Summary of Contents for EarthLinked Technologies Prime-025
- Page 1 Prime Series PSD Geothermal Heating and Cooling System Quick-Start Instructions PSD-QS (02/16) ©2016 EarthLinked Technologies, Inc.
- Page 2 Table of Contents List of Revisions ..........................4 M odel Nom enclature ........................5 Safety ..............................6 Equipm ent M anuals ......................... 6 Installation ............................7 1) Component Matching ....................... 7 2) Compressor Unit Placement ....................8 3) Refrigeration ..........................9 4) System Applications and Electrical ..................
- Page 3 List of Figures Figure 1. Matching Component Model Numbers .................. 7 Figure 2. General Layout of System Components ................8 Figure 3. Compressor Unit Bracket Installation ..................9 Figure 4. Compressor Unit Clearance ....................9 Figure 5. PSD Connections ....................... 10 Figure 6.
-
Page 4: List Of Revisions
Figure 34. Compressor Motor Circuit Testing..................47 Figure 35. Compressor Motor Grounded Winding Test ..............48 Figure 36. System Troubleshooting Chart ..................49 List of Revisions Revised electrical drawings Revised charging method due to elimination of TXV Removed the requirement to add 1,000 BTUH to the Heating Load for each occupant if domestic water heating by Heat Recovery Module (HRM) is part of the system. -
Page 5: M Odel Nom Enclature
Earthlinked Technologies. Installation and service must be made in accordance with the instructions set forth in this manual. Failure to provide installation and service by an ETI authorized installer in a manner consistent with this manual will void and nullify the limited warranty coverage for the system. -
Page 6: Safety
Safety Warning, Caution and Important notices appear throughout the manual. Read these items carefully before attempting installation, servicing or troubleshooting the equipment. IMPORTANT! Notification of installation, operation or maintenance information which is important, but which is not hazardous. WARNING! Indicates a hazardous situation, which if not avoided will result in serious injury or death, or equipment or property damage. -
Page 7: Installation
Installation 1) Component Matching Upon receipt of the equipment, carefully check the component model numbers by referencing Figure 1, to ensure that all components of the system match. Air Handler Cased Coil Prime Hybrid Cooling Compress. Earth Loop Arcoaire Arcoaire Module Unit Model... -
Page 8: Compressor Unit Placement
Figure 2. General Layout of System Components 2) Compressor Unit Placement ® EarthLinked compressor units may be located inside or outside. If outside, place compressor unit on a standard HVAC outdoor unit pad. If inside, place it on a level, hard surface. -
Page 9: Refrigeration
Figure 3. Compressor Unit Bracket Installation Figure 4. Compressor Unit Clearance ® Placement instructions for other pieces of equipment that make up the EarthLinked System are included with those pieces of equipment and are listed in this manual under Equipment Manuals. 3) Refrigeration ®... -
Page 10: Figure 5. Psd Connections
SIZE, INCHES TYPE OF PORT FUNCTION CONNECTION -025 -030 -036 -040 -050 -060 1-1/4” Hole Electrical, Power 7/8” Hole Electrical, Control AH/CC/HWM Liquid Braze EL Liquid* Braze Anode Socket EL Vapor* Braze AH/CC/HWM Vapor Braze DWT Supply Braze DWT Return Braze Electrical, control Electrical, control... - Page 11 Compressor units are shipped from the factory with a low pressure nitrogen holding charge. Carefully relieve the holding charge when the compressor unit is being prepared to connect refrigerant system piping. Caution! This compressor unit is equipped with Copeland Ultra 32-3MAF Polyol Ester Oil (POE).
-
Page 12: Figure 6. Line Set Sizes
The compressor unit has factory installed service valves on the earth loop vapor and liquid stubouts, outside the compressor unit. For the installation of system components requiring refrigeration connections, refer to Figure 6 for line set sizes and the appropriate installation manual(s) following Figure 6. LINE SET ADAPTERS REQUIRED FOR THE AIR HANDLER, CASED COIL, HYDROINIC WATER MODULE AND DOMESTIC WATER MODULE ARE FIELD SUPPLIED. -
Page 13: System Applications And Electrical
4) System Applications and Electrical The PSD compressor unit electrical box major components and electric data for all compressor sizes are shown in Figure 7. The SureStart Module is a factory installed component that (1) reduces compressor starting current and (2) reduces compressor starting torque, thus reducing stress on the compressor at start-up. The Earth Loop Protection Control System, comprised of the EPS Power Supply, EPS Module and EPS Fuse is in the contained within the electric box. -
Page 14: Figure 7. Psd Electric Box Components & Electrical Data
Voltage Compressor Compressor Voltage/Phase/ Unit Model Model Min. Max. -025-1C ZPS26K5E-PFV 230-1-60 73.0 14.6 18.0 -025-2C ZPS26K5E-TF5 230-3-60 58.0 12.0 -030-1C ZPS30K5E-PFV 230-1-60 83.0 17.0 21.0 -030-2C ZPS30K5E-TF5 230-3-60 73.0 12.9 16.0 -036-1C ZPS35K5E-PFV 230-1-60 96.0 20.0 25.0 -036-2C ZPS35K5E-TF5 230-3-60 88.0 15.8... -
Page 15: Figure 8. Psd Compressor Unit Electrical Schematic, 230-1-60
Figure 8. PSD Compressor Unit Electrical Schematic, 230-1-60 PSD-QS (02/16) Page 15... -
Page 16: Figure 9. Psd Compressor Unit Electrical Schematic, 230-3-60
Figure 9. PSD Compressor Unit Electrical Schematic, 230-3-60 PSD-QS (02/16) Page 16... -
Page 17: Figure 10. Psd Air Heating/Cooling/Water Heating Application
Figure 10. PSD Air Heating/Cooling/Water Heating Application PSD-QS (02/16) Page 17... -
Page 18: Figure 11. Psd Air Heating/Coolingwater Heating Field Wiring Diagram
Figure 11. PSD Air Heating/CoolingWater Heating Field Wiring Diagram PSD-QS (02/16) Page 18... -
Page 19: Surestart
5) SureStart Features SureStart is a factory installed soft starter that reduces light flicker caused at start-up by scroll compressor motors. This control has the following features: 60 to 70% reduction in direct in-rush current Under voltage protection ... -
Page 20: Figure 11A. Surestart Mode Of Operation
Figure 11a. SureStart Mode of Operation PSD-QS (02/16) Page 20... -
Page 21: Flash Codes – Single Phase
Flash Codes – Single Phase LED Flash Codes A Red LED indicator will flash under the following conditions. [NOTE: LED fault indicator is turned off in normal running mode.] a) Rapid Flash (10 / sec) : Low Voltage b) Triple Flash Every Three Seconds (3 / 3 secs): Lockout on Three Failed Starts c) Slow Flash (1 / 3 secs): Lockout on Over Current d) Slow Steady Flash (1 / sec): Cycle Delay / Fault Mode Flash Code (Rapid Flash (10 / sec) : Low Voltage) -
Page 22: Flash Codes – Three Phase
Flash Codes – Three Phase A Red LED indicator will flash under the following conditions. [NOTE: LED fault indicator is turned off in normal running mode.] a) Reverse Phase: (1 / 2 secs) b) Fault Mode/Cycle Delay: (1 / 4 secs) c) Low Voltage/Over Voltage: 2 / 2 secs) Flash Code (Reverse Phase: (1 / 2 secs)) Displayed if the supply “Phase Sequence”... -
Page 23: Internal Heat Recovery System
6) Internal Heat Recovery System The PSD compressor unit has a built-in heat recovery system which provides supplemental domestic water heating at a significant operating cost savings. The heat recovery system operates throughout the year to provide free hot water when operating in cooling mode and reduced cost hot water when operating in the heating mode. -
Page 24: Figure 13A. Gste Storage Water Heater - Service Connections
Figure 13a. GSTE Storage Water Heater - Service Connections Figure 13b. GSTE Storage Water Heater – Tank Top View PSD-QS (02/16) Page 24... - Page 25 The PSD compressor unit internal heat recovery system contains a water high temperature control. It is factory set to 140°F. The heat recovery system also contains a refrigerant low temperature which is factory set to 130°F. Also, a freeze protection control is designed to operate the circulating pump when water temperature drops to 40°F, in order to provide water circulation independent of compressor operation.
-
Page 26: Earth Loop Protection System
Earth Loop Protection System 1) Anode Wire Installation Prior to this, the below grade installation of the DIRECT AXXESS® Earth Loop System, including the Earth Loop Protection System anode and anode wire has been completed per the Earth Loop Protection Kit Manual, and at this point the anode wire is ready to be connected to the compressor unit. -
Page 27: Figure 15. Disassembled Plug Connector
Figure 15. Disassembled Plug Connector PSD-QS (02/16) Page 27... -
Page 28: Figure 16. Anode Wire Insertion
Strip the insulation from the multi-strand anode wire back approximately ¾ inch from the end and, while keeping the strands together, push the anode wire through the gland nut, gland cage, gland and plug body as shown in Figure 16. Loosen one of the two screw terminals on the plug insert to receive all of the strands of anode wire on one terminal. -
Page 29: Figure 17. Install The Plug Insert
Figure 17. Install the Plug Insert Slide the gland forward on the anode wire until it is firmly seated in the plug body as shown in Figure 18. Next, slide the gland cage over the gland, and slide the gland nut firmly against the gland cage, with the gland nut against the plug body. -
Page 30: Figure 19. Secure The Anode Wire
Once the gland nut has been hand tightened into the plug body, use two adjustable wrenches to further tighten the gland nut until it is snug in the plug body as shown in Figure 19 and the anode wire is held firmly in the plug body and will not slip out. Do not over-tighten the gland nut! Figure 19. -
Page 31: Eps Operation And Service
2) EPS Operation and Service Reference Figure 21 for the EPS components in the compressor unit electric box. Figure 21. Electric Box with EPS Components With power ON, and viewing the EPS Module in the compressor unit electric box, the EPS green light should be illuminated, indicating there is power to the EPS system. -
Page 32: Current Verification
3) Current Verification If it is necessary to verify the current flow through the EPS system, it can be checked with a digital DC ammeter set on the Milliampere scale. The correct electrical currents for nominal system capacities are listed in Figure 22. Nominal System Capacity, Tons Current Rating 1.5 thru 2.5... -
Page 33: Start-Up Process
Start-Up Process System Leak Check CAUTION! During the Evacuation and Initial Charging processes, be sure that ALL ® power to the EarthLinked System is OFF. This includes the compressor unit, air handler and all other electrically powered system components. Failure to do so will cause lockout on start-up. After all indoor and outdoor refrigerant bearing components of the system have been installed and joints have been nitrogen brazed, pressurize the system prior to evacuation to leak test the system. -
Page 34: Figure 24. Psd Internal Flow Schematic
Figure 24. PSD Internal Flow Schematic PSD-QS (02/16) Page 34... -
Page 35: Figure 25. Psd Piping
Figure 25. PSD Piping PSD-QS (02/16) Page 35... -
Page 36: Evacuation
Evacuation Refer to Figure 26 and the following procedure: 1. Carefully vent any pressurized nitrogen charge from the compressor unit and system.. 2. After venting the pressurized system, use a good quality gage manifold and a non-permeable hose set as shown in Figure 26. If possible, use two Schrader core removal tools. Install one on the discharge line access port and the other on the initial charging port. -
Page 37: Figure 26. Evacuation Of Psd System
Figure 26. Evacuation of PSD System PSD-QS (02/16) Page 37... -
Page 38: Initial Charge
Initial Charge 1. Disconnect the vacuum pump and isolate the digital vacuum gage. Connect the refrigerant container to the charging hose of the manifold gage set as shown in Figure 27. WARNING! Inhalation of high concentrations of refrigerant gas vapor is harmful and may cause heart irregularities or death. -
Page 39: Figure 27. Initial Charge Of Psd System
Figure 27. Initial Charge of PSD System PSD-QS (02/16) Page 39... -
Page 40: Final Charge
Final Charge 1. Remove the Schrader core tool from the hose just taken off of the initial charging port. 2. Crack open the LP valve on the manifold gage set so that a small amount of refrigerant gas flows to purge the hose. Connect the hose to the final charging port, shown in Figure 28. Tighten the hose to the final charging port and turn off the LP valve when the hose connection is secure. -
Page 41: Figure 28. Final Charge Of Psd System
Figure 28. Final Charge of PSD System PSD-QS (02/16) Page 41... -
Page 42: Figure 29. Charging To The Middle Sight Glass
Figure 29. Charging to the Middle Sight Glass Figure 30. Charging to the Top Sight Glass PSD-QS (02/16) Page 42... -
Page 43: Figure 31. Pressure-Temperature For R-410A
TEMPERATURE PRESSURE TEMPERATURE PRESSURE (°F) (psig) (°F) (psig) 26.1 199.2 30.8 216.1 35.9 234.0 41.5 253.0 47.5 273.0 54.1 294.1 61.2 316.4 68.8 339.9 77.1 364.6 86.0 390.5 95.5 417.7 105.7 446.3 116.6 476.3 128.3 507.6 140.8 540.5 154.1 574.8 168.2 610.6 183.2... -
Page 44: Figure 32. Start-Up Process
Figure 32. Start-Up Process PSD-QS (02/16) Page 44... -
Page 45: Troubleshooting
Troubleshooting CAUTION! SERVICE MAY BE PERFORMED ONLY BY AN EARTHLINKED TECHNOLOGIES AUTHORIZED PROFESSIONAL HVAC OR REFRIGERATION SERVICE PERSON. USE ONLY SAFE AND APPROVED SERVICE TECHNIQUES. IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, MAINTENANCE OR SERVICE CAN CAUSE 1) THE ® EARTHLINKED SYSTEM OR COMPONENTS TO MALFUNCTION AND OR FAIL, 2) PROPERTY DAMAGE, INJURY OR DEATH. -
Page 46: Figure 33. Compressor Unit Voltage Information
Figure 33. Compressor Unit Voltage Information The following compressor checklist is provided to analyze the compressor and determine if it is operating properly or if it is faulty: 1. Electrical Service Panel – turn power off. a. Check circuit connections for tightness b. - Page 47 Note: Feel the top of the compressor to see if it has overheated. If it is hot, the internal overload may be open. You may have to wait several hours for it to reset before proceeding. If the compressor draws a high amperage and does not start (amperage is approximately locked rotor amperage –...
- Page 48 Test the compressor motor for a grounded winding. The check should be made using an ohmmeter capable of measuring very high resistance on a VOM. The resistance between windings and the housing is one million to three million ohms for an ungrounded winding.
-
Page 49: System
2) System Problem / Likely Cause(s) Correction Symptom 1. Adjust thermostat settings. / Replace 1. Thermostat fault. thermostat. A. System does not run. 2. Power supply problem (AHU / 2. Check power supply for adequate compressor unit). phase and voltage. Check wiring to system and external breakers or fuses. - Page 50 C. System blows 4. Excessively high or low supply 4. Note voltage range limitations specific fuses or trips voltage or phase loss (3 only). to the compressor. circuit breaker 5. Faulty run capacitor or soft start 5. Replace as necessary. (con’t) components.
- Page 51 7. Refrigerant undercharged. 7. Check for refrigerant level in G. Uncomfortable ACC.(Heating mode only) temperature. Repair leak, evacuate and recharge the (Not enough system. Check In-line sight glass in heat/cold air) cooling mode. (cont’d) 8. Restriction in refrigerant circuit. 8. Check for blockage or restriction, especially in Liquid Flow Control.
-
Page 52: Com M Issioning Docum Ent
Commissioning Document The document that follows (LIT-170) enables verification and documentation of system component model numbers, location of underground system components and system performance for air and hydronic heating and cooling. PSD-QS (02/16) Page 52... - Page 53 PSD-QS (02/16) Page 53...
- Page 54 PSD-QS (02/16) Page 54...
- Page 55 PSD-QS (02/16) Page 55...
- Page 56 PSD-QS (02/16) Page 56...
- Page 57 PSD-QS (02/16) Page 57...
- Page 58 PSD-QS (02/16) Page 58...
-
Page 59: Tools And Equipm Ent
Tools and Equipment The purpose of the following list is to highlight key pieces of equipment, tools and materials necessary ® for the installation, maintenance and servicing of EarthLinked Heating and Cooling System HVAC (above ground) equipment. The professional HVAC technician is expected to have a compliment of standard tools for the general servicing of refrigeration equipment. -
Page 60: Triple Evacuation
Triple Evacuation Triple evacuation is implemented to evacuate a system to a deep vacuum. It is accomplished by evacuating a system to a vacuum of 1500 microns, and then bleeding a small amount of dry nitrogen into the system. The nitrogen is then blown out to the atmosphere. The system is then evacuated until the vacuum is again reduced to 1500 microns.
