HANTZ ANS-9012 Installation Manual

Chapter 1: Introduction

1.1 Product Overview

The ANS-9012 Flash Disk uses SDHC (Secure Digital High Capacity) memory
cards in a 2.5" SATA HDD form-factor to act as a solid state disk. Its
advantages include lightness, compactness, better transfer rates and shock
resistance compared to conventional hard disks, lower power consumption,
less noise during operation and better tolerance for temperature changes. The
ANS-9012 offers practically unlimited scalability depending on the SDHC
capacity. As SDHC is relatively inexpensive compared to the solid state drives
now in the market, it offers a very competitive solution in terms of price, speed
and capacity. For industrial and military computers that must operate for long
periods of time in special working environments, the ANS-9012 can replace
conventional HDDs for better reliability and meet more types of usage
requirements.

1.2 Specification

ACARD Chip: ANC772
●
Supports SATA 1.5/3Gbps interface in host
●
Offers 6 expansion slots. Each slots supports a 4/8/16/32GB SDHC card
●
Supports SLC NAND Flash memory
●
Maximum capacity: Depends on SDHC capacity
●
Supported operating systems include Windows, Linux and Mac OS X
●

1.3 Features

Standard 2.5" SATA HDD interface
●
Offers a fast and low-cost replacement to expensive solid state drives.
●
Offers solid state drives' advantages such as zero noise and low power
●
consumption.
Offers stable and reliable performance.
●
Offers better read/write access performance, shock resistance and
●
operating temperature range than conventional HDD.
No drivers or software required.
●
SolidD2.5 ANS-9012 Flash Disk

Installation Guide
