo GENERAL CONTENTS INTRODUCTION DESCRIPTION pag. MAIN FUNCTIONS BASIC CONFIGURATION pag. PERSONALISING THE SERVICES pag. MUSIC WHILE ON HOLD pag. HOUSE-AUTOMATION SCENARIOS pag. DOOR ENTRY CALLS pag. CALL AN EXTENSION pag. GENERAL EXTENSION CALL pag. CALL ON OUTSIDE TELEPHONE LINE pag.
Page 8 PABX 28D SERVICES IN “OFFICE” MODE ANSWER FOR ANOTHER EXTENSION pag. ANSWER WITH CALL CAPTURE pag. ANSWER ON NOTICE OF CALL pag. OPTIONAL PERSONALISATIONS INITIAL CONDITIONS pag. BASIC CONFIGURATION pag. ACCESS TO THE PROGRAMMING THROUGH EXTENSIONS pag. DISABLING TELEPHONES RECEIVING INCOMING TELEPHONE CALLS pag.
Page 9 Terraneo INTRODUCTION DESCRIPTION The telephone exchange can make systems for communication in homes and offices combining the telephone services with the door entry services. In the basic version it can manage 2 telephone lines, 2 door entry calls and up to 8 telephones. Another telephone can be connected in parallel to each telephone.
Page 10 PABX 28D MAIN FUNCTIONS BASIC CONFIGURATION The PABX telephone exchange is supplied with a “basic configuration” for “FAMILY” services, corresponding to the following: as a base the programming, temporary unlock and remote activation password is: 1 2 3 4; the exchange is set up for touch-tone telephone lines;...
Page 11 Terraneo MAIN FUNCTIONS DOOR ENTRY CALLS The telephone exchange can manage up to 2 separate door entry calls, which can be addressed separately on 2 groups of telephones (divisions). If activated the DOSA service can put through a door entry call, from an outdoor station, to a telephone number, both landline and mobile.
Page 12 PABX 28D MAIN FUNCTIONS EXAMPLE OF A SYSTEM WITH ONE DIVISION AND ONE DOOR ENTRY CALL In the basic configuration the exchange has just one division which can also manage a single door entry call. DOOR ENTRY EXTENSION EXTENSION OUTDOOR STATION FAX –...
Page 13 Terraneo MAIN FUNCTIONS EXAMPLE OF A SYSTEM WITH TWO DIVISIONS AND TWO DOOR ENTRY CALLS In single-family systems the exchange can be programmed to have two divisions to separate the calls and services (see “operation with 2 divisions” table) to the home itself from those, for example, of an office or workshop or other forming part of the same residential unit.
Page 14 PABX 28D 3.1 CALL AN EXTENSION This function can communicate with one of the telephones connected to the exchange, if the extension number is known. Lift the receiver, you will hear the start dialling tone. Dial the extension number to be called (from 401 to 408 or 416).
Page 15 Terraneo 3.2 GENERAL EXTENSION CALL This operation calls all the telephones (apart from those programmed as answering machine, modem and fax) at the same time and is useful when you are not sure where the person you are calling is. Lift the receiver;...
Page 16 PABX 28D 3.3 CALL ON OUTSIDE TELEPHONE LINE This operation can call an outside telephone, both landline and mobile. Lift the receiver; you will hear the start dialling tone. Press 0 for access to the available outside line (automatic search) or dial 11 or 12 to select outside telephone line 1 or 2.
Page 17 Terraneo 3.4 REPEAT LAST NUMBER CALLED ON OUTSIDE TELEPHONE LINE The exchange saves the last number called by each telephone on the outside telephone line. The procedure to call the last number is that described below: Lift the receiver; you will hear the start dialling tone.
Page 18 PABX 28D 3.5 USE OF THE SHORT NUMBER PHONE BOOK Up to 50 most frequently used telephone numbers can be saved in the phone book (see relevant chapter). These numbers can be sent to the telephone line by dialling 30XX, where XX (between 01 and 50) indicates the telephone number’s abbreviated code.
Page 19 Terraneo 3.6 AUTO-DIAL ON BUSY BETWEEN EXTENSIONS If on calling an extension you obtain the busy signal, you can book the call as follows: Busy signal after calling an extension. Dial 55 (on some telephones the R key is indicated with FLASH) Hang up and wait for the telephone to ring (short rings in quick sequence) Warning: this procedure is only valid with touch-tone telephones.
Page 20 PABX 28D 3.9 PUT A CONVERSATION (OUTSIDE OR DOOR ENTRY) ON HOLD During the conversation proceed as follows: Conversation in progress To put the caller on hold: with touch-tone telephone press with pulse-dial telephone press 1 While on hold the caller will hear music and the “please hold the line”...
Page 21 Terraneo 3.10 PUT AN OUTSIDE OR DOOR ENTRY CONVERSATION ON HOLD AND PUT IT THROUGH TO ANOTHER EXTENSION During the conversation proceed as follows: Conversation in progress To put the call through to an extension: with touch-tone telephone press followed by the extension number (e.g.
Page 22 PABX 28D 3.11 ANSWER ON NOTICE OF CALL If during a conversation another call (telephone or door entry) arrives the exchange sends a notice of call tone to the lifted receivers and the other enabled telephones ring. You can answer normally by lifting the receiver of one of the free telephones.
Page 23 Terraneo 3.12 CAPTURE CALL WITH ANSWERING MACHINE SERVICE A call sent to the answering machine can be intercepted using the “capture call” service. The extension programmed as answering machine works as follows: it does not ring during a general call it allows remote activation from an outside telephone line even if this is used by the answering machine sending the pre-recorded message The procedure to activate the service must be performed by another telephone assigned to the same...
Page 24 PABX 28D 3.13 DIRECT ACCESS TO THE OUTSIDE TELEPHONE LINE When the “direct access to the outside telephone line” service is activated, you can access the outside telephone line from any telephone connected to the telephone exchange by just lifting the receiver.
Page 25 Terraneo 3.14 TEMPORARY UNLOCKING OF PREFIXES This service can temporarily unlock the prefix lock on a telephone if set up in the programming phase. Dial 97 followed by the four figures of the password (base 1234) (e.g. 971234); If the password is not correct the exchange sends a time-out tone as an invitation to hang up. If the password is correct you will hear a dial tone, the prefix lock is now deactivated.
Page 26 PABX 28D...
Page 27 Terraneo DOOR ENTRY SERVICES 4.1 OPEN DOOR LOCK In systems with several outdoor stations, during the call and conversation, the command operates the door lock of the outdoor station from which the call was made. With an idle system (no call) instead it operates the door lock of the outdoor station configured as main.
Page 28 PABX 28D DOOR ENTRY SERVICES 4.3 SELF-SWITCHING ON OF THE OUTDOOR STATION This command allows you to hear and see (with video systems) what is happening at the outdoor station. Lift the receiver. Press the key with symbol (Self-switching on) if the telephone is of the Pivot series; press R61 if it is another telephone.
Page 29 Terraneo OTHERS SERVICES 5.1 REMOTE ACTIVATION OF DEVICES The PABX exchange can command the switching on and off of electrical devices by typing the codes on the extension keypad. If the PABX is suitably programmed the devices can also be switched on and off from an outside telephone making a call to the telephone line to which the PABX is connected.
Page 30 PABX 28D OTHERS SERVICES 5.2 MANAGEMENT OF DEVICES FROM AN EXTENSION Timed “impulsive” command Lift the receiver 991n Dial is the number of the relay to be operated from 0 to 8 e.g. 2) ON-OFF command Lift the receiver 991n...
Page 31 Terraneo OTHERS SERVICES 5.3 MANAGEMENT OF DEVICES FROM AN OUTSIDE TELEPHONE LINE Timed “impulsive” command Lift the receiver Dial the home number (outdoor telephone line to which the PABX is connected). After 6 rings you will hear music for 3 seconds. At the end of the music, dial the remote activation password (4 numbers, base 1234) and wait for the dial tone.
Page 32 PABX 28D OTHERS SERVICES ON-OFF command Lift the receiver Dial the home number. After 6 rings you will hear music for 3 seconds. At the end of the music, dial the remote activation password (4 numbers, base 1234) and wait for the dial tone. The password numbers must be different from those of any codes to operate other devices (e.g.
Page 33 Terraneo OTHERS SERVICES 5.4 CHECK DEVICE STATE Lift the receiver Dial the home number. After 6 rings you will hear music for 3 seconds. At the end of the music, dial the remote activation password (4 numbers, base 1234) and wait for the dial tone.
Page 34 PABX 28D OTHERS SERVICES NIGHT SERVICE – SWITCHING ALL THE CALLS TO TELEPHONES 401 AND 402 The exchange can be programmed so that all the telephone and door entry calls are sent just to telephones 401 and 402. Do this as follows: Lift the receiver Dial 312 to activate the night service.
Page 35 Terraneo OTHERS SERVICES 5.6 PUTTING THE DOOR ENTRY CALL THROUGH ON OUTSIDE TELEPHONE LINE (DOSA SERVICE) When the service is active, when there is a door entry call, as well as ringing the enabled extensions the exchange automatically dials a telephone number, landline or mobile, which the user has previously saved in the short number phone book, putting the call through to the outside.
Page 36 PABX 28D OTHERS SERVICES 5.7 AUDIO ROOM MONITOR The exchange can check a particular room listening to the noises captured by the telephone in the room (e.g.: check the sleep of the child sleeping in the bedroom). For this function a telephone must be set up as room monitor as follows:...
Page 37 Terraneo OTHERS SERVICES 5.8 OPERATION WITH 2 DIVISIONS Below is a brief description of the services available and how they work, for operation with two divisions: Service Operation Intercom Possible between extensions of different divisions Putting through a call Possible between extensions of different divisions General call Possible between extensions of the same division Answer for another extension...
Page 38 PABX 28D SERVICES IN “OFFICE” MODE If the exchange is programmed in “OFFICE” version it will behave like the basic “FAMILY” version apart from three services “Answer for another extension”, “Answer on notice of call (change caller)” and answer with call capture which will work differently.
Page 39 Terraneo SERVICES IN “OFFICE” MODE 6.3 ANSWER ON NOTICE OF CALL If during a conversation another call (telephone or door entry) arrives the exchange sends a notice of call tone to the lifted receivers and the other enabled telephones ring. Answer normally by lifting the receiver of one of the free telephones.
Page 40 PABX 28D SERVICES IN “OFFICE” MODE To put the second call through to another telephone proceed as follows: Press with touch-tone telephones or with pulse-dial telephones and dial the extension number required. Wait for the person called to answer. If the extension called is busy, or does not answer, the line can...
Page 41 Terraneo OPTIONAL PERSONALISATIONS The personalisation can be performed by manually typing the codes from the touch-tone telephone keypads. It is not possible with pulse-dial telephones. 7.1 INITIAL CONDITIONS The telephone exchange is supplied with a “basic configuration” for “FAMILY” services as described in the relevant section.
Page 42 PABX 28D OPTIONAL PERSONALISATIONS 7.4 DISABLING TELEPHONES RECEIVING INCOMING TELEPHONE CALLS This can define to which telephones the calls from the outside telephone line will be sent, or which extensions will ring when there is an incoming call and be able to answer this call.
Page 43 Terraneo OPTIONAL PERSONALISATIONS 7.5 DISABLING TELEPHONES RECEIVING OUTGOING TELEPHONE CALLS This personalisation defines which telephones can use the outside telephone line to make outgoing calls. In basic programming conditions all extensions are enabled to use the outside line. The personalisation procedure is the following: Link with house-automation scenario X which can be activated with command 31X (from 311 to 315)(see “Personalisation of house-automatic scenarios”...
Page 44 PABX 28D OPTIONAL PERSONALISATIONS 7.6 DISABLING TELEPHONES FOR DOOR ENTRY CALLS This personalisation defines which telephones can receive calls from the outdoor station. In basic programming conditions all the telephones can receive door entry calls. When there is an answering machine (modem or fax) it is useful to disable the receiving of door entry calls.
Page 45 Terraneo OPTIONAL PERSONALISATIONS 7.7 DISABLING TELEPHONES FOR DOOR ENTRY SERVICES This personalisation defines which telephones can open the electric door lock, switch on the staircase lights or auto-switch on the outdoor station (door entry services). In basic programming conditions all the telephones can perform the door entry services. The personalisation procedure is the following: Link with house-automation scenario X which can be activated with command 31X (from 311 to 315)(see “Personalisation of house-automatic scenarios”...
Page 46 PABX 28D OPTIONAL PERSONALISATIONS 7.8 MANAGING PREFIX LOCKS Activating dialling locks. This personalisation can define which telephone prefixes cannot be called from each extension. The locks are valid for all the telephone carriers programmed as described below. In basic programming conditions no prefix is locked.
Page 47 Terraneo OPTIONAL PERSONALISATIONS Activating locks on dialling programmed prefixes The procedure for locking programmed prefixes is the following: Lift the receiver Type the following commands in sequence: - 951 to activate the lock, - 950 to deactivate the lock Password e.g. 1234 - Number of the extension to lock (or unlock) between 01 and 16 e.g.
Page 48 PABX 28D OPTIONAL PERSONALISATIONS 7.9 ASSIGNING A NEW PERSONALISATION PASSWORD To assign a personalisation/programming password different from that supplied with the basic programming (1 2 3 4 ): Lift the receiver Perform the personalisation access procedure (sect. 7.3). Type the following sequence: Press four keys in succession to form the number which will be the new password.
Page 49 Terraneo OPTIONAL PERSONALISATIONS 7.10 ASSIGNING A NEW TEMPORARY UNLOCK AND REMOTE ACTIVATION PASSWORD To assign a temporary unlock password different from that supplied with the basic programming (1 2 3 4 ): Lift the receiver. Perform the personalisation access procedure (sect.
Page 50 PABX 28D OPTIONAL PERSONALISATIONS 7.11 ENTERING THE SHORT NUMBERS IN THE PHONE BOOK Fill in the short number/telephone number correspondence table. The telephone number must not contain code 0 of automatic dialling of the outside telephone line. Short number Telephone number...
Page 51 Terraneo OPTIONAL PERSONALISATIONS 7.11 ENTERING THE SHORT NUMBERS IN THE PHONE BOOK Lift the receiver. Dial sequence 36XXXX (where XXXX are the four numbers of the programming password). Wait for the dial tone. Dial the number: Short number from 01 to 50 Telephone number max 24 numbers yyyyyyyyyyyyyyyyyyyyyyyy Warning: 2-second pauses can be inserted with R during automatic dialling of the telephone...
Page 52 PABX 28D NOTE ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
Page 53 Terraneo MEMO CARD (remote activation reminder) Fill in the reminder below giving the data of the user associated with each relay (e.g. garden light), the mode of operation (impulsive or on-off), the telephone number to communicate with the exchange from outside telephone line and the password for access to remote activation.
Page 54 PABX 28D MEMO CARD (remote activation reminder) COMMANDS CODES Activation 991 + n Deactivation 990 + n Check 992 + n Device Relay belonging to number Exchange Module 1 Module 1 Module 1 Module 1 Module 2 Module 2 Module 2...
