Hyundai Autonet

PNAV-3550 User's Manual

Thank you for purchasing the PONTUS navigation product.

This user's manual explains detailed methods of use regarding our product. For safety and efficiency,

make certain to become familiarized with the contents of this manual before using this product.

<FIG 1>

Logo Screen

CONTENTS

Chapter 1 Product Information

1. Product Introduction

2. Make certain to read before use

3. Caution when handling the CD

Chapter 2 Before use

1. What is included in the box

2. Names of each section

Chapter 3 Installation

1. Car Installation

Chapter 4 . Screen Explanation by each Mode and Basic Directions

1.NAVI Mode

2 AUDIO Mode

3 VIDEO Mode

4 PHOTO Mode

5 RECORD Mode

6. SD CARD Mode

7 Environment Setting

Chapter 5 Miscellaneous Issues

1. Data Upload & Download Methods Between a Computer and PNAV-3550

2. Upgrading Method for the System Palm ware

February 5, 2005

Jupiter English Manual

Table of Contents

Need help?

Do you have a question about the PNAV-3550 and is the answer not in the manual?

Questions and answers

Summary of Contents for PONTUS PNAV-3550

Page 1 3 VIDEO Mode 4 PHOTO Mode 5 RECORD Mode 6. SD CARD Mode 7 Environment Setting Chapter 5 Miscellaneous Issues 1. Data Upload & Download Methods Between a Computer and PNAV-3550 2. Upgrading Method for the System Palm ware February 5, 2005...
Page 2: Product Information
Hyundai Autonet Jupiter English Manual 3. Troubleshooting 4. Product Specifications 5. Technical Support & Product Warranty Chapter 1 Product Information 1. Product Introduction 2. Make certain to read before use 3. Caution when handling the CD 1. Product Information This product is a car navigation with MP3 player system. It is designed to be installed and used in vehicle. A GPS engine and an antenna have been mounted for car navigation along with an accurate digital map.
Page 3 Hyundai Autonet Jupiter English Manual [Understanding GPS] GPS used for commercial purposes will carry a distance error, on average, of 15 meters(convert to feet). In addition, the distance error reading when close to buildings, underpasses, overpasses, and others may be up to 100 meters(convert to feet). Please take this into consideration during use. [Warnings] - Do not install the device on top of the vehicle’s airbag.
Page 4: Caution When Handling The Cd
Hyundai Autonet Jupiter English Manual (Normal operating temperature: 32~131F) [Prohibited] -Do not use the device for long periods of time with the engine turned off. Prolonged use with the ignition off may cause the battery to discharge. -Do not apply metal window tint. Applying strong window tint to the window area in which the GPS Antenna is installed may cause instability in GPS data reception or errors.
Page 5: Before Use
Hyundai Autonet Jupiter English Manual Chapter 2 Before use 1. What is included in the box 2. Names of each section 1. What is included in the box After purchasing this product, open the packaging and see if any of the components listed below are damaged or missing.
Page 6 Hyundai Autonet Jupiter English Manual (1) USB Port : It is a port used to connect the main unit to a PC using a USB cable, which could be used for updating a map and uploading a data file. (2) MIC Port : It is a section that could record voice by inserting a microphone.
Page 7: Installation
Hyundai Autonet Jupiter English Manual [Cradle] (1) Power Connector : This supplies power to the Device through the vehicle 12 volt jack cable. If the power is not being supplied smoothly, check to see whether the area around the cradle connection or the device connection is dirty and clean if necessary.
Page 8: Car Installation
Hyundai Autonet Jupiter English Manual (1) Cradle Connector Section : This is the section which is inserted behind the cradle to make the product immobile. (2) Rotator : This is the section which allows the angle of the product to be set in accordance to the driver’s eyesight.
Page 9: Screen Explanation By Each Mode And Basic Directions
Hyundai Autonet Jupiter English Manual Follow these steps when installing the device in your vehicle. (1) Mount the mount stand against the front window of the vehicle. (2) Connect the top connector of the mount stand with the connector insertion behind the cradle. (3) Gently place the bottom side of the device on the bottom surface of the cradle and slowly insert inward until a “click”...
Page 10: Audio Mode
Hyundai Autonet Jupiter English Manual The screen will be moved to a relevant menu when selecting a desired picture among icons on a screen. 1. NAVI MODE REFER to SPACE MACHINE NAVI * After operating NAVI for the first time, it could be terminated when using a NAVI termination button only.
Page 11 Hyundai Autonet Jupiter English Manual ‘YES’- Playing the music file starting with the file heard when used previously. ‘NO’- Playing the new music file by opening a new file. The following search window will be open when selecting ‘NO’. 1) Previous Button: Moving to the immediate previous screen. 2) Check Box: Selecting relevant directories and files.
Page 12 Hyundai Autonet Jupiter English Manual 3) Upward/Downward Button: Moving upward/downward when searching for a file. * The checked file will be changed to yellow when it is selected, and the screen will be moved to the program execution screen when selecting the file once again. STOP Button: Moving to the main menu after completion.
Page 13: Video Mode
Hyundai Autonet Jupiter English Manual 3. VIDEO MODE Execution/Termination of the VIDEO PLAYER The VIDEO icon should be clicked at the main screen when wishing to execute the VIDEO PLAYER. The following two menus will appear when starting the VIDEO PLAYER. ‘YES’- Playing the movie file starting with the file seen when used previously.
Page 14 Hyundai Autonet Jupiter English Manual (Picture Correction) 1) Previous Button: Moving to the immediate previous screen. 3) Upward/Downward Button: Moving upward/downward when searching for a file. * The checked file will be changed to yellow when it is selected, and the screen will be switched to the VIDEO PLAYER screen when selecting the file once again.
Page 15 Hyundai Autonet Jupiter English Manual STOP Button: Moving to the main menu after completion. 2) REW Button: Moving backward fast while playing. 3) PLAY Button: Playing a selected file. 4) STOP Button: Stopping a file in the midst of playing.. 5) FF Button: Moving forward fast while playing.
Page 16 Hyundai Autonet Jupiter English Manual 4. PICTURE MODE STOP Button: Moving to the main menu after completion. 2) TOOL Button: Starting the environment setting menu. 3) PREVIOUS PICTURE Button: Moving to a previous picture. 4) NEXT PICTURE Button: Moving to a next picture.. 5) Counterclockwise Button: Rotating an image by 90 counterclockwise.
Page 17: Record Mode
Hyundai Autonet Jupiter English Manual 5. RECORD MODE Execution/Termination of the RECORDER The RECORD icon should be clicked at the main screen when wishing to execute the RECORDER. The RECORD MODE should be selected from the following screen. 1) Voice Record Button: Recording voice by using MIC. 2) Audio Record Button: Recording audio through the external output.
Page 18 Hyundai Autonet Jupiter English Manual STOP Button: Moving to the main menu after completion. 2) STOP Button: Stopping the recording. 3) RECORD Button: Starting the recording. 4) TOOL Button: Starting the environment setting menu. * Select the Environment Setting icon during the recording, and check the Power Auto Setting to OFF at the System Setting screen.
Page 19 Hyundai Autonet Jupiter English Manual STOP Button: Moving to the main menu after completion. 2) RECORD Button: Starting the recording. 3) STOP Button: Stopping the recording. 4) TOOL Button: Starting the environment setting menu. * Select the Environment Setting icon during the recording, and check the Power Auto Setting to OFF at the System Setting screen.
Page 20: Sd Card Mode
Hyundai Autonet Jupiter English Manual 6. SD CARD MODE <Picture: Main Menu> The SD CARD icon should be clicked at the main screen when wishing to execute the SD CARD <Picture: SD CARD Search Window> SD CARD PLAY MOVE COPY STOP Button: Moving to the main menu after completion.
Page 21: Environment Setting
Hyundai Autonet Jupiter English Manual 7 Environment Setting and FAQ The screen will be switched to the environment-setting menu when selecting the environment-setting icon at each PLAYER. 1) VIDEO OUT: Selecting either NTIC or PAL method for a scanning method. 2) Brightness: Adjusting the brightness of the LCD.
Page 22 Hyundai Autonet Jupiter English Manual 1) Video Record: Adjusting the recording quality when recording video. 2) Audio Record: Adjusting the recording quality when recording audio. February 5, 2005...
Page 23: Miscellaneous Issues
6. The large-capacity storage device will be registered at the computer browser. 7. COPY, PASTE or DEL files as if using the computer browser. * Note: Movie, music and picture files must be downloaded to the relevant directory of PNAV-3550. 2. Upgrading Method for the System Palm ware 1) Turn on the power supply of the product on.
Page 24 Hyundai Autonet Jupiter English Manual Cases when the power does not turn on when using only the internal battery source - Operations may stop if the remaining battery level becomes too low. In these cases, turn on the power after connecting the AC Adapter. Use only the AC Adapter which has been supplied with the device. Using other types of AC Adapters may cause operation malfunctions or damage to the device.
Page 25 Hyundai Autonet Jupiter English Manual longer periods of time. - Tunnels, underground parking structures, and high-rise buildings may cause decreased GPS reception performance. 3. Product Specifications 1) Unit Window CE 4.2 .NET Flash memory 64MB Display 3.5” TFT (Touch Screen) Size(mm) 123(W) * 77(H) * 32(D) Operating Temp.
Page 26 Hyundai Autonet Jupiter English Manual following telephone and fax numbers: (Tel)562-946-5000, (Fax)562-946-5004. 3) Warranty Service The Warranty period for the purchased product is 1 year. In order to receive service within the warranty period, apply for an RMA through our corporate website and then send us the product along with the RMA Code.
Page 27 Hyundai Autonet Jupiter English Manual FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This Device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
