Summary of Contents for Grants Automation e-Gate SWG-12V
- Page 1 User manUal e-Gate sWG-12V 12V Articulated Arm Swing Gate Operators...
- Page 2 Contents hoW to Use yoUr aUtomatiC Gate operator ..1 hoW the Controls Work ....2 hoW to manUally release the Gate ... 3 maintenanCe .
- Page 3 hoW to Use yoUr aUtomatiC Gate operator before using your automatic Gate always look to see if there is any person, pet or other obstruction (ie.Parked vehicle) in the path of the gate. always wait for the gate to fully open before driving or walking through.
- Page 4 hoW the Controls Work Button A will open the gate and then after a preset time (30 seconds unless changed) the gate will close automatically. Button B will open the gate and hold it open until Button B is clicked again. Buttons C and D are spares and can be programmed to either open a garage door fitted with an e-Gate receiver unit or open the gate part way to allow pedestrian access.
- Page 5 hoW to manUally release the Gate Using a Spanner Loosen the large bolt holding the Arm to the Operator Then push down on the arm to release it from it’s collar. Do not remove the bolt completely. The Gate can now be opened by Hand - 3 -...
- Page 6 maintenanCe For Battery operated versions the battery should be replaced every 5 years or sooner if it has ever been run flat. The operator uses a 12V 7Ah Gel Battery that is commonly used in alarm systems and general purpose. They can be purchased from Grant’s Automation or most Automotive parts suppliers, alarm suppliers, electronic and battery shops.
- Page 7 WirinG diaGram for battery e-Gate Control Board BlACK WarninG! 10A Fuse The Battery cables mUst be ConneCted the riGht Way 12V Gel Battery aroUnd! if not you may damage the control board. What happens if there is a poWer CUt? Battery operated versions will not be effected by a power cut unless it is longer than a few hours, then the gate should be manually operated until the power is restored and the battery has charged.
- Page 8 ChanGinG the remote Control battery The remote control uses a 12V Thin Battery 8mm diameter x 28mm long L828 type. slide it Undo the screw then lift the forward to in the back of the back half up free it from the remote control with a as far as you can front half without...
-
Page 9: Trouble Shooting
troUble shootinG operator not working at all - check power cord is plugged in and switched ON. Check fuse or circuit breaker for the gate is ON. For Battery versions if the power has been turned OFF and the battery has run flat the power must be turned ON and the operator left to charge over night before it is used.
