- Page 1 Quick Start Guide Wireless Video Kit, 150 Feet Range, One to One HDMI, up to 1080P GWHDKIT11 PART NO. Q1492 www.iogear.com...
-
Page 2: Package Contents
Package Contents 1 x HDMI Extender Transmitter 1 x HDMI Extender Receiver 1 x IR Blaster Extension Cable 1 x IR Receiver Extension Cable 2 x Antennas 2 x 5 VDC/2A Wall Mount Switching Power Supply 1 x Quick Start Guide System Requirements 1 HDMI source device (DVD, PS3, Set top box, PC etc.) 1 HDMI display device (SDTV, HDTV, projector with HDMI port, etc.) - Page 3 Overview Transmitter A. Power input B. HDMI signal indicator C. Wireless signal indicator D. HDMI input E. IR Blaster extension cable connector F. Antenna connector Receiver A. Power input B. Data transmission indicator C. Wireless connection indicator D. HDMI output connector E.
-
Page 4: Hardware Installation
Hardware Installation STEP 1 Install the antenna to the transmitter (F) STEP 2 Connect the IR blaster cable to the connector (D) STEP 3 Connect one side of the HDMI cable to the transmitter (D) and the other side to your video source... - Page 5 Hardware Installation STEP 4 Install the antenna to the receiver (F) STEP 5 Connect the extension cable to the connector (E) STEP 6 Connect one side of the HDMI cable to the receiver (D) and the other side to your video source...
- Page 6 Hardware Installation STEP 7 Connect 5VDC/2A power supply to the Transmitter power input port (A), the HDMI signal indicator (B) will light up when connection to the source is established STEP 8 Connect 5VDC/2A power supply to the Receiver power input port (A) STEP 9 Wireless connection indicator of the transmitter and receiver will light up when the transmitter and receiver connection is established wirelessly...
- Page 7 Q Transmitter and receiver cannot be connected wirelessly A 1. Please check if the wireless connection light is on and blinking 2. Restart both transmitter and receiver 3. Reconnect HDMI cables Q The wireless indicator is on but no signal to the display A Please check and see if the video source is working correctly by connecting the HDMI cable directly to the display and see if the operation is now normal...
-
Page 8: Compliance Information
Important Product Information Product Model Serial Number Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR iogear.custhelp.com support@iogear.com www.iogear.com...
