Summary of Contents for BONNET PRO Mini Max Mule 220R

Page 1 MULE 220R Owner’s/Operator’s Manual...
Page 2 These guidelines are presented for your protection and convenience. Please read them carefully, since a failure to heed these precautions could result in discomfort or injury. When using an electrical appliance, basic safety precautions and common sense should always be followed. Bonnet Pro will not be responsible for machine operator errors.
Page 3 WARNING! Before using, front plug located on gearbox behind sprayer bracket must be replaced with included breather plug. Oil must be changed after the first 50 hours and every 500 hours thereafter. 14 ounces Mobil SHC 634 Gear oil must be used. Failure to do so will void your warranty.
Page 4: Storage And Transportation
PLEASE NOTE: Before using your MiniMax. Breather plug must be installed to prevent an upper oil seal failure. Failure to follow procedure for installing the breather vent WILL VOID YOUR WARRANTY! When you receive you MiniMax you will need to change the solid plug with the breather plug that is supplied in the little bag attached to the chassis, pic #1.
Page 5: Oil Change Instructions
Oil Change Instructions Your new MiniMax Terminator uses a gearbox that contains oil rather than grease. This allows you to easily change the lubricant in your machine. Grease will weaken and become soiled over time. With oil like in your car, you can easily add new clean lubricant for a long product life.
Page 6 SoMe tHinGS to reMeMBer Before You Start Thank you for your purchase of the MiniMax. With reasonable care this machine should give you years of productive service. We appreciate the trust you placed in us with your purchase. #1 To start, only fill your solution tank with 1 gallon until you become accustomed to the feel and weight of your machine. Also start with a broken in soft carpet bonnet (19”) if possible, a 17”...
Page 7: Operation
Always remember to recycle if possible. Bonnet Pro 4529 Bethlehem Pike Telford, PA 18969 Phone: (215) 723-5330 www.bonnetpro.com Specifications and parts are subject to change without notice. Copyright 2016 Bonnet Pro. All rights reserved. Printed in U.S.A.
Page 8: Important Safeguards
thank you for your purchase. WarninG: Maintenance and repairs must be done by authorized personnel only. WarninG: Keep all fasteners tight. Keep adjustments according to Your new MiniMax Carpet Machine will afford you many specifications. years of trouble-free operating satisfaction provided it is given proper care.
Page 9: Safety Precautions
• With damaged cord or plug. environment and is not constructed for any other use. use • If not in proper operating condition. only recommended cleaning chemicals from Bonnet Pro. • In outdoor areas. • In standing water. all operators must read, understand and practice the •...
Page 10 WarninG To prevent injury, always remove the electrical plug from the electrical outlet before changing the Revive encapsulation pads or bonnets and before leaving the machine. PrePare tHe MaCHine for oPeration To attach the drive block or brush or other attachment, be sure the handle is “locked”...
Page 11: Machine Operation
Machine operation MaCHine oPeration attention: Use caution when starting out, the machine will jolt for SafetY: Do not operate machine, unless operator when the on/off triggers are pulled. manual is read and understood. WarninG: fire or explosion Hazard. never operate Machine 6.
Page 12: Transporting Machine
Machine operation switch, wait 15 seconds and press the reset button located on the 7. Change oil after first 50 hours and every 500 hours thereafter. handle. See video at bonnetpro.com concerning oil changes and machine maintenance. 8. Do not operate the machine in the same spot for a long period of time.
Page 13 operating the MiniMax Pump Your pump is the demand type. Meaning if you have no demand or When starting, using the front sprayer your initial setting might be water flow it will not run/ make noise. If your solution control valve between the blue and silver colored rings on the solution control valve is closed or the front sprayer valve is shut and the shower feed valve (pic#1) For a setting using the shower feed you might start between...
Page 14 Do not over tighten handle clamp Bonnet Pro suggests using your hand and not your foot to This will cause the clamp to fail and is not covered under warranty. To adjust your handle clamp, tighten it as much that is needed to prevent engage and disengage the handle clamp.
Page 15: Troubleshooting
troubleshooting ProBLeM CauSe SoLution Machine does not operate. Faulty power cord. Contact Service Center. Tripped circuit breaker. Reset circuit breaker on machine. Tripped building circuit breaker. Reset circuit breaker in building. Faulty machine wiring. Contact Service Center. Faulty On/Off handle switch. Contact Service Center.
Page 16 Steps and Coil Hose WARnInG: When going up stairs: It is always the operator’s responsibility to assess the safety of moving their MiniMax up stairs to make sure conditions are safe. Always remove the chemical jug if full and the detachable power cord to lighten the machines weight.
Page 17 These guidelines are presented for your protection and convenience. Please read them carefully, since a failure to heed these precautions could result in discomfort or injury. When using an electrical appliance, basic safety precautions and common sense should always be followed. Bonnet Pro will not be responsible for machine operator errors.
Page 18 • Return the part to the factory for warranty work. Bonnet Pro will repair or replace the defective part(s) (at the company’s option) if the defect is a result of manufacturing, mate- rials, or workmanship during the warranty period.
