  • Page 1 User Manual and Specifications for LC-40w Projector LTBL tech “Loss Prevention for the 21 Century” Add:702 Split Rail Drive·Brentwood,TN 37027615-400-2464 or 615-593-0510 www.ltbltech.com...
  • Page 2 Thank you for your purchase of the LC-40w LightCop Projector. Before installing and using your LC-40w projector, we would like to present some helpful information concerning use, specifications, and maintenance. Your LC-40w is a safety/warning sign projector whose efficiency in luminosity depends upon a reasonably reflective surface such as concrete.
  • Page 3 I. Technical Information about your LC-40w 1. Operational Voltage: Although your LightCop comes preinstalled with "Intelligent Power Translating Circuitry". Your unit is configured to function on 90v to120v AC Edison power. 2. Rated Frequency for optimal operation is 50 to 60Hz.
  • Page 4 1- Lens 2- Lock Nut 3- Mounting base of Lens 4- Radar Unit 5- Thermal Mgmt 6- Thumb Screw 7- Bracket 8- Screw Nut Figure-2 10- Logo Clamping Wire, 11- Glass Gobo Add:702 Split Rail Drive·Brentwood,TN 37027615-400-2464 or 615-593-0510 www.ltbltech.com...
  • Page 5 The LightCop will always be mounted overhead onto a Steel I-Beam. I-beam mounting information and procedure for mounting, including description of hardware is included. Utilize the Safety Tie-Off Cable as a secondary safety measure for mounting. Add:702 Split Rail Drive·Brentwood,TN 37027615-400-2464 or 615-593-0510 www.ltbltech.com...
  • Page 6 Thumb Screw- (6) on both sides of the bracket, and adjust the projection direction. 2. Gobo Replacement (see figure #2) Unscrew the nut- (8) and gasket, and open the front cover of lens (as Add:702 Split Rail Drive·Brentwood,TN 37027615-400-2464 or 615-593-0510 www.ltbltech.com...
  • Page 7 2. Working process: Turn on the Power, the image will be lit and work all the time. Turn on the switch for the Radar control, and this will activate the radar module to make the flash/warning sequence work: The gobo Add:702 Split Rail Drive·Brentwood,TN 37027615-400-2464 or 615-593-0510 www.ltbltech.com...
  • Page 8 7. Do not modify your LightCop or change components in any manner, as this will void your factory warranty. 8. Please turn off the unit immediately when a malfunction occurs, and Add:702 Split Rail Drive·Brentwood,TN 37027615-400-2464 or 615-593-0510 www.ltbltech.com...
  • Page 9 3. Check the operation of your projector regularly to avoid costly safety accidents in your workplace environment. VII. Contact Us: Address:LTBLtech, LLC, 702 Split Rail Drive, Brentwood,TN 37027 Tel: Mike Roddick·615-400-2464, or Mark Antony Wray·615-593-0510 Or catch us on the Web at:www.ltbltech.com...
