Mercia Garden Products 03OVLPBRN0705-V2 Instructions Manual

03OVLPBRN0705-V2
Overall Dimensions:
Length = 1490mm
Width = 2131mm
Height = 2195mm
Base Dimensions:
Length = 1448mm
Width = 2082mm
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN

BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY

- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand
(not supplied) including a Phillips screwdriver, Stanley knife, wood saw,
step ladder and drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be a ected during various weather
conditions. For the duration of heavy or extended periods of rain, swelling of the
wood panels may occur. Warping of the wood may also occur during excessive
dry spells due to an interior moisture loss. Unfortunately, these processes cannot
be avoided but can be helped. It is suggested that the outdoor building is
sprayed with water during extended periods of warm sunshine and sheltered as
much as possible during rain or snow.
Our buildings are delivered pre-treated with a water based timber treatment
however this only helps to protect during transit of your garden item. To
validate your guarantee and for better protection against weathering it is
ESSENTIAL that you treat the garden building with a wood preserver within 3
months of assembly. This will need to be re-applied annually to ensure longevity
of your building. Care must be taken when constructing the garden building
that it is not touching the ground and is on a suitable base.

BUILDING A BASE

When thinking about where the building and base is going to be constructed: Ensure that there will be access to all sides for maintenance
work and annual treatment.

TYPES OF BASE

- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base dimensions, The base should be
slightly smaller than the external measurement of the building, i.e. The cladding should overlap the base, creating a run o for water. It is also
recommended that the oor be at least 25mm above the surrounding ground level to avoid ooding.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens products independently tested to EN71
level, we cannot accept responsibility for your safety whilst erecting or using this product.
Mercia Graden Products Limited, Sutton On Trent, Newark, Nottinghamshire, NG23 6QN
www.merciagardenproducts.co.uk
16/03/2012
x2
This building should be erected by
two adults
For ease of assembly, it is advisable to
pilot drill all screw holes and ensure
all screw heads are countersunk.
2mm Drill bit
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
For Assistance Please
Contact Customer Care on
01636 880514
Please retain product label and instructions for future reference
1
Door Gable
Qty 1
4 5
Floor
Qty 1
Slave Door
Qty 1
Fixing Kit
8
Roof Eave - 27x32x1720mm Qty 2
9
Ridge Bar - 27x44x1457mm Qty 1
10
Fascia - 12x80x1240mm Qty 4
11
Centre Fascia Block- 44x44x340mm Qty 1
12
Fascia Block- 27x44x140mm Qty 2
13
Finial - Qty 2
2
3
Plain Gable Plain Side
Qty 1
Qty 2
7
6
Roof Sheet
Qty 2
Master Door
Qty 1
14
16
Press lock
15
Qty 1
17
Chrome
18
Handle
Qty 2
19
Felt
20
Butt Hinge
Qty 6
Barrel Bolt
Qty 2
Corner
Brace
Qty 2
Turn
button
