SAFETY FIRST!
READ INSTRUCTIONS COMPLETELY
Before getting started please read this
user manual and at all times follow
the important safety instructions.
v1.0
JOETAP
NITRO & STILL
BEVERAGE DISPENSER
ON-DEMAND NITROGENATED BEVERAGES
FROM CONCENTRATE
I N S TA L L A T I O N , U S E & M A I N T E N A N C E G U I D E
JT-CTMG
BARISTA
®
Listed by Edison Testing Laboratories.
Conforms to UL & NSF Standards.
Pending
Advertisement
Table of Contents
Related Manuals for Micro Matic JOETAP JT-CTMG
Summary of Contents for Micro Matic JOETAP JT-CTMG
- Page 1 SAFETY FIRST! READ INSTRUCTIONS COMPLETELY Before getting started please read this user manual and at all times follow the important safety instructions. JT-CTMG JOETAP BARISTA ® NITRO & STILL BEVERAGE DISPENSER ON-DEMAND NITROGENATED BEVERAGES FROM CONCENTRATE I N S TA L L A T I O N , U S E & M A I N T E N A N C E G U I D E v1.0 Listed by Edison Testing Laboratories.
- Page 2 2 | JOETAP BARISTA INSTALLATION, USE & MAINTENANCE GUIDE 855-4JOETAP (866) 327-4159 MICROMATIC.COM ®...
-
Page 3: Table Of Contents
ROUTINE MAINTENANCE & CLEANING SAFETY & PROCEDURAL NOTICES .............4 RECEIVING & INSPECTING ...............6 SPECIFICATIONS ..................6 DIMENSIONS ....................7 COMPONENTS ..................8 LOCATION & INSTALLATION ...............9 MAKING ADJUSTMENTS ................15 GENERAL OPERATION ................20 ROUTINE MAINTENANCE & CLEANING ............21 TROUBLESHOOTING ................22 DECOMMISSIONING ................24 TERMS OF USE. WARRANTY. INDEMNIFICATION........26 855-4JOETAP (866) 327-4159 MICROMATIC.COM... -
Page 4: Safety & Procedural Notices
SAFETY NOTICES As you work on this equipment, be sure to pay close attention to the safety notices in this manual and any warning/caution labels on the unit. Disregarding the notices may lead to serious injury and/or damage to the equipment. Read and understand ALL applicable OSHA (Occupational Safety and Health Administration) safety regulations and/or national and local codes before operating this unit. - Page 5 READ THESE BEFORE PROCEEDING NOTE: Save these instructions. NOTE: We reserve the right to make product improvements at any time. Specifications and design are subject to change without notice. CAUTION NOTICE WARNING Proper installation, care and Routine adjustments and PERSONAL INJURY POTENTIAL maintenance are essential maintenance procedures Do not operate equipment...
-
Page 6: Receiving & Inspecting
Request an inspection by the shipping company of the original manufactured specifications. damaged equipment. Retain all crating material until inspection has been made. Finally, contact Micro Matic. UNCRATING: 1. Cut and remove the outer packaging 2. Lift the unit off the skid 3. -
Page 7: Dimensions
547.65 [21.56] NOTE: We have developed this manual as a reference guide for the owner/operator and installer of this equipment. Please read this manual before installation or operation of the machine. A qualified service technician must perform installation and start-up of this equipment. -
Page 8: Components
COMPONENTS ELECTRICAL HAZARD WARNING LABEL (3" X 3") STILL FAUCET SERIAL NUMBER/ NAME /CERTIFICATION LABEL (3" X 5") NITRO FAUCET POWER CORD WATER INLET PORT DATE OF MANUFACTURE LABEL N2 GENERATOR GAS RESERVOIR GAUGE VOLTAGE REGULATOR GAUGE N2 REGULATOR GENERATOR ON/OFF ADJUSTMENT SCREW INDICATOR LIGHT N2 REGULATOR... -
Page 9: Location & Installation
These instructions are provided to assist the qualified installer. Contact your distributor guidelines may affect warranty coverage. or call JoeTap/Micro Matic for information regarding start-up services. INSTALLATION LOCATION REQUIREMENTS The JT-CTMG may be island-mounted or installed on a front or rear counter. Locate the unit so the following requirements are satisfied. - Page 10 ELECTRICAL NOTICE • Must be installed near a properly grounded electrical outlet with proper electrical requirements fused at proper amperage or circuit connected through an equivalent Due to continuous improvements, this HACR circuit breaker with ELCB (GFCI). information is for reference only.
- Page 11 REQUIRED TOOLS & MATERIALS CAUTION Cutting the countertop • Hand installation pincers for ear clamps (to install ear clamp on water inlet barb connection). may decrease its strength. Counter should be braced • Square head screwdriver (Robertson) & Phillips head screwdriver (to adjust N2 regulator, to support the dispenser countertop weight plus gently pry caps, and remove lid from the unit).
- Page 12 FILL CHILLER WATER/ICE BATH • Fill the water/ice bath with 2 gallons of water. – Water/ice bath should be filled using sight glass tube on the front of the chiller. NOTE: Sight glass tube accessed by opening dispenser door and removing two Phillips head screws from white plastic shroud covering the face of the chiller.
- Page 13 STARTUP & GAS LEAK TEST • Open the door and turn ON the two green switches located on the chiller air inlet shroud and ensure that all of the buttons located on the control panel are turned OFF. NOTE: Buttons that are on will be illuminated. –...
- Page 14 FINE-TUNING BRIX & LEVEL OF N2 INFUSION NOTICE • Pour a full serving from the nitro faucet and determine if N2 infusion pressure needs to be adjusted. Do not leave the product pump button on while the – If there is too much head/cascading or not enough head/cascading, adjust accordingly. water pump button is off for Recommended head size after settling: ½"...
-
Page 15: Making Adjustments
POST-INSTALLATION OVERVIEW • Location – Floor drain, ambient conditions, countertop weight support, air ventilation clearance • Electrical connection – Grounded, dedicated circuit, refer to name label on the back of the system • Water connection – Flow rate, max pressure, in-line shutoff, treatment, temperature •... - Page 16 PROCEDURE NOTICE • Increase Level of N2 infusion (thicker head and more dramatic cascading effect). – Turn the N2 regulator adjustment screw clockwise. Do not leave the product pump button on while the – Hold the gas in button for a full second. water pump button is off for extended periods of time, •...
- Page 17 • To adjust the voltage regulator, press the set button until a digit that needs adjusted is blinking. • Once a digit that needs adjusted is blinking, use the +/– buttons on the regulator to increase or decrease the blinking digit’s value. •...
- Page 18 PROCEDURE (CONTINUED) • Test the flow rate adjustment and continue adjusting/testing until the desired water flow rate and still faucet brix reading are achieved. • Reinstall the black plastic cap that covered the still water flow rate adjustment. ADJUSTING PRESSURE SWITCH NOTE: Always check for debris in nose cone of pulsing faucet before determining pressure switch needs adjusted.
- Page 19 • Press the start button to test the sample. • Record the brix reading. • Press the start button to test the sample again. NOTE: If the readings differ by more than .1, press the start button once more and test/ record the reading.
-
Page 20: General Operation
GENERAL OPERATION • Under normal circumstances, both green switches on the face of the chiller, the water WARNING pump button, and the product pump button should be ON. ELECTRIC SHOCK HAZARD • Use only one faucet at a time. If both faucets are opened at the same time, the nitrogen Unplug unit before servicing faucet will starve for water and begin sputtering. -
Page 21: Routine Maintenance & Cleaning
ROUTINE MAINTENANCE & CLEANING WARNING When using cleaning fluids DAILY or chemicals, rubber gloves and eye protection should • Wipe down and clean all surfaces with warm soapy water. be worn. – Refrigerated product storage area. – Exterior surfaces of the system including beneath the unit and the drip tray (if applicable). -
Page 22: Troubleshooting
PROCEDURE (CONTINUED) • Turn ON the product pump button and open nitro faucet again. – Dispense 8 of cleaner, turn ON the water button, dispense for five seconds, turn OFF the water pump button, and continue to dispense 8 more ounces of undiluted cleaner. –... - Page 23 PROBLEM POSSIBLE CAUSE(S) SOLUTION(S) 1. Loose connection, severed 1. Nitrogen Generator: Gas leak line, or faulty part a. Take note of the pressure reading on the N2 regulator. Turn the gas supply (Nitrogenator ™ to the dispenser OFF using gas OFF button. Wait 1-2 minutes and turn Nitrogen Generator the gas supply back ON keeping an eye on the regulator pressure.
-
Page 24: Decommissioning
DECOMMISSIONING WARNING Only trained and certified • Clean system following Routine Cleaning Procedure (section 8) making sure Bag-in-Box electrical, plumbing and refrigeration technicians of product is not reconnected after the Bag-in-Box cleaner is disconnected. should service this unit. • Ensure water pump and product pump buttons are ON. •... - Page 25 NOTES 855-4JOETAP (866) 327-4159 MICROMATIC.COM JOETAP BARISTA INSTALLATION, USE & MAINTENANCE GUIDE | 25 ®...
-
Page 26: Terms Of Use. Warranty. Indemnification
Matic’s maximum liability hereunder in any case is expressly Matic will have no responsibility to honor claims received after limited to, at Micro Matic’s election, (i) the repair or replacement the date the Warranty Period expires. of the Product without charge or refund of the purchase price, WHAT WILL MICRO MATIC DO? upon return of the Product in accordance with Micro Matic’s... - Page 27 Micro Matic’s gross negligence, even if Micro Matic has whether known or unknown, against Micro Matic, and its been advised of the possibility of such damage or loss. Some...
- Page 28 NationalAccounts@Micro-Matic.com Info@JoeTap.com 866-327-4159 855-4JoeTap (855-456-3827) micromatic.com/joetap joetap.com 28 | JOETAP BARISTA INSTALLATION, USE & MAINTENANCE GUIDE 855-4JOETAP (866) 327-4159 MICROMATIC.COM ® 01857-D0717 ©2017 Micro Matic USA, Inc. All Rights Reserved. Micro Matic reserves the right to change specifications without notice.
