1. OUTLINE 1.1 STRUCTURE AND PRINCIPLE SVA190WX01TB module is composed of the amorphous silicon thin film transistor liquid crystal display (a-Si TFT LCD) panel structure with driver LSIs for driving the TFT (Thin Film Transistor) array and a backlight. The a-Si TFT LCD panel structure is injected liquid crystal material into a narrow gap between the TFT array glass substrate and a color-filter glass substrate. -
Page 5: General Information
At IBL=6.5Arms / lamp and checkered flag pattern Power consumption 22 W (typ.) Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 6: Block Diagram
Note: System ground(GND), FG (Frame ground) in the product should be connected together in customer equipment. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 7: Detailed Specification
Note3: Measured at center of LCD module's rear shield surface (including self-heat) Note4: No condensation Note5: Ta = 50°C, RH = 85% Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 8: Electrical Characteristics
(Cold terminal) and high voltage terminal (Hot terminal). Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 9: Power Supply Voltage Sequence And Ripple
If customer stops the display signals, they should cut Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 10 If the power supply capacity is above the fusing current, the fuse may blow in a short time, and then nasty smell, smoking and so on may occur. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
- Page 11 4.4.4 Connectors for power supply and signals CN201 CN202 Insert direction CN203 CN204 Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 12: Interface And Connector Pin Alignment
Not connection. Ground +5.0V power supply +5.0V power supply +5.0V power supply Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 13 System ground (GND), FG (Frame ground) and VBLC (Lamp low voltage terminal) in the product should be connected together in customer equipment. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 14: Lvds I/F Data Chart
Global LCD Panel Exchange Center SN-SA-A0032-04-E 14/39 4.6 LVDS I/F DATA CHART Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 15 Note4: If only Hsync and Vsync, the product don’t work. Make sure DE signal has been input. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 16: Display Colors And Input Data Signals
Note: Combination with 8 bit (256 grayscale) R,G,B color signal , the color can be formed. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 17: Interface Timing
Refer to the timing DE/Data characteristics of LVDS Hold time transmitter Rise time, Fall time Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 18 Invalid Vertical timing DATA(A),(B) Invalid Invalid 899 900 Note 1: DATA(A)=RA0-RA7,GA0-GA7,BA0-BA7 DATA(B)=RB0-RB7,GB0-GB7,BB0-BB7 Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
- Page 19 ••• • • • • ••• • D(1,900) D(2,900) D(2,900) ••• D(1440,900) Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 20: Optics
Also measurement method for luminance is as follows. 50cm Luminance Meter (TOPCON BM-5A) Spectroradiometer(TOPCON SR-3) LCD module (Product) Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 21 10% up to 90%. (See the following diagram.) 100% White Luminance Black Toff Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
- Page 22 4.9.5 Definition of viewing angle Normal axis (Perpendicular) 12 o’clock Left Upper Lower Right Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 23: Defect Criteria
Note 6 See“4.10.2 Close defect dots”. Note 7 See“4.10.3 Linked defect dots”. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 24 : Dark dot defect dots Combination between bright dotsand dark dot Etc. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
- Page 25 3 defect dots Combinations between bright dot and dark dot Allowed Etc. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
- Page 26 Note3: If any problems arise with the LCMS suppliers by suppliers, the custom and supplier will cooperate and make efforts to solve it with mutual confidence and respect. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 27: Reliability Tests
Note2: See the following figure for discharge points. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 28: Estimated Luminance Lifetime
Note1: MTTF is mean time to half-luminance. In case the product works under low temperature environment, the lifetime becomes short. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 29: Markings
7.3 OTHER MARKINGS High voltage caution marking Disposal method marking for lamp Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 30: Indication Locations
Product rear side High voltage caution Disposal method marking Barcode label Product label Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 31: Packing, Transportation And Delivery
524 L x348 W x 423 H typ. Weight 1 typ. 13.5 typ. Total weight (with 5 products) Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 32: Outline Figure For Packing
8.5 OUTLINE FIGURE FOR PACKING 8.5.1 Packing box LCD module Packing box Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 33 Packing boxes (6boxes×3 tiers maximum) Cardboard pallet Top cap Cardboard sleeve Band Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 34: Precautions
(such as bezel flat area) except mounting hole portion. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 35 .Otherwise, there is the fear that a display dignity decreases by an impact or vibrations. Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
-
Page 36: Outdrawing
Global LCD Panel Exchange Center SN-SA-A0032-04-E 36/39 10. OUTDRAWING 10.1 FRONT VIEW Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! -
Page 37: Rear View
Global LCD Panel Exchange Center SN-SA-A0032-04-E 37/39 10.2 REAR VIEW Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! - Page 38 1. Add the max. of Luminance uniformity(TBD to 1.33)p20 Add DEFECT CRITERIA(p23~26) Not duplication without authorization Shanghai SVA NEC Liquid Crystal Display Co., Ltd. www.panelook.com One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
