00 Getting the software
01 Getting started
02 Getting connected to a smartphone
03 Recording data without a smartphone
04 Getting synchronized with your computer
05 Reviewing your data
06 Getting around
Empatica has currently four products.
Empatica
E3: wrist bracelet that measures physiological data
•
Empatica
Connect: cloud platform for getting and reviewing the data.
•
•
Empatica
Realtime: Iphone application that visualize data in realtime.
•
Empatica
Manager: Desktop software that facilitates the transfer of data between the device and the cloud
When using the E3 you can collect data in two ways by combining the products above.
With a mobile
phone: you will use the realtime application to collect the data on the phone that then transfer
•
the data to the cloud.
Without a mobile
•
memory to the cloud.
In both the two situations the data are transferred to the cloud platform called
visualizing or getting the recorded data.
E3 Quick setup guide
Rev 002 22 Apr 2014
phone: you will use the Empatica manager to transfer the data recorded in the E3's internal
Connect
© Empatica 2012
that will be the final tool for
Advertisement
Summary of Contents for Empatica E3
- Page 1 Empatica Manager: Desktop software that facilitates the transfer of data between the device and the cloud When using the E3 you can collect data in two ways by combining the products above. With a mobile phone: you will use the realtime application to collect the data on the phone that then transfer •...
- Page 2 Download the Empatica Realtime application from the App store if your have an iphone 4s or above and you want to record your data with it. First search for Empatica Realtime and then install the app © Empatica 2013...
- Page 3 Download the Empatica Manager for Desktop Below are the links where you can download them Win ] https://dl.dropboxusercontent.com/u/1421169/SetupEmpatica_0.1.3_driver_dotnet.zip [Mac os X ] https://dl.dropboxusercontent.com/u/1421169/EmpaticaManager-0.3.dmg Install the Empatica Manager © Empatica 2013...
-
Page 4: Getting Started
You can try to turn the E3 off with the same normal pressure. When you start to turn it off, as soon as you click the button the led •... - Page 5 Recording data without a smartphone section or Getting synchronized with your computer. Green yellow means that the E3 is getting discharged. If you see this combination and any other color please see the Getting • around section © Empatica 2013...
- Page 6 Getting connected to a smartphone Open the Empatica Realtime Application, log in with your user name and password then click on start new session. After few seconds a list of discovered devices appears. Then click in on the device to which you want to connect The E3 must be in the stand by state to be discoverable by your iphone.
- Page 7 When you are done with the recording, go back to the initial screen, press the X to stop the acquisition and then press OK. After disconnection the recorded data are transfered to the cloud. Be sure you have an active internet connection. © Empatica 2013...
- Page 8 Data are stored in the internal memory of the E3 and can be synchronized later to your computer. The Red light goes off after few second but the E3 is still recording. You know this by looking at the Sensors led below the case that are on.
- Page 9 Log in with your user name and password Plug the USB cable to your E3, be sure that the E3 is in a OFF state. The status led is off and the sensors led in the bottom part of the case are off. This is important for the correct functioning of the Empatica Manager.
- Page 10 Connect. It may happen that the Manager does not recognize the E3 properly. If this happens you can switch the E3 off with a normal pressure keeping it plugged. Close the Empatica Manager application. Open the Empatica Manager again and switch on the E3 manually with a normal pressure.
- Page 11 Review your data Go to the connect platform at www.empatica.com/connect and login Click Session list button to display all your data. The firs in the list is your latest recording © Empatica 2013...
- Page 12 Click View on one of your sessions to see the data © Empatica 2013...
- Page 13 Getting around Charge the E3 by plugging it into the USB port of your computer. Be sure that the Empatica Manager is not running otherwise the synchronization process will start. You can also use an external usb charger that can provide at least 200 mAh of current.
