One Touch X100 Quick Start

One Touch X100 HSDPA USB MODEM

1 About WIRELESS USB MODEM

WIRELESS USB MODEM is a kind of Internet equipment customized for mobile
working and entertainment, which allows the user connect to Internet
conveniently.

2 Installation

Insert (U)SIM card
1. Open USB cover;
2. Remove product cover;
3. Correctly insert (U)SIM into the slot according to direction shown in figure,
and confirm that (U)SIM has been inserted completely.
(1) (2) (3)
Insert T-flash card
1. Open USB cover;
2. Remove product cover;
3. Push T-flash card slot and pull out with narrow indicator. Then insert T-flash
card into the slot according to direction shown in figure, and confirm that T-flash
card has been inserted completely.
Note: T-flash slot is placed under the (U)SIM slot. Before inserting T-Flash card,
(U)SIM card should be removed, if present.
