Remote Control Engine Starter System
Owner's Manual
Introduction
1.Introduction・・・・・・・・・・・・・・・・・・・・・・・・・・2
9.Troubleshooting・・・・・・・・・・・・・・・・・・・・・・・・11
10.Specifications・・・・・・・・・・・・・・・・・・・・・・・12
Congratulations on your purchase of the MITSUBISHI MOTORS Remote Control Engine
Starter System. This system will provide you with convenience and assistance, making
each drive a delightful experience.
To take full advantage of your MITSUBISHI MOTORS Remote Control Engine Starter System
please read this manual thoroughly.
Keep this manual handy for easy reference.
DANGER
MITSUBISHI MOTORS Remote Control Engine Starter System is only for Automatic
transmission cars.
DO NOT install MITSUBISHI MOTORS Remote Control Engine Starter System in Manual
transmission cars.
- 1 -
08, 8

Advertisement

loading
Need help?

Need help?

Do you have a question about the PZ113 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Faltec PZ113

  • Page 1: Table Of Contents

    Remote Control Engine Starter System Owner’s Manual Introduction 1.Introduction・・・・・・・・・・・・・・・・・・・・・・・・・・2 2.Features of the System ・・・・・・・・・・・・・・・・・・・・・3 3.Safety Precaution・・・・・・・・・・・・・・・・・・・・・・・・4 4.Operating the Transmitter・・・・・・・・・・・・・・・・・・・・6 5.Setting the Idling Time・・・・・・・・・・・・・・・・・・・・・8 6.Before Leaving Your Car・・・・・・・・・・・・・・・・・・・・・8 7.Care and handling・・・・・・・・・・・・・・・・・・・・・・・・9 8.Transmitter Battery Replacement・・・・・・・・・・・・・・・・10 9.Troubleshooting・・・・・・・・・・・・・・・・・・・・・・・・11 10.Specifications・・・・・・・・・・・・・・・・・・・・・・・12 Congratulations on your purchase of the MITSUBISHI MOTORS Remote Control Engine Starter System.
  • Page 2 1.Introduction Safety Messages ●The following symbols are used in this manual. DANGER WARNING are extremely important. The instructions following these symbols ! ! must be read thoroughly and followed accordingly. The instructions following this symbol must be followed for safety. DANGER !...
  • Page 3: 2.Features Of The System ・・・・・・・・・・・・・・・・・・・・・3

    2.Features of the System ●The remote control engine starter system consists of a Transmitter that allows you to start and stop the engine from outside of the vehicle without using the car keys. ← P.6 However, as precaution measures, the Transmitter will not start the engine unless all of the following conditions are satisfied: ①The gearshift lever is in the “P"...
  • Page 4: 3.Safety Precaution・・・・・・・・・・・・・・・・・・・・・・・・4

    3.Safety Precaution DANGER ! Do not start your engine in a closed garage or other area with poor ventilation. Exhaust fumes can cause poisoning and cause unconsciousness and even death. DANGER ! Electric waves from the transmitter can carry very far depending on the surrounding circumstances.
  • Page 5 WARNING ! Do not start the engine near flammable material, such as grass. It can cause fire. WARNING ! Do not start the engine without removing the body cover from the car. It can cause fire. WARNING ! To prevent accidents during engine warm up, when parking make sure that: - the wiper switch and winkers are turned OFF.
  • Page 6: 4.Operating The Transmitter・・・・・・・・・・・・・・・・・・・・6

    4.Operating the Transmitter Electric waves from the transmitter can carry very far depending on the surrounding circumstances. To prevent an accident caused by accidental start of the engine, be sure to operate the remote control car starter system in an area where you can check the surroundings of your car. Before you start the engine ・Check your car so that it satisfies all conditions listed on page 8.
  • Page 7 Stopping the engine. Operation of the Transmitter Push the request button Let go of the request button when the indicator blinks. Push the stop button while the indicator is blinking (about 2 seconds). The blinking indicator will change to a continuous light (about 3 seconds), and the engine-stopping signal will be transmitted The engine stops.
  • Page 8: 5.Setting The Idling Time・・・・・・・・・・・・・・・・・・・・・8

    5.Setting the idling time Consult your dealer for setting the idling time. The idling time can be set for 5 minutes, 10 minutes, 20 minutes or 30 minutes. Initial setting (at factory before shipping) is ten minutes. 6.Before Leaving Your Car Always confirm that the following engine starting conditions 1-4 are satisfied before using the remote control engine starter.
  • Page 9: 7.Care And Handling・・・・・・・・・・・・・・・・・・・・・・・・9

    7.Care and handling To prevent system breakdown and accidents WARNING ! ・tore the transmitter out of reach of children If your transmitter is ever lost or malfunctioning, contact your dealer at once. ・ In case you lend your car and keys to a third party, do not include your Transmitter for preventing accidents.
  • Page 10: 8.Transmitter Battery Replacement・・・・・・・・・・・・・・・・10

    8.Transmitter Battery Replacement Replace old batteries for new ones according to the following procedures: Battery Replacement ① Remove the screw in the battery cover Close the battery cover according to steps using a plus driver. ① to ③. ② Lift the front side of the cover. ③...
  • Page 11 9.Troubleshooting Check the following symptoms to diagnose problems with the Remote Control Engine Starter System before consulting your dealer. Engine does not start by operating the transmitter. 【The indicator of the Transmitter does not light up】 Check Remedy The next transmission cannot be made for two Is a transmission repeated directly one after seconds after the indicator goes off.
  • Page 12 10.Specifications Transmitter Main Unit(Receiver) Communication Communication 426.0500MHz 426.0500MHz frequency frequency Communication uni-directional Communication uni-directional (receiving) method (transmission.) method Application Transmission FCC conforming Coaxial cable whip antenna standard antenna Operation Transmission time approximately 3 seconds power-supply DC10V~16V Transmission rest Two seconds or more voltage time Current...
