ELX200 Passive Loudspeakers
ELX200-10 | ELX200-12 | ELX200-15 | ELX200-12S | ELX200-18S
en | Installation manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELX200-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Electro-Voice ELX200-10

  • Page 1 ELX200 Passive Loudspeakers ELX200-10 | ELX200-12 | ELX200-15 | ELX200-12S | ELX200-18S en | Installation manual...
  • Page 3: Table Of Contents

    Tripod or pole mount Floor monitor Suspension Recommended configurations Basic stereo system using full-range systems Using full-range systems as stage monitors Stacking full-range systems with subwoofers Troubleshooting Technical data Dimensions Frequency response Electro-Voice Installation manual 2017.10 | 01 | F.01U.326.890...
  • Page 4: Safety

    Electro-Voice installation guides. Do NOT use handles to suspend the loudspeaker. Handles on Electro-Voice loudspeakers are intended to only be used for temporary transport by people. Items, such as fiber rope, wire rope, cables, or other types of materials cannot be used to suspend loudspeaker from the handles.
  • Page 5: Precautions

    Do not use Electro-Voice loudspeakers in an environment where temperatures are below 0°C (32°F) or exceed +40°C (104°F). Never expose an Electro-Voice loudspeaker to rain, water, or high moisture. Electro-Voice loudspeakers are easily capable of generating sound pressure levels sufficient to cause permanent hearing damage to anyone within normal coverage distance.
  • Page 6: Description

    ELX200 Passive Loudspeakers Description Thank you for choosing an Electro-Voice passive loudspeaker system. Please take time to consult the manual to understand all the features built into your EV system and fully utilize its performance capabilities. ROCK SOLID SOUND: Electro-Voice ELX200 portable loudspeakers The ELX200 series is the newest member of the best-selling Electro-Voice portable loudspeaker family.
  • Page 7 Ideal for portable and installed applications. Lightweight, compact 15 mm wood enclosure with internal bracing with durable polyurea top-coat finish. ▪ Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting. Electro-Voice Installation manual 2017.10 | 01 | F.01U.326.890...
  • Page 8: Tripod And Floor Monitor Operation

    ELX200 Passive Loudspeakers Tripod and floor monitor operation Tripod or pole mount ELX200-10, ELX200-12, and ELX200-15 loudspeakers mount on a tripod stand or on a pole above a subwoofer. Mounting a loudspeaker on a tripod stand Figure 3.1: Full-Range models on a tripod stand Caution! Tripod is not evaluated for safety with this loudspeaker.
  • Page 9 Tighten the thumb screw to secure the loudspeaker to the pole. The thumb screw is only available on the 12" and 15" full-range loudspeaker models. The 10" full-range loudspeaker does not have a thumb screw. Electro-Voice Installation manual 2017.10 | 01 | F.01U.326.890...
  • Page 10: Floor Monitor

    ELX200 Passive Loudspeakers Floor monitor ELX200-10, ELX200-12, and ELX200-15 loudspeakers may be used as a floor monitor by placing the loudspeaker on the integral monitor angle. To set up a loudspeaker as a floor monitor, do the following: Place the loudspeaker on a level and stable surface.
  • Page 11: Suspension

    Suspending any object is potentially dangerous and should only be attempted by individuals who have a thorough knowledge of the techniques and regulations of suspending objects overhead. Electro-Voice strongly recommends all loudspeakers be suspended taking into account all current national, federal, state, and local laws and regulations. It is the responsibility of the installer to ensure all loudspeakers are safely installed in accordance with all such requirements.
  • Page 12 Eyebolts must be fully seated and oriented in the plane of pull. Always use washers under the eyebolt to distribute the load on the enclosure. Figure 4.2: Eyebolt shown with washers (A) and without washers (B) 2017.10 | 01 | F.01U.326.890 Installation manual Electro-Voice...
  • Page 13 Figure 4.3: Eyebolts shown orientated in the plane of pull (left correct, right incorrect) Warning! Never exceed the limitations or maximum recommended working load for Electro-Voice loudspeakers. Disregarding this warning could result in serious injury or death. 5° MAX 5° MAX 5°...
  • Page 14: Recommended Configurations

    ELX200 Passive Loudspeakers Recommended configurations Basic stereo system using full-range systems Basic stereo system using ELX200-10, ELX200-12 or ELX200-15 loudspeakers (ELX200-15 versions shown). ELX200-10, ELX200-12, ELX200-15 Output 2 Amplifier Mixer Input B Input A NL4 Pin Configuration Pin 1+ and 1-...
  • Page 15: Using Full-Range Systems As Stage Monitors

    Using full-range systems as stage monitors Multiple ELX200-10, ELX200-12 or ELX200-15 loudspeakers in monitor position (ELX200-15 versions shown). Amplifier Mixer NL4 Pin Configuration Pin 1+ and 1- Used Pin 2+ and 2- Not used Caution! Do not exceed the maximum load rating of the amplifier.
  • Page 16: Stacking Full-Range Systems With Subwoofers

    ELX200 Passive Loudspeakers Stacking full-range systems with subwoofers This configuration allows a user to increase the low frequency performance without using additional amplifier channels (ELX200-15 and ELX200-18S versions shown). ELX200-10, ELX200-12, ELX200-15 ELX200-12S ELX200-18S Output 2 Amplifier Input B Mixer...
  • Page 17 Amplifier Load (per Output Channel) # of Subwoofer/Full-Range Nominal Minimum Combinations 4 Ohms 3.8 Ohms 2 Ohms 1.9 Ohms Electro-Voice Installation manual 2017.10 | 01 | F.01U.326.890...
  • Page 18: Troubleshooting

    Most likely there is a break in the signal path. Poor system Check and correct the system grounding, as required. grounding or ground loop If these suggestions do not solve your problem, contact your nearest Electro-Voice dealer or Electro-Voice distributor. 2017.10 | 01 | F.01U.326.890 Installation manual Electro-Voice...
  • Page 19: Technical Data

    Technical data ELX200-10, ELX200-12, and ELX200-15 ELX200-10 ELX200-12 ELX200-15 Freq. response (-3 dB): 65 Hz - 20 kHz 77 Hz - 17 kHz 77 Hz - 16 kHz Freq. range (-10 dB): 49 Hz - 22 kHz 51 Hz - 20 kHz...
  • Page 20: Dimensions

    [13 in] 220mm [9 in] 273 mm [11 in] 531 mm [21 in] 118 mm [5 in] Figure 7.1: ELX200-10 dimensions 155 mm [6 in] 363 mm 253 mm [10 in] [14 in] 344 mm [14 in] 311 mm [12 in]...
  • Page 21: Frequency Response

    [10 in] [11 in] 229 mm 600 mm [9 in] 24 in 574 mm [23 in] 160 mm [6 in] Figure 7.5: ELX200-18S dimensions Frequency response Figure 7.6: ELX200-10 frequency response and impedance Electro-Voice Installation manual 2017.10 | 01 | F.01U.326.890...
  • Page 22 ELX200 Passive Loudspeakers Figure 7.7: ELX200-12 frequency response and impedance Figure 7.8: ELX200-15 frequency response and impedance Figure 7.9: ELX200-12S frequency response and impedance 2017.10 | 01 | F.01U.326.890 Installation manual Electro-Voice...
  • Page 23 Figure 7.10: ELX200-18S frequency response and impedance Electro-Voice Installation manual 2017.10 | 01 | F.01U.326.890...
  • Page 24 Bosch Sicherheitssysteme GmbH Bosch Security Systems, Inc Robert-Bosch-Ring 5 12000 Portland Avenue South 85630 Grasbrunn Burnsville MN 55337 Germany www.boschsecurity.com www.electrovoice.com © Bosch Sicherheitssysteme GmbH, 2017...
