- Page 1 PICASSO PCI-3C(PRO) Dual input Triple channel Analog Video PCI frame grabber with optional CVBS inputs User Manual Draft version Rev 2.B doc 1.0...
- Page 2 Rev 2.B doc 1.0 Copyright © 2001 by ARVOO Engineering BV All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by means, electronic, mechanical, by photocopying, recording, or otherwise, without the prior written permission of ARVOO Engineering BV.
- Page 3 CONTENTS CONTENTS OVERVIEW ..............................4 FEATURES ..............................5 GETTING STARTED........................... 6 ........................ 6 ARDWARE EQUIREMENTS NSTALLING THE PICASSO ......................... 6 ..........................7 CONNECTORS 1.3.1 Video sources ..........................7 1.3.2 General Purpose Input /Output connector .................. 9 APPENDIX A ..............................11 picasso PCI-3C User Manual - 3 -...
-
Page 4: Overview
OVERVIEW OVERVIEW The picasso PCI-3C is a high-performance ‘plug and play’ PC-card for the PCI-bus. It enables each standard PCI system to capture and store single images for image processing or full-frame display of real-time video in a window (30 frames/sec). The picasso PCI-3C operates as a PCI bus master, allowing it to transfer images directly to the system or VGA memory without impacting the processor. -
Page 5: Features
FEATURES FEATURES 32-bit PCI interface, 3.3V or 5V I/O compatible The picasso is a full PCI 2.1 bus master with a transfer rate up to 132 Mbytes/sec. This allows the bus master to transfer up to 30 frames/sec. Support of zero wait state burst transfers. Two RGB colour/multiple monochrome video inputs Several configurations are possible, selected by software. -
Page 6: Getting Started
A mouse or compatible pointing device. One 3.5 inch floppy disk drive for installation. ARVOO recommends only motherboards that are equiped with modern PCI-chipsets, good test results have been found with e.g. the Intel 440BX, i810, i815 or i820 chipsets. -
Page 7: I/O Connectors 1.3.1 Video Sources
GETTING STARTED 1.3 I/O connectors Figure 1 1.3.1 Video sources The picasso PCI-3C supports two RGB video sources or six B&W. The picasso PCI-3Cpro supports two RGB, six B&W, or four CVBS (composite colour) video sources. The selection of the different video inputs is software controlled. The green LED (D1) [see Figure 1] indicates locking of the frame grabber on an incoming video signal. - Page 8 GETTING STARTED The video input-connector is a SUB-D15 connector and the GPIO is a SUB-D9 connector [see Figure 2]. SUB-D15 SUB-D9 Figure 2: Close-up of RGB-VID and GPIO connectors. Table 1 shows connection of the video sources to the SUB-D15 connector. The pin assignment depends on the video sources that are used.
-
Page 9: General Purpose Input /Output Connector
When U19 and F1 is placed [see Figure 1] no external power supply is needed. U19 will provide the external 5V. F1 is a fuse with the following specifications: 250mA, fast. Ask ARVOO support for more information. ATTENTION: The maximum output current is 100mA. - Page 10 GETTING STARTED In Figure 6 a wiring example for an output is given. External 5V Imax 100 External power supply picasso output 0/1 Figure 5 In Figure 6 a wiring example for an input is given. External 5V External power supply picasso Input 0/1...
-
Page 11: Appendix A
APPENDIX A Appendix A 1. Electrical specifications Electrically-compatible with PCI specification, version 2.1. Power requirements Min. Typical Max. Supply voltage, Vcc 4.75 V 5.0 V 5.25 V Supply current, Vcc = 5.0 V 1.0 A 1,1 A Supply voltage, 12Vcc 11.5 V 12 V 12.5 V...
