Summary of Contents for Video Systems WB-8412SD

Page 1 User Manual 4 Ch Video Sever 1/33...
Page 2 WARINGS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC & ELETRIC CONDUCTIVE OBJECT THROUGH VENTILATION GRILLS. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK.
Page 3 Content PREFACE..............................4 PRODUCT SPECIFICATIONS ......................... 4 III. PRODUCT INSTALLATION........................6 ............................. 6 ONITOR ETTING ........................7 ARDWARE NSTALLATION IP A ............................8 SSIGNMENT ): ................... 12 NSTALL CTIVE CONTROL SETUP ONCE ONLY LIVE VIDEO.............................. 14 VIDEO SERVER CONFIGURATION ....................16 ..............................
Page 4: I. Preface
I. PREFACE This is a four channel MPEG-4/MJPEG Video Server with web server built-in. It encodes analogue signals of traditional cameras to digital signals; the users can monitor real-time video via IE browser. MPEG-4 compression format supports smooth video quality. Also, it supports USB backup. 2-way audio enables the user to have a video conference.
Page 5 Hardware ARM 9 ,32 bit RISC 64MB Video Input BNC x 4 Input Video Looping BNC x 4 Audio In/Out 1 in / 1 out (RCA type) Alarm Input Relay Out RS-485 X1, for PTZ control Power Lan: DC 12V 600mA / WLAN: DC 12V 700mA Dimensions (WxHxD) 218x44x202mm Network...
Page 6: Iii. Product Installation
Delete files Yes, can be deleted or overwrite Client system requirement Windows 2000, XP, 2003 IE 6.0 or above Hardware (Minimum) Intel-C1.6G, RAM: 256MB, Graphic Card: 32MB III. Product Installation A. Monitor Setting Right-Click on the desktop. Select “ Properties”. Change color quality to highest (32bit).
Page 7 B. Hardware Installation Connect power adaptor Connect Ethernet cable to Video Server iii. Connect Video Server to a computer or Local network. Ｂ-1 I/O Control Instruction I/O terminal connector – used in application, for e.g., motion detection, event triggering, alarm notifications. It provides the interface to: 1 Digital Input (GND+Alarm) –...
Page 8 Door/Window Contacts ALARM N.O./ N.C. Relay Output Connection ALARM N.O./ N.C. C. IP Assignment Use “IP Installer”, comes with CD, to assign the IP address of VIDEO SERVER. There are two languages for IP Installer： IPInstallerCht.exe: Chinese version IPInstallerEng.exe: English version iii.
Page 9 DHCP (Dynamic IP) Dial-up (PPPoE) Execute IP Installer Use Windows XP SP2 or newer version. If the following message popup, please click “Unblock.” The GUI of IP Installer： vii. IP Installer searches all IP deceives which connect with the internet and it lists all of them on the left side or the user can click “Search Device”...
Page 10 Please make sure the subnet of PC IP address and VIDEO SERVER IP address are the same. The same Subnet: VIDEO SERVER IP address: 192.168.1.210 PC IP address: 192.168.1.100 Different Subnets: VIDEO SERVER IP address: 192.168.2.210 PC IP address: 192.168.1.100 10/33...
Page 11 To Change PC IP address: Control Panel Network Connections Local Area Connection Properties Internet Protocol (TCP/IP) Properties Please make sure your Video Server and PC have the same Subnet. If not, please change Video Server subnet or PC IP subnet accordingly. A quick way to access remote monitoring is to left-click the mouse twice on a selected Video Server listed on “Device list”...
Page 12 Then, please key in the default “user name: admin” and “password: admin”. xii. After VIDEO SERVER reboot, click “Search Device” to research VIDEO SERVER. And, use IE Browser for live viewing. D. Install ActiveX control (setup once only) For the first time to view VIDEO SERVER via IE browser, it will request the user to install ActiveX.
Page 13 When popup the following dialogue box, click “Yes”. 13/33...
Page 14: Iv. Live Video
IV. Live Video After executing IE browser and typing the IP address of VIDEO SERVER, the following message will popup and request the user to input the user name and password. The default user name and password are “admin” and “admin.” When the user name and the password are correct, it will connect to VIDEO SERVER via IE Browser.
Page 15 ：Get into the administration page. ：Video Snapshot. Live Video. The user can click on each channel for single channel format. VIDEO SERVER supports 2-way audio. After click on “Chatting”, the user can use the microphone which connects with the PC to talk to the server side. Status and Function keys：...
Page 16: V. Video Server Configuration
V. VIDEO SERVER Configuration Click to get into the administration and click on to return to the live viewing as follows. 16/33...
Page 17 A. System System Setup Set up the video server name, select language, and the time on this video server. Sever name ： This is the video server name for the user to search on IP Installer. Select language：There are English, Traditional Chinese, and simplified Chinese.
Page 18 Anonymous User Login： Yes：Allow anonymous login. No：Require user name and password to login. Add user： Type the user name and password and then click on “Add/ Set”. Click on “Edit” or “Delete” to modify the user. iii. System update Update the firmware online. Click on “Browse…” to select the firmware. And then, click on “Upgrade.”...
Page 19 Other settings： Reboot system：Reboot the video server. Factory default：Recover all settings. 19/33...
Page 20: B.network
B.Network IP Setting VIDEO SERVER supports static IP and DHCP. DHCP：Use Dynamic Host Configuration Protocol to get all network parameters automatically. Static IP：Type IP address, subnet mask, gateway, and DNS. DNS： With DHCP, DNS will be assigned automatically. Static IP: Based on the network environment. Port：If the user uses the router, some ports have to be adjusted in case of conflict.
Page 21 Send mail after dialed：After this function is enabled, it will send an email to a specific mail account. For the mail setting, please refer to IV. “Mail and FTP” settings. iii. DDNS VIDEO SERVER supports DDNS. It uses dynamic IP to redirect IP and connect with the video sever.
Page 22 Camddns： Input user name. Schedule Update: Default 1440 minutes. Click on “Apply” on save. DDNS State： Updating: Information updating. Idle: Stop Service. DDNS registration successful, can now log by http://<username>.ddns.camddns.com: Register successfully. Update Failed, the name is already registered: The user name has already been used.
Page 23 because both use the same IP. If the user doesn’t unplug Ethernet cable, wireless setting can not be executed). Status of Wireless Networks； it can scan all wireless services. Wireless Setting： Mode：There are Infrastructure and Ad-hoc. Infrastructure is for connecting with the router. Ad-hoc is for connecting with PC. When the user uses Ad-hoc mode, there is “Channel”...
Page 24 『WEP』 Authentication：There are Open System and Shared Keys, it is based on different encryptions. This has to be the same as the Router’s setting. Encryption：There are 64 bits and 128 bits. This is based on Key Type based on the Router’s setting. Key Type：There are HEX and ASCII.
Page 25 25/33...
Page 26: C. M Ultimedia
C.Multimedia Image Setting Select each channel to control. iii. Adjust “Brightness”, “Contrast”, “Hue”, and “Saturation”. iv. Video Setting 26/33...
Page 27 Basic mode： Resolution： There are 3 resolutions to be adjusted. QCIF Quality： There are 5 qualities to be adjusted. The higher the quality is, the bigger the files size is. Video Format：MPEG4 or JPEG. Video System： It supports NTSC and PAL. Advanced Mode：...
Page 28 Resolution： There are 3 resolutions to be adjusted. QCIF Bitrate Control Mode： There are CBR﹝Constant Bit Rate﹞and VBR﹝Variable Bit Rate﹞. CBR；64Kbps~4Mbps。 VBR：Q=4~30。 If the bandwidth is smaller than CBR or VBR setup, it will cause legging and incomplete images. Video Frame Rate： The video refreshing rate per second.
Page 29 Video System：It supports NTSC and PAL. Audio: VIDEO SERVER supports 2-way audio. a. For the video server to local PC, select “Enabled” to enable this function. b. For local PC to the video server, click on “chatting” on IE browser. 29/33...
Page 30: D.event
D.Event VIDEO SERVER provides multiple event settings. Event Setting VIDEO SERVER supports one motion detection area on each channel. When the motion is triggered, it can send out the video to a certain email address or upload the video to FTP. If the user has a USB device, they can do USB backup.
Page 31 Input Setting： Input 1 Action：E-mail/ FTP/ Out1/ Out2/ Out3/ Out4/ Save to SD card. Input 2 Action：The same as Input 1. Subject：Default GPIO In Detected! Interval：Default 10 sec. Click on “Apply” to save. Output Setting：Mode Setting：OnOff Switch or Slide Switch. Click on “Apply”...
Page 32 To send out the video via mail or FTP, please set up the configuration first. iv. USB Storage Playback It will show the capacity of USB Device and the date of the video file. The user can choose a certain date to play back. The video file is with AVI format.
Page 33: Vi. Factory Default
video file to play back on Microsoft Media Player. To delete the video, check the video file and click on Del . When the USB device is full, it will remove the oldest video automatically. VI. Factory Default Unplug the power of the Video Server Please connect T+ to R+ in the back panel iii.
