Summary of Contents for Pegasus Astro ULTIMATE POWERBOX
- Page 1 VERSION 1.1 SEPTEMBER 12, 2017 ULTIMATE POWERBOX PRODUCT MANUAL BY PEGASUS ASTRO [COMPANY ADDRESS]...
- Page 2 Thank you for purchasing our Pegasus Astro - Ultimate Powerbox. If you are tired of carrying multiple power packs and dealing with a mess of power and data cables, our Ultimate Powerbox, a sophisticated power control unit, is the absolute solution. Our idea is one enclosure that makes available a sufficient number of amperes. No cables disturb the movements of the mount and the instrument, only the main power cord and one USB data cord comes to the Ultimate Powerbox from which branch off the other cables powering all devices.
- Page 3 Insert the 2.5mm plug on the DC power cable. Controller will initialize and the status LED will turn red after 4 seconds. (The 4 seconds wait time duration is on purpose for a new firmware upload process) USB2 HUB 9/12/2017 Ultimate Powerbox...
- Page 4 POWER OUTPUTS Ultimate Powerbox has four (4) 12V DC output. Each output includes a Smart Mosfet, capable to deliver up to 6 Amps of current. These mosfet incorporates a broad range of smart features like diagnose and protection.
- Page 5 PTC fuse is installed inside the controller to avoid any overcurrent issue with the connected stepper motors. An RJ12 connector is located at the back of the Ultimate Powerbox. Pinout can be seen at the following table: UNIPOLAR STEPPER MOTOR (RJ12) CONNECTOR...
- Page 6 We advise to buddle the UPB with a Compute PC Stick or a small PC cube. These tiny computers have (nowadays) sufficient power for your astrophotography requirements. • It is wise to select and use good quality and short length USB cables. 9/12/2017 Ultimate Powerbox...
- Page 7 AWG 18 cable. Make also sure that you do not exceed 3m to reduce voltage drops. I would like to use the Ultimate Powerbox to my We have good news for you. The device has a remote observatory.
- Page 8 6th USB hub port to supply it with enough power juice and you have your tiny PC up and running! If you don't like it after some time, buy another one with higher specs 9/12/2017 Ultimate Powerbox...
