- Page 1 Dust Networks™ ® Eterna Evaluation & Development DC9006A and DC9004B User Guide Interface Card & Programming JTAG Adapter...
-
Page 2: Table Of Contents
Table of Contents About This Guide...................3 Audience ....................3 Related Documents..................3 Conventions and Terminology ...............3 Revision History ..................4 Getting Started .....................5 DC9006 Interface Card.................5 Installation ....................5 Setup ......................6 Warning .....................6 Interface Card (DC9006A) ................7 Block Diagram ....................7 USB Interface .....................7 JTAG ......................7 SPI ......................7 CLI......................8 API ......................8... -
Page 3: About This Guide
About This Guide This document describes the DC9006 and DC9004B Eterna Evaluation & Development boards. The latest revision of this document may be found online at: www.linear.com/docs/58003. Audience This document is intended for system, hardware and software developers. Related Documents The following related documents are available: DC9006 &... -
Page 4: Revision History
Revision History Revision Date Description May 19, 2017 First Release July 11, 2017 Added footer ADI Confidential notice Internal Document Number: 040-0132 DC9006A DC9004B U NALOG EVICES ONFIDENTIAL UIDE... -
Page 5: Getting Started
Getting Started DC9006 Interface Card The DC9006 Interface Card is a USB interface for Eterna Evaluation & Development Mote such as the DC9018. The DC9006 may also be used as a programmer when connected to a DC9004B adapter card. In this case, the DC9006 provides access to any Eterna platforms that feature the recommended programming connectors. -
Page 6: Setup
Once drivers are installed for the Interface Board, one should use the same USB port each time the manager is connected to the computer. If a different USB port is used, the setup procedure will need to be repeated for that port. The Eterna Evaluation and Development Board Set require Windows 7 or Windows XP with SP3, or later versions of Windows. -
Page 7: Interface Card (Dc9006A)
Interface Card (DC9006A) Block Diagram The following diagram depicts the main features of the DC9006 Interface Card. Figure 2 Diagram of the DC9006 Interface Card (right) USB Interface The Interface Card communication interface to the USB host consists of four serial ports. -
Page 8: Cli
The third USB serial port provides access to the UARTC0_TX and UARTC0_RX lines of the LTC5800 (when JP1 “CLI OFF” jumper is not installed). A 2-wire serial interface is supported; typically 9600 baud, the baud rate is application dependant and is described in the Eterna Board Specific Parameter Configuration Guide. -
Page 9: Jumper Settings
VCCA JP5A HDR_2MM_PTH HDR_100MIL_PTH CURRENT AddOn JP5B RED JUMPER HDR_100MIL_PTH 10.0, 1% 0402 VSENSE ISO_VSUPPLY Figure 3 Current Sensing Jumpers A third 0.100” header P2 is provided for ground reference. Both P2 pins are connected to the isolated ground. For accurate current measurements, all JP1 headers shall be installed (see section: Mote Signal Disconnection). -
Page 10: Interface Signal Disconnection
Jumper Description Default Note disconnects the JTAG lines from one of the USB serial interface and should always be installed unless the USB JTAG interface is supported in the development or evaluation tools; "SPI OFF" to disconnect SPI lines, RESETn and FLASH_P_ENn; "CLI OFF"... -
Page 11: Eterna Evaluation And Development Mote Socket Pinout
ISO_MOTE_OFFn ISO_MOTE_OFFn VCCA_SW SC70 ISL43L210 100k VCCA ISO_MOTE_OFFn 0201 ISOOC_RESETn SPST-NO NoStuf f DMN2004 SWT3-G 0201 SC70-3 ISOSW_TDI ISOSW_TMS 0201 ISOSW_TCK ISOSW_TDO 0201 0.1uF ISOOC_RESETn 0201 0201 0201 NoStuf f 0201 100MIL_VERT_SHR HDR2X10BOXED EXT. JTAG & SWD CONNECTOR MOTE RESET Figure 5 External JTAG Pinout, Reset &... -
Page 12: Programming Adapter (Dc9004B)
Programming Adapter (DC9004B) Introduction The DC9004B Programming Adapter enables the DC9006 Interface card to connect to a variety of interfaces on a customer board featuring an Eterna chip. The DC9004B supports the following customer board connections: • the 2x5 2mm pitch programming header, described in the integration guide; •... -
Page 13: Usage
Usage For a non-powered customer board, where the customer board is powered by the VSUPPLY and GND signals of the DC9004, simply connect the ribbon cable. For an independently powered customer board, first place the DC9006 JP7 jumper (see Figure 4) in the “OFF” position, then connect the ribbon cable. Note that in this configuration the DC9006 will draw some power from the customer board to power some of its circuitry. -
Page 14: Jtag And Swd Interfaces (2X5 2Mm" Pitch Header)
In order to use the Tag-Connect TC2050-IDC cable, a surface mount footprint located on the customer board shall match the following pin numbering. CLI_RX RESETn CLI_TX VSUPPLY FLASH_P_ENn IPCS_MOSI IPCS_SSn IPCS_SCK IPCS_MISO Figure 8 Tag-Connect Programming Footprint JTAG and SWD Interfaces (2x5 2mm” pitch header) The following table describes the pinout of the JTAG P6 (MOLEX/878321020). -
Page 15: Ltp5900 Socket (26-Pin, 2Mm Pitch)
Pin # Signal Direction Pin # Signal Direction Notes: Pin#1 may be connected to VSUPPLY when P8 jumper is installed (not recommended with self - powered board). Signal direction is relative to the Programming Adapter board. The Tag-Connect cable TC2030-CTX-20 only support SWD mode and connect the following signals to the customer board footprint below. -
Page 16: Limitations
Pin # Signal (J1) Dir. Pin # Signal (J2) Dir. FLASH_P_ENn Signal direction is relative to the Programming Adapter board Limitations Ribbon Cable Length Evaluation kits are shipped with the latest version for the DC9006. However, for early versions of the DC9006 (700-0184 rev5 or earlier), the maximum recommended ribbon cable length is 2 inches. - Page 17 DEMONSTRATION BOARD IMPORTANT NOTICE Linear Technology Corporation (LTC) provides the herein referenced item(s) under the following AS IS conditions: Any evaluation and development board or kit referenced herein (the “DEMO BOARD”, “DEMO CIRCUIT”, or “DC”) being sold or provided by Linear Technology is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not provided by LTC for commercial use.
- Page 18 Trademarks SmartMesh, SmartMesh IP, Dust, Mote-on-Chip are trademarks of Dust Networks, Inc. Dust Networks and Eterna, are registered trademark of Dust Networks, Inc. All third-party brand and product names are the trademarks of their respective owners and are used solely for informational purposes. Copyright This documentation is protected by United States and international copyright and other intellectual and industrial property laws.
- Page 19 Page Intentionally Left Blank DC9006A DC9004B U UIDE NALOG EVICES ONFIDENTIAL...
