Double Power Electronics DP-8120VB User Manual

1+1 pocket. multi-currency banknote sorter

Hide thumbs

Table Of Contents

User Manual

Preface

Thank you for choosing our products! It is an accurate, reliable multi-currency banknote

sorter, the structure design and performance are more scientific and the operation is extremely

smooth and vibration free. it defines a new standard of banknote counting machines with sorting

functions.

In order to make the best use of the accurate banknote counting/sorting capability of the unit,

please read this manual carefully before using and operate as per the procedures stipulated in the

manual.

Contents

Safety Instruction ................................................................................................................................................... 2

Features .................................................................................................................................................................... 3

Unpacking ................................................................................................................................................................ 3

Exterior Introduction .............................................................................................................................................. 4

Operation Instruction ............................................................................................................................................ 6

Function Instruction .............................................................................................................................................. 8

User Menu Instruction ........................................................................................................................................ 12

Sensitivity Parameters Setting .......................................................................................................................... 13

Resume to Factory Setting ................................................................................................................................ 15

Troubleshooting ................................................................................................................................................... 15

Regular Maintenance Instruction ..................................................................................................................... 20

How to replace the fuse .................................................................................................................................... 20

Specifications ....................................................................................................................................................... 21

Prepared by

i-Currency Banknote Sorter

Mult

2015.09.26

16:35:43 +08'00'

1+1 Pocket

User Manual

Reviewed by

2015.09.2

6 17:21:32

+08'00'

Approved by

2015.10.14

14:30:11

+08'00'

Table of Contents

Need help?

Do you have a question about the DP-8120VB and is the answer not in the manual?

Questions and answers

Summary of Contents for Double Power Electronics DP-8120VB

Page 1 User Manual 1+1 Pocket i-Currency Banknote Sorter Mult User Manual Preface Thank you for choosing our products! It is an accurate, reliable multi-currency banknote sorter, the structure design and performance are more scientific and the operation is extremely smooth and vibration free. it defines a new standard of banknote counting machines with sorting functions.
Page 2: Safety Instruction
User Manual Safety Instruction To avoid damage to the machine and personal injury, please read all warnings and cautions carefully before first use!  Place the unit on a solid flat surface.  Before moving the unit, please disconnect the power cord, otherwise the power cord may be damaged resulting in fire and electrical shock.
Page 3: Features
User Manual Features  Detects magnetic ink, infrared ink, UV, CIS image, length, thickness, etc.  Compact size, dual-operator user interface with large and clear LCD display.  Installs up to 4 different currencies, banknotes can be processed in all four orientations. ...
Page 4: Exterior Introduction
User Manual Exterior Introduction 1. Three-view drawing ♦Hopper with adjustable guides ♦Banknote pressing wheel ♦Hopper ♦Banknote twiddling wheel ♦Control panel ♦LCD display ♦Reject pocket ♦Banknote receiving wheel ♦Banknote receiving sensor ♦Stacker 2. Back view ♦ Adjusting screw ♦ Handle ♦On/off Switch ♦Handle of back drawer ♦RS232 port ♦Banknote...
Page 5 User Manual 3. Explanation about the user’s panel ：Currency section. ：Batch function on/off and set batch number. ：Increase the batch number by 1(just press) or 10(press and hold). ：Send count report to print. ：Counting mode settings: MIX, SINGLE, FACE, ORIENT, COUNT. ：Add function on/off.
Page 6: Operation Instruction
User Manual Operation Instruction In order to avoid counting/detecting errors, the following banknotes should be handle before counting: ① Keep the banknotes in order ② Straighten out the folded notes ③ Remove the wrinkled notes ④ Remove any stray foreign object from the note pack ⑤...
Page 7 User Manual messages are displayed on the LCD, please handle them according to the Troubleshooting in the manual. Figure 1 Before counting the banknotes, please adjust the left and right hopper guide to a suitable position base on the length of the banknotes for smooth feeding. Next place the well-prepared banknotes onto the hopper flatly and the machine will start counting.
Page 8: Function Instruction
User Manual Function Instruction 1. Currency selection After turning on the machine, the symbol of current currency is displayed on the LCD. If you need counting/sorting other types of currencies, press "CUR" key to change current currency, the symbol of installed currency will be displayed in turn. "EUR"...
Page 9 User Manual Denomination Piece Value If the printer is connected to the machine, press the "PRINT" key, the report will be printed. 2015-06-26 08:33 Deno Value EUR 10 EUR 20 EUR 50 Total B. Single mode In single mode, "SINGLE" is displayed on the LCD and the machine can count the same denomination.
Page 10 User Manual In Face mode, "FACE" is displayed on the LCD and the machine will sort the banknotes according to front and back. The banknote with a front or the rear side first detected by the sensor, becomes the reference for stacker.
Page 11 User Manual pieces that have been counted. Note: In count mode, the counterfeit detecting function is switched off. 3. Accumulative Counting When you need accumulative counting, press the "ADD" key on the control panel, if "ADD" is displayed on the LCD, the machine will count on the basic of the original number displayed on the LCD.
Page 12: User Menu Instruction
User Manual User Menu Instruction In normal working state, press the "MENU" key to enter user menu interface, you can select the any item by pressing the "ADD" key or "DISPLAY" key. 1. Counting Speed After selecting "1:SPEED" item, press the "RESET" key to enter, there are three kinds of speed you can select.
Page 13: Sensitivity Parameters Setting
User Manual 3. Capacity of the Reject Pocket In user menu interface, After selecting " 3:REJECT POCKET CAPACITY" item, press the "RESET" key to enter, and then you can select the capacity of the reject pocket. 4. Date and Time Setting In user menu interface, After selecting "...
Page 14 User Manual Please follow the steps to change the sensitivity parameters setting: In normal working state, press the “ CLEAR” key for 5 times to enter maintenance menu, press the “ ” key to enter “1 SENSITIVE SET” item; Press the " ”...
Page 15: Resume To Factory Setting
User Manual Resume to Factory Setting Press the “ CLEAR ” key for 5 times to enter maintenance menu, press the “ ” or “ ” key to select the “5 FACTORY DEF” item, press the “ ” key to enter the item or save the setting result;...
Page 16 User Manual 2. How to adjust the feeding clearance The adjusting screw of the feeding clearance on the top cover has already been set to the best position in the factory. But when you meet the following problems during counting/sorting, it is necessary to re-adjust the adjusting screw.
Page 17 User Manual avoid strong light source 2. Re-adjust UV sensor Left Counting 1.Remove the banknote and clear away the dust. 2.Re-adjust counting IR sensor Right Counting 3.Replace left/right counting receiving tube Left2 Counting SENSOR Right2 Counting SENSOR Left CIS IR 1.
Page 18 User Manual (MG2) Replace MRS magnetic board (MG5) (MG4) Replace big magnetic sensor (MT) (MG6) Replace magnetic board on the right (MG7) (MG9) 4. Detective error message display and solutions If one of the following error messages is displayed on the LCD during the course of counting/sorting, please handle them as per the following solutions after the machine is stopped.
Page 19 User Manual 1.Remove it and continue the counting 2.If it is often displayed, adjust CIS IR transmission light 3.Lower the sensitivity level. 1.Remove it and continue the counting 2.If it is often displayed, adjust UV sensor 3. Replace UV sensor Remove it and continue the counting.
Page 20: Regular Maintenance Instruction
User Manual Regular Maintenance Instruction ■ If the temperature is lower than 20℃, please turn on the machine and wait for 3 minutes before counting. ■ The machine shall be operated at places with good ventilation and kept away from strong sunshine and strong magnetic field.
Page 21: Specifications
User Manual Specifications Counterfeit detection: IR, MG, CIS IMAGE, MT, UV, etc Counting speed: 800/1000/1200 notes/min, select-able Hopper Capacity: 500 notes Stacker Capacity: 200 notes Reject Pocket Capacity Max, 50 notes Power supply: 100~240V AC, 50/60Hz Power consumption: ≤50W Temperature: 0℃~40℃...
