- Page 1 Platinum CCTV Surveillance Solutions CD-9360 SONY Indoor/Outdoor Day/Night Long-Range Infrared Varifocal 540 TVL Camera Installation Manual Outdoor Varifocal Hi-Res Day/Night Infrared CCD Bullet Camera For Warranty Registration, Visit Http:// Platinum-CCTV.com...
- Page 2 Platinum CCTV Surveillance Solutions Camera Installation Camera Mounting: Items Needed: Screwdriver, Drill, Mounting Hardware (not included), Pencil Mark the bolt holes and attach bracket to wall Loosen the adjustments and position camera as desired.
- Page 3 Platinum CCTV Surveillance Solutions Camera Installation Remove back of camera housing Adjust Zoom/Focus with 2 adjustment screws Set Camera’s higher level functions with On- Screen Display once connected.
- Page 4 Platinum CCTV Surveillance Solutions CD-9360 Long Range IR CCD Camera Image Sensor 1/3” SONY HQ1 CCD Number of Pixels NTSC: 540 (H) x 491 (V) Scanning System 15.7343Khz (H), 60 Hz (V) Sync System Internal Synchronization Resolution 540 TVL Lens 4-9mm Varifocal Lens (Ext.
